JVC SP-THM508F Service Manual

3-26
DVD servo board
Block No. [0][7]
C1 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C2 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C3 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C5 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C6 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C7 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
CN1 QGF1036F1-15 CONNECTOR FFC/FPC (1-15)
CN2 QGB2024K1-07S CONNECTOR B-B (1-7)
CN3 QGB2024J1-07S CONNECTOR B-B (1-7)
SW1 QSW0844-001 PUSH SWITCH
SW2 QSW0844-001 PUSH SWITCH
SW3 QSW0844-001 PUSH SWITCH
SW4 QSW0844-001 PUSH SWITCH
SW5 QSW0844-001 PUSH SWITCH
SW6 QSW0854-002 PUSH SW
SW8 QSW0923-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
IC201 LA6502-X IC
IC301 MN2DS0004AA-H IC
IC302 BA00HC5WF-X IC
IC305 MM1563DF-X IC 3.3V Regulator
IC451 MN101C61GNE1 IC(MCU)
IC452 BR93L56RFV-W-X IC
IC453 S-80827CNNB-W IC
IC505 K4S643232F-TC60 IC
IC509 AT49BV322AT70TI IC(FLASH)
IC512 SN74LVC373APW-X IC(DIGITAL)
IC513 SN74LVC373APW-X IC(DIGITAL)
IC701 AK4384VT-X IC
IC702 AK4384VT-X IC
IC703 AK4384VT-X IC
IC704 CS5342-CZZ-X IC(DIGITAL)
IC705 MM1615AN-X IC
Q101 KTA1001/Y/-X TRANSISTOR
Q102 2SC4617/R/-X TRANSISTOR
Q103 KTA1001/Y/-X TRANSISTOR
Q104 2SC4617/R/-X TRANSISTOR
Q105 UN2119-X TRANSISTOR
C101 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C102 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C103 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C104 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C105 NEA70JM-226X E CAPACITOR 22uF 6.3V M
C106 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C107 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C108 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C204 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C205 NCB31HK-271X C CAPACITOR 270pF 50V K
C206 NDC31HJ-151X C CAPACITOR 150pF 50V J
C211 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C217 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C251 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C256 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C257 NCB31HK-822X C CAPACITOR 8200pF 50V K
C258 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C259 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C260 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C261 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C262 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C300 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C301 NEA70GM-227X E CAPACITOR 220uF 4V M
C302 NEA70GM-476X E CAPACITOR 47uF 4V M
C303 NBE20JM-476X TA E CAPACITOR 47uF 6.3V M
C304 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C305 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
 Symbol No. Part No. Part Name Description Local
C306 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C307 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C308 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C309 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C310 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C311 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C312 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C313 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C314 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C315 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C316 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C317 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C318 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C319 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C320 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C321 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C322 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C323 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C324 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C325 NDC31HJ-180X C CAPACITOR 18pF 50V J
C326 NDC31HJ-150X C CAPACITOR 15pF 50V J
C328 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C329 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C330 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C331 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C332 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C333 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C334 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C335 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C336 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M
C337 NCB31CK-183X C CAPACITOR 0.018uF 16V K
C338 NCB31HK-562X C CAPACITOR 5600pF 50V K
C339 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C340 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C341 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C347 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C348 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C349 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C350 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C351 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C352 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C353 NCB31HK-561X C CAPACITOR 560pF 50V K
C354 NCB31HK-561X C CAPACITOR 560pF 50V K
C356 NCB21CK-105X C CAPACITOR 1uF 16V K
C359 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C371 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C380 NCB21CK-105X C CAPACITOR 1uF 16V K
C381 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C382 NCB31HK-471X C CAPACITOR 470pF 50V K
C391 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C451 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C452 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C453 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C454 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C455 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C551 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C552 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C553 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C554 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C555 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C556 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C557 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C558 NEA70GM-476X E CAPACITOR 47uF 4V M
C701 NCB21CK-105X C CAPACITOR 1uF 16V K
C702 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C703 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C704 NCF21CZ-225X C CAPACITOR 2.2uF 16V Z
C705 NCF21CZ-225X C CAPACITOR 2.2uF 16V Z
C706 NCF21CZ-225X C CAPACITOR 2.2uF 16V Z
C707 NCF21CZ-225X C CAPACITOR 2.2uF 16V Z
C708 NCF21CZ-225X C CAPACITOR 2.2uF 16V Z
C709 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C712 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C713 NEA71CM-106X E CAPACITOR 10uF 16V M
C714 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C715 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C716 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C717 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
 Symbol No. Part No. Part Name Description Local
