RS-232C INTERFACE (SR-MV55U ONLY)
9F: Remote Data The remote control codes for controlling the VTR (similar to wired remote control) via RS-232C are as shown in
the following table. The codes apply to both DVD and VCR deck unless otherwise stated.
Code Items Remarks Code Items Remarks
03 STOP/CLEAR 88 TBC ON/OFF VCR Deck only
04 EJECT VCR Deck only 8E ON SCREEN
06 S.FWD/SLOW+ 90 MEMORY/MARK DVD Deck only
07 S.REV/SLOW– 96 CM SKIP
08 FWD SLOW 1/6 VCR Deck only 97 DV INPUT DVD Deck only
0B POWER ON/OFF AF REV FRAME
0C PLAY/SELECT B0 –SLOW D
DVD Deck only
0D PAUSE B1 SHUTTLE
– C
14 NEXT/6/INDEX +1 B2 SHUTTLE
– B
15
PREVIOUS/ 2 /INDEX –1 B3 SHUTTLE – A
17 AUDIO B4 SHUTTLE
– 2
18 INPUT – B5 SHUTTLE
– 1
19 INPUT + B6 –SLOW B
1E ON SCREEN VCR Deck only B7 –SLOW C
20 TEN KEY 0/AUX/SPACE
DVD Deck only
B8 +SLOW C
21 TEN KEY 1 B9 +SLOW B
22 TEN KEY 2/ABC BA SHUTTLE +1
23 TEN KEY 3/DEF BB SHUTTLE +2
24 TEN KEY 4/GHI BC SHUTTLE +A
25 TEN KEY 5/JKL BD SHUTTLE +B
26 TEN KEY 6/MNO BE SHUTTLE +C
DVD Deck only27 TEN KEY 7/PQRS BF +SLOW D
28 TEN KEY 8/TUV C0 ANGLE/LIVE CHECK
29 TEN KEY 9/WXYZ C4 SUBTITLE DVD Deck only
31 REMAIN/REC MODE CC REC
36 CANCEL CD REC PAUSE
37 SET UP CE INDEX +1
VCR Deck only38 DISPLAY CF INDEX
– 1
39 COUNTER RESET VCR Deck only D0 REV SLOW 1/6
3C ENTER D4 RETURN
3D FINALIZE DVD Deck only D6 VCR/DVD
40 AUTO TRACKING ON/
OFF
VCR Deck only
D8 JOG –1
DVD Deck only
41 TRACKING + D9 JOG –1/2
42 TRACKING – DA JOG +1/2
43 VCR DECK DVD Deck only DB JOG +1
44 DVD DECK
VCR Deck only
DC INSTANT REPLAY
7C SP E0 TOP MENU/NAVIGATION DVD Deck only
7D LP E1 L1 Y/C INPUT SELECT
80 CURSOR e E2 L1 COMPOSITE INPUT SELECT
81 MENU DVD Deck only EA AUX(L-1) SELECT VCR Deck only
82 CURSOR r EC F-1 Y/C INPUT SELECT
84 CURSOR w ED FWD FRAME
86 CURSOR t EE F-1 COMPOSITE INPUT SELECT
87 OPEN/CLOSE DVD Deck only
