RS-232C INTERFACE (SR-MV55U ONLY)
JVC Status Sense
DISC TYPE
DD JVC
SENSE
1byte 2byte 3byte 4byte
VCR DVD VCR DVD VCR DVD VCR DVD
bit7 1 (Fixed) 1 (Fixed) 0 (Fixed) 0 (Fixed) 1 (Fixed) 1 (Fixed) 1 (Fixed) 1 (Fixed)
bit6 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 1 (Fixed) 1 (Fixed)
bit5 0 (Fixed) 0 (Fixed) 1 (Fixed) 1 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed)
bit4
During
Playback of EP
Recorded Tape
0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed)
bit3 0 (Fixed) 0 (Fixed) 0 (Fixed)
Refer to the
DISC TYPE
table below.
0 (Fixed) 0 (Fixed)
During
dubbing
(Including
PAUSE)
During
dubbing
(Including
PAUSE)
bit2 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed)
bit1 0 (Fixed) 0 (Fixed) 1 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed)
bit0 1 (Fixed) 1 (Fixed) 0 (Fixed)
During
dubbing
(Including
PAUSE)
During
dubbing
(Including
PAUSE)
0 (Fixed) 0 (Fixed)
bit3 bit2 bit1 bit0
DVD 0000
DVD-RAM 0001
DVD-R 0010
DVD-RW 0011
DVD+R 0000
DVD+RW 0000
VCD 0110
CD 0111
... ... ... ... ...
No disc 1111
