JVC SR-VS30E Service Manual

5-3
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
******************************
FINAL ASSEMBLY <M2>
! 501 LP10409-008B FRONT PANEL ASSY,VS30E
LP10409-009B FRONT PANEL ASSY,VS30EK
501A LP21070-003B CASSETTE DOOR(VHS)
501B PQ46448 TORSION SPRING(VHS)
501E LP31048-008B DOOR(R),VS30E
LP31048-009B DOOR(R),VS30EK
501F LP30756-002A C.DOOR(DV)
501G LP40688-001A SPRING(DV)
501H LP31047-005B DOOR(L)
501J PU60109 CATCHER,X2
501K LP21071-002A COVER
501L QYTDSF2608Z SCREW,X2
! 502 LP10411-006A TOP COVER
503 QYTDSF3010R SCREW,X4,TOP COVER(SIDE)
504 QYTDSF3010M SCREW,X2,TOP COVER(REAR)
505 LP20981-019A DRUM SUB ASSY
505E LP40323-001A CONTACT
505F LP30004-014A COMPRESSION SPRING
506 PDZ0179-1-4 ROTOR ASSY
507 QYSPSP3006Z SCREW,X2,ROTOR
! 508 QAR0169-002 STATOR ASSY
509 QYSPSPH2606Z SCREW,X2,STATOR
510 QYTDST2610Z SCREW,X3,DRUM
! 511 LP10412-001B BOTTOM CHASSIS
513 LP21073-001A BASE(DV)
515 QYTDST2606Z SCREW,X3,DV MECHA
516 QYTDSF3010Z SCREW,X4,BASE(DV)
527 PQ46617B-1 FOOT ASS’Y,X2
528 PQ35504 FOOT(2),X2(REAR)
! 530 QMP4A10-170 POWER CORD,VS30E
! QMP51K0-170-K POWER CORD,VS30EK
531 QYTDSF4012Z SCREW,X2,VHS MECHA
533 LP40226-001A PC SUPPORT,X2
535 QYTDSF3010Z SCREW,X2,VHS MECHA
539 QYTDSF3010Z SCREW,VHS MAIN
542 QYTDST2606Z SCREW,X4,DV MAIN
543 QYTDSF3010Z SCREW,X3,SW REG
548 QAR0121-001 FAN MOTOR
549 LP40918-001A SCREW,X2,FAN MOTOR
553 QYTDSF2608Z SCREW,X8,SW/DISPLAY
554 QYTDSF3010Z SCREW,X2,BRACKET(CHASSIS)
555 LP30312-001B BRACKET(CHASSIS)
556 LP40407-001A KNOB ASSY
557 LP40370-001E ROLLER ARM ASSY
557A PDM4311A-1 ROLLER ASSY
558 PQ45160 INERTIA PLATE
559 LP31095-004A KNOB ASSY
562 QYTDSF2608Z SCREW,X2,JOG
563 PU49485-4 WIRE CLAMP
564 QYTDSF3010Z SCREW,WIRE CLAMP
565 QYTDSF2608Z SCREW,X2,POWER SW
566 LP31072-001B T.BOARD(FAN)
! 567 QYTDSF3010Z SCREW,SW REG
568 QYTDSF3010Z SCREW
! 569 LP10413-001A BOTTOM COVER
570 PQ35504 FOOT(2)(CENTER)
WR1 WJT0005-001A E-CARD WIRE,AC HEAD CN2001
WR2 QUQ210-0820CC FFC WIRE,DV MAIN CN2601
WR3 QUQ212-0414CG FFC WIRE,DV MAIN CN3014
WR4 QUQ112-1428CG FFC WIRE,DV MAIN CN701
WR5 QUQ112-1008CG FFC WIRE,FRONT CN7510
WR6 QUQ112-2008CG FFC WIRE,FRONT CN3011
WR7 QUQ212-0516CG FFC WIRE,DRUM CN3001
WR8 QUQ212-1028CG FFC WIRE,SW REG CN7508
WR9 QUQ212-1238CG FFC WIRE,SW REG CN7509
WR10 QUQ105-2008AA FFC WIRE,MDA CN1501
WR11 QUQ212-0810CG FFC WIRE,SW REG CN1001
WR12 QJA002-051600 SIN ID C-C WIRE,SW REG CN5324
WR7002 QUB220-05XLXL SIN TWIST WIRE
