5-11

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

or RN1309 DIGI TRANSISTOR

or UN521E DIGI TRANSISTOR

Q2051 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

Q2052 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR

Q2053 DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSISTOR

or UN521E DIGI TRANSISTOR

Q2054 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q2061 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

Q2062 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q2251 DTA144WU DIGI TRANSISTOR

or PDTA144WU DIGI TRANSISTOR

or RN2309 TRANSISTOR

or UN511E DIGI TRANSISTOR

Q2252 DTC114EU DIGI TRANSISTOR

or PDTC114EU DIGI TRANSISTOR

or RN1302 DIGI TRANSISTOR

or UN5211 DIGI TRANSISTOR

Q2601 DTC114EU DIGI TRANSISTOR

or PDTC114EU DIGI TRANSISTOR

or RN1302 DIGI TRANSISTOR

or UN5211 DIGI TRANSISTOR

Q2602 DTC114EU DIGI TRANSISTOR

or PDTC114EU DIGI TRANSISTOR

or RN1302 DIGI TRANSISTOR

or UN5211 DIGI TRANSISTOR

Q3001 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR

Q3002 PTZ-NV16 PHOTO TRANSISTOR

or PTZ-NV16A PHOTO TRANSISTOR

Q3003 PTZ-NV16 PHOTO TRANSISTOR

or PTZ-NV16A PHOTO TRANSISTOR

Q3004 2SD1819A/QRS/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

Q3005 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR

Q3007 UN521E DIGI TRANSISTOR

or DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSISTOR

Q3009 UN521E DIGI TRANSISTOR

or DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSISTOR

Q3010 UN521E DIGI TRANSISTOR

or DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSISTOR

Q3011 UN521E DIGI TRANSISTOR

or DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSISTOR

Q4001 UN5211 DIGI TRANSISTOR

or DTC114EU DIGI TRANSISTOR

or PDTC114EU DIGI TRANSISTOR

or RN1302 DIGI TRANSISTOR

Q5401 2SB1256 TRANSISTOR

Q5402 DTC114TU DIGI TRANSISTOR

or PDTC114TU DIGI TRANSISTOR

or RN1311 TRANSISTOR

or UN5215 DIGI TRANSISTOR

Q5403 2SD1450/ST/-T TRANSISTOR

or 2SD1302/ST/-T TRANSISTOR

Q5404 2SD2144S/UV/-T TRANSISTOR

Q6030 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR

Q6031 DTC114EU DIGI TRANSISTOR

or PDTC114EU DIGI TRANSISTOR

or RN1302 DIGI TRANSISTOR

or UN5211 DIGI TRANSISTOR

Q6032 DTC114EU DIGI TRANSISTOR

or PDTC114EU DIGI TRANSISTOR

or RN1302 DIGI TRANSISTOR

or UN5211 DIGI TRANSISTOR

Q7501 DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSISTOR

or UN521E DIGI TRANSISTOR

Q7502 2SC1317/RS/-T TRANSISTOR

D1 DA204U DIODE

D6 MTZJ5.1C ZENER DIODE

D202 QRE141J-152Y RESISTOR 1.5kØ,1/4W

D203 QRE141J-101Y RESISTOR 100Ø,1/4W

D204 QRE141J-101Y RESISTOR 100Ø,1/4W

D701 DA204U DIODE

D2001 1SS133 DIODE

or 1N4148M DIODE

D2202 MTZJ8.2C ZENER DIODE

D3001 LNB2301L01VI LE DIODE

D3002 1SS133 DIODE

or 1N4148M DIODE

D3003 RD39ES/B3/-T2 ZENER DIODE

or MTZJ39C ZENER DIODE

D3004 11ES2 DIODE

or 1A3G DIODE

D3005 11ES2 DIODE

or 1A3G DIODE

D3007 1SS355 DIODE

D3008 1SS355 DIODE

D4001 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W

D4002 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W

D5401 11ES2 DIODE

or ERA15-02-T2 DIODE

or 1A3G DIODE

D5402 MTZJ11C ZENER DIODE

or RD11ES/B3/-T2 ZENER DIODE

D6002 HZ30-2L-T2 ZENER DIODE
