JVC SR-VS30E Service Manual

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
5-16
C723 NCB21HK-103X CAPACITOR 0.01µF,50V
C724 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C725 NCB21HK-103X CAPACITOR 0.01µF,50V
C726 NCB21HK-103X CAPACITOR 0.01µF,50V
C727 QEKJ1CM-106 E CAPACITOR 10µF,16V
C2001 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C2002 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2003 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C2005 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C2006 NCB21HK-123X CAPACITOR 0.012µF,50V
C2007 QEKJ1CM-226 E CAPACITOR 22µF,16V
C2008 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C2009 NCB21HK-122X CAPACITOR 0.0012µF,50V
C2010 NCB21HK-152X CAPACITOR 0.0015µF,50V
C2011 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C2012 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C2016 NCB21HK-221X CAPACITOR 220pF,50V
C2051 NCB21HK-331X CAPACITOR 330pF,50V
C2052 QFLC1HJ-333Z F CAPACITOR 0.033µF,50V
C2053 NCB21HK-332X CAPACITOR 0.0033µF,50V
C2054 NCB21HK-103X CAPACITOR 0.01µF,50V
C2055 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2061 QFLC1HJ-333Z F CAPACITOR 0.033µF,50V
C2062 NCB21HK-332X CAPACITOR 0.0033µF,50V
C2063 NCB21HK-103X CAPACITOR 0.01µF,50V
C2064 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2201 NCB21EK-104X CAPACITOR 0.1µF,25V
C2202 NCB21EK-333X CAPACITOR 0.033µF,25V
C2203 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2204 NCB21HK-102X CAPACITOR 0.001µF,50V
C2205 QEKJ1HM-105 E CAPACITOR 1µF,50V
C2207 QEKJ1CM-476 E CAPACITOR 47µF,16V
C2208 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C2209 NCF21EZ-104X CAPACITOR 0.1µF,25V
C2210 NCF21EZ-104X CAPACITOR 0.1µF,25V
C2213 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2214 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2215 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C2216 QEKJ1HM-474 E CAPACITOR 0.47µF,50V
C2217 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2218 QEKJ1HM-474 E CAPACITOR 0.47µF,50V
C2219 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2220 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C2221 NCB21HK-103X CAPACITOR 0.01µF,50V
C2222 QEKJ1HM-474 E CAPACITOR 0.47µF,50V
C2223 QEKJ1HM-474 E CAPACITOR 0.47µF,50V
C2224 NCB21HK-103X CAPACITOR 0.01µF,50V
C2225 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C2226 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2227 NCB21EK-104X CAPACITOR 0.1µF,25V
C2228 NCB21EK-104X CAPACITOR 0.1µF,25V
C2251 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C2252 NCB21HK-103X CAPACITOR 0.01µF,50V
C2253 NCB21HK-103X CAPACITOR 0.01µF,50V
C2254 NCB21HK-103X CAPACITOR 0.01µF,50V
C2255 NDC21HJ-181X CAPACITOR 180pF,50V
C2601 NDC21HJ-101X CAPACITOR 100pF,50V
C2602 NDC21HJ-101X CAPACITOR 100pF,50V
C2603 NDC21HJ-101X CAPACITOR 100pF,50V
C2604 NDC21HJ-101X CAPACITOR 100pF,50V
C2605 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2606 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2607 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2608 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2609 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2610 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2611 QEKC1EM-106 E CAPACITOR 10µF,25V
C2612 QEKC1EM-106 E CAPACITOR 10µF,25V
C2613 QEKC1EM-106 E CAPACITOR 10µF,25V
C2614 NDC21HJ-101X CAPACITOR 100pF,50V
C2615 NDC21HJ-101X CAPACITOR 100pF,50V
C2616 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2617 QEKJ1EM-106 E CAPACITOR 10µF,25V
C3001 NCB21EK-104X CAPACITOR 0.1µF,25V
C3002 NCB21HK-103X CAPACITOR 0.01µF,50V
C3003 QEKJ1EM-106 E CAPACITOR 10µF,25V
C3004 NCB21EK-104X CAPACITOR 0.1µF,25V
C3008 NDC21HJ-102X CAPACITOR 0.001µF,50V
C3010 QEZ0244-229 EDL CAPACITOR 0.0022F,5.5V
C3012 QEKJ0JM-107 E CAPACITOR 100µF,6.3V
C3015 NCB21EK-104X CAPACITOR 0.1µF,25V
C3016 NCB21EK-104X CAPACITOR 0.1µF,25V
C3022 NCB21EK-104X CAPACITOR 0.1µF,25V
C3024 NDC21HJ-220X CAPACITOR,VS30E 22pF,50V
NDC21HJ-180X CAPACITOR,VS30EK 18pF,50V
C3025 QAT3725-300Z TRIM CAPACITOR,CLOCK ADJ,VS30E
C3027 QERF1CM-106 E CAPACITOR 10µF,16V
C3030 QERF1CM-226 E CAPACITOR 22µF,16V
C3031 NCB21EK-104X CAPACITOR 0.1µF,25V
C3032 NCB21EK-104X CAPACITOR 0.1µF,25V
C3033 NCB21EK-104X CAPACITOR 0.1µF,25V
C3036 NDC21HJ-180X CAPACITOR 18pF,50V
C3037 NDC21HJ-120X CAPACITOR 12pF,50V
C3040 NCB21HK-103X CAPACITOR 0.01µF,50V
C3041 NDC21HJ-120X CAPACITOR,VS30EK 12pF,50V
C3042 QETL0JM-108 E CAPACITOR 1000µF,6.3V
C3050 NCB21EK-104X CAPACITOR 0.1µF,25V
C3054 NCB21HK-103X CAPACITOR 0.01µF,50V
C3602 NCB21EK-104X CAPACITOR 0.1µF,25V
C3652 NCB21EK-104X CAPACITOR 0.1µF,25V
C4002 NCB21EK-104X CAPACITOR 0.1µF,25V
C4003 NCB21HK-102X CAPACITOR 0.001µF,50V
C4004 QEKJ1AM-226 E CAPACITOR 22µF,10V
C4006 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C4007 NCB21HK-102X CAPACITOR 0.001µF,50V
C4008 NCB21AK-105X CAPACITOR 1µF,10V
C4009 NCB21HK-563X CAPACITOR 0.056µF,50V
C4010 NCB21EK-223X CAPACITOR 0.022µF,25V
C4011 NCB21EK-104X CAPACITOR 0.1µF,25V
C4012 NCB21AK-105X CAPACITOR 1µF,10V
C4013 NCB21HK-563X CAPACITOR 0.056µF,50V
C4014 NDC21HJ-101X CAPACITOR 100pF,50V
C4015 NCB21HK-102X CAPACITOR 0.001µF,50V
C5401 QEKC1CM-476 E CAPACITOR 47µF,16V
C5402 QEKC1CM-107 E CAPACITOR 100µF,16V
C5403 QEKJ1CM-476 E CAPACITOR 47µF,16V
C5404 QEKJ1CM-107 E CAPACITOR 100µF,16V
C6014 NCB21HK-103X CAPACITOR 0.01µF,50V
C6023 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
C6032 NCF21EZ-473X CAPACITOR 0.047µF,25V
C6033 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
C6037 QEKJ1CM-106 E CAPACITOR 10µF,16V
