JVC SR-VS30E Service Manual

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
5-18
or 2PC4081/R/-X TRANSISTOR
Q1418 2SA1576A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR
Q1419 DTC124TU DIGI TRANSISTOR
Q1420 2SC4081/QRS/-X TRANSISTOR
or 2PC4081/R/-X TRANSISTOR
D1401 RD4.3ES/B3/-T2 ZENER DIODE
D1402 1SS133 DIODE
or 1N4148M DIODE
R1401 NRSA02J-181X MG RESISTOR 180Ø,1/10W
R1402 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R1404 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W
R1406 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R1407 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W
R1408 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W
R1410 NRSA02J-391X MG RESISTOR 390Ø,1/10W
R1411 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W
R1413 NRSA02J-331X MG RESISTOR 330Ø,1/10W
R1414 NRSA02J-821X MG RESISTOR 820Ø,1/10W
R1415 NRSA02J-221X MG RESISTOR 220Ø,1/10W
R1416 NRSA02J-104X MG RESISTOR 100kØ,1/10W
R1417 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R1418 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R1421 NRSA02J-391X MG RESISTOR 390Ø,1/10W
R1426 NRSA02J-561X MG RESISTOR 560Ø,1/10W
R1427 NRSA02J-333X MG RESISTOR 33kØ,1/10W
R1428 NRSA02J-393X MG RESISTOR 39kØ,1/10W
R1429 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W
R1430 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
R1431 NRSA02J-821X MG RESISTOR 820Ø,1/10W
R1432 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W
R1433 NRSA02J-510X MG RESISTOR 51Ø,1/10W
R1434 NRSA02J-153X MG RESISTOR 15kØ,1/10W
R1435 NRSA02J-223X MG RESISTOR 22kØ,1/10W
R1436 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W
R1437 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W
R1438 NRSA02J-473X MG RESISTOR 47kØ,1/10W
R1439 NRSA02J-273X MG RESISTOR 27kØ,1/10W
R1440 NRSA02J-473X MG RESISTOR 47kØ,1/10W
R1441 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W
R1442 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W
R1446 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R1447 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R1448 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R1449 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R1450 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R1452 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R1453 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R1454 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R1455 NRSA02J-681X MG RESISTOR 680Ø,1/10W
R1458 NRSA02J-681X MG RESISTOR 680Ø,1/10W
R1459 NRSA02J-681X MG RESISTOR 680Ø,1/10W
R1460 NRSA02J-273X MG RESISTOR 27kØ,1/10W
R1461 NRSA02J-121X MG RESISTOR 120Ø,1/10W
R1463 NRSA02J-101X MG RESISTOR 100Ø,1/10W
VR1401 QVZ3521-103Z V RESISTOR,D/A LEVEL ADJ
B1412 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
C1401 QEKJ1CM-336 E CAPACITOR 33µF,16V
C1403 QEKJ0JM-337 E CAPACITOR 330µF,6.3V
C1404 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1405 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1406 NCB21HK-103X CAPACITOR 0.01µF,50V
C1407 NDC21HJ-680X CAPACITOR 68pF,50V
C1408 NDC21HJ-330X CAPACITOR 33pF,50V
C1410 QEKJ1EM-475 E CAPACITOR 4.7µF,25V
C1411 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1412 NDC21HJ-680X CAPACITOR 68pF,50V
C1413 NDC21HJ-330X CAPACITOR 33pF,50V
C1415 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1416 QEKJ1CM-106 E CAPACITOR 10µF,16V
C1417 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1421 NDC21HJ-330X CAPACITOR 33pF,50V
C1422 NDC21HJ-680X CAPACITOR 68pF,50V
C1423 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1424 NCB21HK-103X CAPACITOR 0.01µF,50V
C1425 NCB21HK-103X CAPACITOR 0.01µF,50V
C1426 NDC21HJ-390X CAPACITOR 39pF,50V
C1428 NDC21HJ-220X CAPACITOR 22pF,50V
C1429 QEKJ0JM-337 E CAPACITOR 330µF,6.3V
C1430 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1432 NCF21CZ-105X CAPACITOR 1µF,16V
C1433 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1435 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1436 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1437 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1438 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1439 NCB21HK-103X CAPACITOR 0.01µF,50V
C1440 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1441 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1442 NCF21CZ-105X CAPACITOR 1µF,16V
C1444 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1445 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1446 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C1447 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1448 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C1449 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1450 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1451 QEKJ1EM-475 E CAPACITOR 4.7µF,25V
C1452 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1453 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1454 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1455 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1463 QEKJ0JM-336 E CAPACITOR 33µF,6.3V
C1468 NDC21HJ-101X CAPACITOR 100pF,50V
C1470 NDC21HJ-330X CAPACITOR 33pF,50V
C1471 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1472 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1473 NCF21EZ-104X CAPACITOR 0.1µF,25V
L1401 QQL29BJ-100Z COIL 10µH
L1402 QQL071J-6R8Y COIL 6.8µH
L1403 QQL071J-6R8Y COIL 6.8µH
L1404 QQL071J-6R8Y COIL 6.8µH
L1405 QQL01BJ-101Z COIL 100µH
L1406 QQL071J-330Y COIL 33µH
L1407 QQL01BJ-101Z COIL 100µH
L1409 QQL071J-1R0Y COIL 1.0µH
LC1401 QQR0521-007Z NOISE FILTER
LC1402 QQR0521-006Z NOISE FILTER
SD1 LP30706-001C SHIELD FRAME(S-VHS)
SD2 LP30684-001A SHIELD CASE(S-VHS)
CN1401 QGG2502K1-17 HEADER PIN,(1-17)MAIN
