JVC SR-VS30E Service Manual

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
5-24
R3112 NRSA63J-473X MG RESISTOR 47kØ,1/16W
R3113 NRSA63J-220X MG RESISTOR 22Ø,1/16W
R3114 NRSA63J-681X MG RESISTOR 680Ø,1/16W
R3115 NRSA63J-821X MG RESISTOR 820Ø,1/16W
R3116 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R3117 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W
R3118 NRSA63J-473X MG RESISTOR 47kØ,1/16W
R3119 NRSA63J-563X MG RESISTOR 56kØ,1/16W
R3120 NRSA63J-681X MG RESISTOR 680Ø,1/16W
R3121 NRVA63D-821X CMF RESISTOR 820Ø,1/16W
R3122 NRVA63D-821X CMF RESISTOR 820Ø,1/16W
R3123 NRSA63J-271X MG RESISTOR 270Ø,1/16W
R3124 NRSA63J-474X MG RESISTOR 470kØ,1/16W
R3125 NRSA63J-331X MG RESISTOR 330Ø,1/16W
R3131 NRSA63J-563X MG RESISTOR 56kØ,1/16W
R3132 NRSA63J-473X MG RESISTOR 47kØ,1/16W
R3133 NRSA63J-220X MG RESISTOR 22Ø,1/16W
R3134 NRSA63J-681X MG RESISTOR 680Ø,1/16W
R3135 NRSA63J-821X MG RESISTOR 820Ø,1/16W
R3136 NRSA63J-183X MG RESISTOR 18kØ,1/16W
R3137 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W
R3138 NRSA63J-473X MG RESISTOR 47kØ,1/16W
R3139 NRSA63J-393X MG RESISTOR 39kØ,1/16W
R3140 NRSA63J-681X MG RESISTOR 680Ø,1/16W
R3141 NRVA63D-821X CMF RESISTOR 820Ø,1/16W
R3142 NRSA63J-122X MG RESISTOR 1.2kØ,1/16W
R3143 NRSA63J-271X MG RESISTOR 270Ø,1/16W
R3161 NRSA63J-105X MG RESISTOR 1MØ,1/16W
R3162 NRSA63J-101X MG RESISTOR 100Ø,1/16W
R3163 NRSA63J-105X MG RESISTOR 1MØ,1/16W
R3164 NRSA63J-101X MG RESISTOR 100Ø,1/16W
R3165 NRSA63J-101X MG RESISTOR 100Ø,1/16W
R3501 NRSA63J-225X MG RESISTOR 2.2MØ,1/16W
R3502 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R3503 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R3504 NRSA63J-121X MG RESISTOR 120Ø,1/16W
R3506 NRSA63J-680X MG RESISTOR 68Ø,1/16W
R3508 NRSA63J-680X MG RESISTOR 68Ø,1/16W
R3510 NRSA63J-121X MG RESISTOR 120Ø,1/16W
R3512 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R3515 NRSA63J-680X MG RESISTOR 68Ø,1/16W
R3516 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R3521 NRSA63J-621X MG RESISTOR 620Ø,1/16W
R3522 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W
R3523 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R3524 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R3526 NRSA63J-681X MG RESISTOR 680Ø,1/16W
R3527 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W
R3528 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R3529 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R3533 NRSA63J-203X MG RESISTOR 20kØ,1/16W
R3534 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R3541 NRSA63J-680X MG RESISTOR 68Ø,1/16W
R3542 NRSA63J-680X MG RESISTOR 68Ø,1/16W
R3543 NRSA63J-680X MG RESISTOR 68Ø,1/16W
R3544 NRSA63J-680X MG RESISTOR 68Ø,1/16W
R3545 NRSA63J-680X MG RESISTOR 68Ø,1/16W
R3556 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R3701 NRSA63J-153X MG RESISTOR 15kØ,1/16W
R3702 NRSA63J-153X MG RESISTOR 15kØ,1/16W
R3703 NRSA63J-822X MG RESISTOR 8.2kØ,1/16W
R3704 NRSA63J-822X MG RESISTOR 8.2kØ,1/16W
R3709 NRSA63J-100X MG RESISTOR 10Ø,1/16W
R3711 NRSA63J-302X MG RESISTOR 3kØ,1/16W
R3712 NRSA63J-302X MG RESISTOR 3kØ,1/16W
R3713 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R3714 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R3716 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R3717 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R3719 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R3720 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R3721 NRSA63J-221X MG RESISTOR 220Ø,1/16W
R3722 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W
R3723 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R3726 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R3727 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W
R3728 NRSA63J-221X MG RESISTOR 220Ø,1/16W
R3740 NRSA63J-221X MG RESISTOR 220Ø,1/16W
R4001 NRSA63J-471X MG RESISTOR 470Ø,1/16W
R4002 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R4003 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R4004 NRSA63J-241X MG RESISTOR 240Ø,1/16W
R4005 NRSA63J-241X MG RESISTOR 240Ø,1/16W
R4006 NRSA63J-241X MG RESISTOR 240Ø,1/16W
R4007 NRSA63J-241X MG RESISTOR 240Ø,1/16W
R4008 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R4009 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W
R4010 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R4021 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
RA1505 NRZ0040-102X NET RESISTOR
RA1506 NRZ0040-102X NET RESISTOR
RA1507 NRZ0040-102X NET RESISTOR
RA1508 NRZ0040-102X NET RESISTOR
RA1509 NRZ0040-102X NET RESISTOR
RA1510 NRZ0040-473X NET RESISTOR
C1001 NEA70JM-107X E CAPACITOR 100µF,6.3V
C1002 NCB31CK-104X CAPACITOR 0.1µF,16V
C1003 NEA70JM-107X E CAPACITOR 100µF,6.3V
C1004 NCB31CK-104X CAPACITOR 0.1µF,16V
C1005 NEA70JM-107X E CAPACITOR 100µF,6.3V
C1006 NCB31CK-104X CAPACITOR 0.1µF,16V
C1007 NCF21CZ-105X CAPACITOR 1µF,16V
C1008 NCF21CZ-105X CAPACITOR 1µF,16V
C1009 NCF21CZ-105X CAPACITOR 1µF,16V
C1010 NCB31CK-104X CAPACITOR 0.1µF,16V
C1011 NCB31CK-104X CAPACITOR 0.1µF,16V
C1012 NCF21CZ-105X CAPACITOR 1µF,16V
C1014 NBE21AM-106X T CAPACITOR 10µF,10V
C1015 NCF21CZ-105X CAPACITOR 1µF,16V
C1016 NCF21CZ-105X CAPACITOR 1µF,16V
C1017 NCB31EK-103X CAPACITOR 0.01µF,25V
C1018 NCF21CZ-105X CAPACITOR 1µF,16V
C1019 NCB31EK-103X CAPACITOR 0.01µF,25V
C1020 NCF21CZ-105X CAPACITOR 1µF,16V
C1021 NBE21AM-106X T CAPACITOR 10µF,10V
C1022 NCF21CZ-105X CAPACITOR 1µF,16V
C1023 NCB31EK-103X CAPACITOR 0.01µF,25V
C1024 NCF21CZ-105X CAPACITOR 1µF,16V
C1025 NBE21AM-106X T CAPACITOR 10µF,10V
C1026 NCF21CZ-105X CAPACITOR 1µF,16V
C1027 NCB31EK-103X CAPACITOR 0.01µF,25V
C1028 NCB31EK-103X CAPACITOR 0.01µF,25V
