JVC SR-VS30E Service Manual

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
5-26
C3132 NCB31CK-104X CAPACITOR 0.1µF,16V
C3140 NCB31CK-104X CAPACITOR 0.1µF,16V
C3141 NCB31CK-104X CAPACITOR 0.1µF,16V
C3142 NDC31HJ-120X CAPACITOR 12pF,50V
C3143 NDC31HJ-120X CAPACITOR 12pF,50V
C3144 NCB31CK-104X CAPACITOR 0.1µF,16V
C3501 NCB31CK-104X CAPACITOR 0.1µF,16V
C3502 NCB31CK-104X CAPACITOR 0.1µF,16V
C3503 NCB31CK-104X CAPACITOR 0.1µF,16V
C3504 NEA70JM-226X E CAPACITOR 22µF,6.3V
C3505 NEA70JM-107X E CAPACITOR 100µF,6.3V
C3506 NEA70JM-226X E CAPACITOR 22µF,6.3V
C3507 NDC31HJ-220X CAPACITOR 22pF,50V
C3508 NDC31HJ-220X CAPACITOR 22pF,50V
C3509 NDC31HJ-220X CAPACITOR 22pF,50V
C3510 NCB31CK-104X CAPACITOR 0.1µF,16V
C3511 NCB31CK-104X CAPACITOR 0.1µF,16V
C3513 NCB31CK-104X CAPACITOR 0.1µF,16V
C3514 NCB31CK-104X CAPACITOR 0.1µF,16V
C3515 NEA70JM-226X E CAPACITOR 22µF,6.3V
C3516 NEA70JM-226X E CAPACITOR 22µF,6.3V
C3517 NEA70JM-107X E CAPACITOR 100µF,6.3V
C3521 NEA70JM-107X E CAPACITOR 100µF,6.3V
C3523 NEA70JM-226X E CAPACITOR 22µF,6.3V
C3531 NDC31HJ-120X CAPACITOR 12pF,50V
C3532 NDC31HJ-150X CAPACITOR 15pF,50V
C3533 NDC31HJ-470X CAPACITOR 47pF,50V
C3534 NDC31HJ-390X CAPACITOR 39pF,50V
C3535 NCB31CK-104X CAPACITOR 0.1µF,16V
C3536 NDC31HJ-120X CAPACITOR 12pF,50V
C3537 NDC31HJ-150X CAPACITOR 15pF,50V
C3538 NDC31HJ-470X CAPACITOR 47pF,50V
C3539 NDC31HJ-390X CAPACITOR 39pF,50V
C3540 NCB31CK-104X CAPACITOR 0.1µF,16V
C3701 NCF21CZ-105X CAPACITOR 1µF,16V
C3702 NCF21CZ-105X CAPACITOR 1µF,16V
C3703 NCB31CK-104X CAPACITOR 0.1µF,16V
C3704 NEA71CM-106X E CAPACITOR 10µF,16V
C3705 NDC31HJ-151X CAPACITOR 150pF,50V
C3706 NCB31CK-104X CAPACITOR 0.1µF,16V
C3707 NCB31CK-104X CAPACITOR 0.1µF,16V
C3708 NDC31HJ-151X CAPACITOR 150pF,50V
C3709 NEA71CM-106X E CAPACITOR 10µF,16V
C3710 NCB31CK-104X CAPACITOR 0.1µF,16V
C3711 NEA71CM-106X E CAPACITOR 10µF,16V
C3712 NEA71CM-106X E CAPACITOR 10µF,16V
C3713 NCB31CK-104X CAPACITOR 0.1µF,16V
C3714 NEA71CM-106X E CAPACITOR 10µF,16V
C3715 NCB31CK-104X CAPACITOR 0.1µF,16V
C3716 NCB31CK-104X CAPACITOR 0.1µF,16V
C3717 NEA71CM-106X E CAPACITOR 10µF,16V
C3718 NEA71CM-106X E CAPACITOR 10µF,16V
C3725 NCB31HK-332X CAPACITOR 0.0033µF,50V
C3726 NCB31HK-682X CAPACITOR 0.0068µF,50V
C3728 NCB31CK-104X CAPACITOR 0.1µF,16V
C3729 NEA71CM-476X E CAPACITOR 47µF,16V
C3730 NEA71CM-476X E CAPACITOR 47µF,16V
C3731 NCB31CK-104X CAPACITOR 0.1µF,16V
C3733 NCB31HK-332X CAPACITOR 0.0033µF,50V
C3734 NCB31HK-682X CAPACITOR 0.0068µF,50V
C4001 NCB31CK-104X CAPACITOR 0.1µF,16V
C4002 NCB31CK-104X CAPACITOR 0.1µF,16V
C4003 NEA70JM-226X E CAPACITOR 22µF,6.3V
C4005 NCB31CK-104X CAPACITOR 0.1µF,16V
C4006 NCB31CK-104X CAPACITOR 0.1µF,16V
C4007 NEA70JM-226X E CAPACITOR 22µF,6.3V
C4009 NCB31CK-104X CAPACITOR 0.1µF,16V
C4010 NCB31CK-104X CAPACITOR 0.1µF,16V
C4011 NEA70JM-226X E CAPACITOR 22µF,6.3V
C4013 NCB31CK-104X CAPACITOR 0.1µF,16V
C4014 NCB31CK-104X CAPACITOR 0.1µF,16V
C4015 NEA70JM-226X E CAPACITOR 22µF,6.3V
C4021 NCB31CK-104X CAPACITOR 0.1µF,16V
C4022 NCB31CK-473X CAPACITOR 0.047µF,16V
C4023 NCB31CK-104X CAPACITOR 0.1µF,16V
C4024 NCB31CK-223X CAPACITOR 0.022µF,16V
C4025 NCB31CK-104X CAPACITOR 0.1µF,16V
C4026 NCB31CK-104X CAPACITOR 0.1µF,16V
C4027 NCB31CK-104X CAPACITOR 0.1µF,16V
C4028 NCB31CK-473X CAPACITOR 0.047µF,16V
C4029 NCB31CK-473X CAPACITOR 0.047µF,16V
C4030 NCB31CK-473X CAPACITOR 0.047µF,16V
C4031 NCB31CK-104X CAPACITOR 0.1µF,16V
C4032 NDC31HJ-221X CAPACITOR 220pF,50V
C4033 NCB31CK-104X CAPACITOR 0.1µF,16V
C4034 NDC31HJ-102X CAPACITOR 0.001µF,50V
C4035 NCB31CK-104X CAPACITOR 0.1µF,16V
C4036 NCB31CK-104X CAPACITOR 0.1µF,16V
C4038 NCB20JM-475X CAPACITOR 4.7µF,6.3V
C4039 NCB31CK-104X CAPACITOR 0.1µF,16V
C4040 NCB31CK-104X CAPACITOR 0.1µF,16V
C4041 NCB20JM-475X CAPACITOR 4.7µF,6.3V
C4046 NCB31CK-104X CAPACITOR 0.1µF,16V
C4047 NCB31CK-104X CAPACITOR 0.1µF,16V
L1001 NQL144K-100X COIL 10µH
L1002 NQL17CM-390X COIL 39µH
L1003 NQL17CM-390X COIL 39µH
L1004 NQL17CM-390X COIL 39µH
L1501 NQL144K-100X COIL 10µH
L1502 NQL144K-100X COIL 10µH
L2001 NQL144K-100X COIL 10µH
L2002 NQL144K-100X COIL 10µH
L2003 NQL144K-100X COIL 10µH
L2004 NQL144K-100X COIL 10µH
L2005 NQL144K-100X COIL 10µH
L2006 NQL144K-100X COIL 10µH
L2007 NQL144K-100X COIL 10µH
L2009 NQL024J-2R2X COIL 2.2µH
L2010 NQL024J-100X COIL 10µH
L2011 NQL024J-120X COIL 12µH
L2015 NQR0337-001X COIL
L3001 NQL144K-100X COIL 10µH
L3021 NQL144K-100X COIL 10µH
L3022 NQL144K-100X COIL 10µH
L3101 NQL144K-100X COIL 10µH
L3103 NQL144K-100X COIL 10µH
L3104 NQL144K-100X COIL 10µH
L3111 NQL024J-150X COIL 15µH
L3112 NQL024J-150X COIL 15µH
L3131 NQL024J-150X COIL 15µH
L3132 NQL024J-150X COIL 15µH
L3151 NQL144K-100X COIL 10µH
