39
7 Center unit (XV-THC30/XV-THC20)
Audio section
Total Harmonic Distortion: 0.02 %
NOTE: This value is measured at System cord CONNECTOR for
reference.
Digital input*
1
:
DIGITAL IN (DBS): –21 dBm to –15 dBm
(OPTICAL) (660 nm E30 nm)
*
1
Corresponding to Linear PCM, Dolby Digital, and DTS Digital
Surround (with sampling frequency — 32 kHz, 44.1 kHz,
48 kHz)
Video section
Video System: NTSC
Horizontal Resolution: 500 lines
Signal-to-Noise Ratio: 64 dB
Video output level
Composite: 1.0 V(p-p)/75 Ω
S-video-Y: 1.0 V(p-p)/75 Ω
S-video-C: 0.286 V(p-p)/75 Ω
Component-Y: 1.0 V(p-p)/75 Ω
Component-P
B/PR: 0.7 V(p-p)/75 Ω
Video input sensitivity/Impedance (VCR IN)
Composite: 1.0 V(p-p)/75 Ω
S-video-Y: 1.0 V(p-p)/75 Ω
S-video-C: 0.286 V(p-p)/75 Ω
USB storage
USB specification: Compatible with the USB 2.0 Full-
Speed
Compatible device: Mass Storage Class
Compatible file system: FAT16, FAT32
Bus power supply: Max. 500 mA
Tuner section
Tuning Range
FM: 87.5 MHz to 108.0 MHz
AM: 530 kHz to 1 710 kHz
General
Power Requirements: AC 120 V , 60 Hz
Power Consumption: 25 W (at operation)
0.6 W (in standby mode)
Dimensions (W M H M D):
400 mm M 85 mm M 316 mm
Mass: 3.8 kg
7 Subwoofer (SP-PWC30)
Amplifier section
Front/Center/Surround: 167 W per channel, RMS at 3 Ω at
1 kHz, with 10 % total harmonic
distortion.
Subwoofer: 167 W, RMS at 3 Ω at 100 Hz, with
10 % total harmonic distortion.
Speaker section
Speaker unit: 16 cm Bass-reflex
Power Handling Capacity: 170 W
Impedance: 3 Ω
Frequency Range: 30 Hz to 200 Hz
Sound Pressure Level: 73 dB/
W·m
General
Power Requirements: AC 120 V , 60 Hz
Power Consumption: 160 W (at operation)
0 W (in standby mode)
Dimensions (W M H M D):
170 mm M 411 mm M 458 mm
Mass: 11.5 kg
7 Subwoofer (SP-PWC20)
Amplifier section
Front/Center/Surround: 135 W per channel, RMS at 4 Ω at
1 kHz, with 10 % total harmonic
distortion.
Subwoofer: 135 W, RMS at 4 Ω at 100 Hz, with
10 % total harmonic distortion.
Speaker section
Speaker unit: 16 cm Bass-reflex
Power Handling Capacity: 140 W
Impedance: 4 Ω
Frequency Range: 30 Hz to 200 Hz
Sound Pressure Level: 74 dB/
W·m
General
Power Requirements: AC 120 V , 60 Hz
Power Consumption: 135 W (at operation)
0 W (in standby mode)
Dimensions (W M H M D):
170 mm M 411 mm M 458 mm
Mass: 11.5 kg
Specifications
