Front board
Block No. [0][2]
Audio board
Block No. [0][3]
FC901 QNG0003-001Z FUSE CLIP
FC902 QNG0003-001Z FUSE CLIP
FW901 QUM219-06DGZ4-E PARA RIBON WIR
FW902 QUM21A-06DGZ4-E PARA RIBON WIR
HS901 GV40606-002A HEAT SINK
J4401 QNN0570-001 PIN JACK
J4402 QNN0572-001 PIN JACK
J4891 QNS0089-001 3.5 JACK
J6001 QNS0170-001 HEADPHONE JACK
K902 QQR0621-001Z COIL
K4702 QQR0621-001Z COIL
K6001 NQR0007-002X FERRITE BEADS
K6002 NQR0007-002X FERRITE BEADS
K6003 NQR0007-002X FERRITE BEADS
K6004 NQR0007-002X FERRITE BEADS
 P901 QNC0082-001 AC INLET
SP471 VYH7653-001 IC HOLDER
X4701 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
IC501 PT6315 IC
IC511 GP1UM271XKVF IR DETECT UNIT
Q503 KRC102S-X DIGI TRANSISTOR
D511 SLR-343VC/NPQ-T LED
D551 SELU2E10C-P LED
C506 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C507 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C511 NCB21CK-105X C CAPACITOR 1uF 16V K
C515 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C541 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C542 NCB31HK-103X C CAPACITOR 0.01uF 50V K
R501 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R502 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R503 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R505 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R506 NRSA63J-330X MG RESISTOR 33 Ω 1/16W J
R511 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R521 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R522 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R526 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R527 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R528 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R531 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R532 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R533 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R534 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R536 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R537 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R538 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R539 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R541 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R542 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R552 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
BK501 LV43659-001A FL HOLDER
BK502 LV43659-001A FL HOLDER
CN501 QGF1205F1-13 CONNECTOR FFC/FPC (1-13)
DI501 QLF0154-001 FL TUBE
FW502 QUM216-09Z4Z4-E PARA RIBON WIR
FW521 QUM213-15DGZ4-E PARA RIBON WIRE
FW561 QUM214-16DGZ4-E PARA RIBON WIRE
JS541 QSW1122-001 JOG VOLUME
K501 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K502 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
S521 QSW0825-001Z TACT SW
S522 QSW0825-001Z TACT SW
 Symbol No. Part No. Part Name Description Local
S523 QSW0825-001Z TACT SW
S526 QSW0825-001Z TACT SW
S527 QSW0825-001Z TACT SW
S528 QSW0825-001Z TACT SW
S529 QSW0825-001Z TACT SW
S531 QSW0825-001Z TACT SW
S532 QSW0825-001Z TACT SW
S533 QSW0825-001Z TACT SW
S534 QSW0825-001Z TACT SW
S535 QSW0825-001Z TACT SW
S536 QSW0825-001Z TACT SW
S537 QSW0825-001Z TACT SW
S538 QSW0825-001Z TACT SW
S539 QSW0825-001Z TACT SW
S540 QSW0825-001Z TACT SW
 Symbol No. Part No. Part Name Description Local
IC151 CD4066BM-X IC
IC152 CD4066BM-X IC
IC153 BD3814FV-X IC
IC154 CD4066BM-X IC
IC158 RC4558D-X IC
IC159 RC4558D-X IC
IC160 RC4558D-X IC
IC509 GP1FAV30RK0F OPT RECEIVER
IC531 RC4558D-X IC
IC581 RC4558D-X IC
IC591 RC4558D-X IC
Q1131 IMX9-W TRANSISTOR
Q1133 IMX9-W TRANSISTOR
Q1135 IMX9-W TRANSISTOR
Q1137 2SC3661-X TRANSISTOR
Q1251 KRA104S-X DIGI TRANSISTOR
Q1252 KRA104S-X DIGI TRANSISTOR
C1001 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1002 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1003 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1101 NCB31HK-331X C CAPACITOR 330pF 50V K
C1102 NCB31HK-331X C CAPACITOR 330pF 50V K
C1103 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1120 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C1121 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C1122 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C1123 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C1124 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1125 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1141 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1142 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1145 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1176 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1177 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1178 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1179 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1180 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1181 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1183 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1201 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1202 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1203 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1204 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1205 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1206 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1207 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1208 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1209 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1210 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1211 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1212 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
 Symbol No. Part No. Part Name Description Local
