JVC TH-C5 Service Manual

3-16
Mother board
Block No. [0][4]
R2582 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2583 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2584 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R2585 NRSA63J-622X MG RESISTOR 6.2k Ω 1/16W J
R2586 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R2587 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2588 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2590 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R2592 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R2594 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R2596 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2599 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
CN441 QGF1036C1-31 CONNECTOR FFC/FPC (1-31)
CN442 QGF1036C1-07 CONNECTOR FFC/FPC (1-7)
J1101 QNN0598-001 PIN JACK
J1103 QND0118-001 DIN CONNECTOR
K1101 NQR0007-002X FERRITE BEADS
 Symbol No. Part No. Part Name Description Local
 IC201 STK413-430 IC
 IC202 STK413-430 IC
IC301 RC4558D-X IC
IC302 RC4558D-X IC
IC303 RC4558D-X IC
IC601 MN101C427NB IC
Q152 KTC2026/Y/ TRANSISTOR
Q501 KRA104S-X DIGI TRANSISTOR
Q502 KTC3875/YG/-X SI TRANSISTOR
Q503 KTC3875/YG/-X SI TRANSISTOR
Q504 KTA1504/YG/-X SI TRANSISTOR
Q505 KRC109S-X TRANSISTOR
Q517 KRC104S-X TRANSISTOR
Q523 KTC3875/YG/-X SI TRANSISTOR
Q524 KTA1504/YG/-X SI TRANSISTOR
Q525 KTC3875/YG/-X SI TRANSISTOR
Q542 KTC3875/YG/-X SI TRANSISTOR
Q603 KTC3875/YG/-X SI TRANSISTOR
Q604 KTC3265/Y/-X TRANSISTOR
Q2101 KTA1504/YG/-X SI TRANSISTOR
Q2201 KTA1504/YG/-X SI TRANSISTOR
Q2301 KTA1504/YG/-X SI TRANSISTOR
Q2401 KTA1504/YG/-X SI TRANSISTOR
Q2501 KTA1504/YG/-X SI TRANSISTOR
Q2601 KTA1504/YG/-X SI TRANSISTOR
Q2701 KTC3875/YG/-X SI TRANSISTOR
Q2702 KTA1046/Y/ TRANSISTOR
Q2703 KRC102S-X DIGI TRANSISTOR
Q2707 KTA1267/YG/-T TRANSISTOR
Q2708 KTC3199/GL/-T TRANSISTOR
Q3101 KTC3875/YG/-X SI TRANSISTOR
Q3102 KTC3875/YG/-X SI TRANSISTOR
Q3201 KTC3875/YG/-X SI TRANSISTOR
Q3202 KTC3875/YG/-X SI TRANSISTOR
Q3301 KTC3875/YG/-X SI TRANSISTOR
Q3302 KTC3875/YG/-X SI TRANSISTOR
Q3401 KTC3875/YG/-X SI TRANSISTOR
Q3402 KTC3875/YG/-X SI TRANSISTOR
Q3501 KTC3875/YG/-X SI TRANSISTOR
Q3502 KTC3875/YG/-X SI TRANSISTOR
Q3701 KRA102S-X DIGI TRANSISTOR
Q3702 KRA102S-X DIGI TRANSISTOR
Q3703 KRC103S-X DIGITAL TR
Q3704 KTC2026/Y/ TRANSISTOR
Q3705 KTC3875/YG/-X SI TRANSISTOR
Q3706 KRC104S-X TRANSISTOR
D101 1SS355-X SI DIODE
 D151 GBU803 BRIDGE DIODE
 Symbol No. Part No. Part Name Description Local
 D152 GBU803 BRIDGE DIODE
D154 1SS133-T2 SI DIODE
D163 1SS133-T2 SI DIODE
D164 MTZJ6.2B-T2 Z DIODE
D165 MTZJ6.8C-T2 Z DIODE
D166 MTZJ6.8C-T2 Z DIODE
D501 1SS133-T2 SI DIODE
D504 1SS133-T2 SI DIODE
D505 UDZS5.1B-X Z DIODE
D506 1SS133-T2 SI DIODE
D507 1SS355-X SI DIODE
D510 1SS133-T2 SI DIODE
D514 1SS133-T2 SI DIODE
D515 1SS133-T2 SI DIODE
D516 MTZJ30C-T2 Z DIODE
D521 MTZJ6.8C-T2 Z DIODE
D535 1SS355-X SI DIODE
D541 1SS133-T2 SI DIODE
D542 1SS133-T2 SI DIODE
D543 1SS133-T2 SI DIODE
D545 1SS133-T2 SI DIODE
D546 1SS133-T2 SI DIODE
D548 1SS133-T2 SI DIODE
D549 1SS133-T2 SI DIODE
D550 1SS133-T2 SI DIODE
D551 1SS133-T2 SI DIODE
D552 1SS133-T2 SI DIODE
D553 1SS133-T2 SI DIODE
D562 SLR-342MC-T12 LED
D601 1SS133-T2 SI DIODE
D610 1SS133-T2 SI DIODE
D611 1SS133-T2 SI DIODE
D612 1SS133-T2 SI DIODE
D2101 1SS133-T2 SI DIODE
D2201 1SS133-T2 SI DIODE
D2301 1SS133-T2 SI DIODE
D2401 1SS133-T2 SI DIODE
D2501 1SS133-T2 SI DIODE
D2601 1SS133-T2 SI DIODE
D2701 MTZJ15C-T2 Z DIODE
D2702 MTZJ15C-T2 Z DIODE
D2703 MTZJ16C-T2 Z DIODE
D2704 1SS133-T2 SI DIODE
D2705 1SS133-T2 SI DIODE
D3101 1SS133-T2 SI DIODE
D3102 1SS133-T2 SI DIODE
D3201 1SS133-T2 SI DIODE
D3202 1SS133-T2 SI DIODE
D3301 1SS133-T2 SI DIODE
D3302 1SS133-T2 SI DIODE
D3401 1SS133-T2 SI DIODE
D3402 1SS133-T2 SI DIODE
D3501 1SS133-T2 SI DIODE
D3502 1SS133-T2 SI DIODE
D3601 1SS133-T2 SI DIODE
D3602 1SS133-T2 SI DIODE
D3703 MTZJ11C-T2 Z DIODE
D3706 1SS133-T2 SI DIODE
D3707 1SS133-T2 SI DIODE
D3708 1SS133-T2 SI DIODE
 C101 QCZ9105-472 C CAPACITOR 4700pF 250V M
C153 NCF21HZ-473X C CAPACITOR 0.047uF 50V Z
C154 NCF21HZ-473X C CAPACITOR 0.047uF 50V Z
C155 NCF21HZ-473X C CAPACITOR 0.047uF 50V Z
C156 NCF21HZ-473X C CAPACITOR 0.047uF 50V Z
C157 NCF21HZ-223X C CAPACITOR 0.022uF 50V Z
C159 NCF21HZ-223X C CAPACITOR 0.022uF 50V Z
C161 QEZ0736-478 E CAPACITER 4700uF
C162 QEZ0736-478 E CAPACITER 4700uF
C163 QETM1EM-478 E CAPACITOR 4700uF 25V M
C164 QETM1EM-478 E CAPACITOR 4700uF 25V M
C167 QETN1EM-476Z E CAPACITOR 47uF 25V M
C168 QETN1CM-107Z E CAPACITOR 100uF 16V M
C171 QETN1CM-107Z E CAPACITOR 100uF 16V M
C172 QETN1CM-107Z E CAPACITOR 100uF 16V M
C501 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C502 NCF31HZ-103X C CAPACITOR 0.01uF 50V Z
 Symbol No. Part No. Part Name Description Local
