DVD loading board
Block No. [0][7]
R726 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R727 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R728 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R730 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R732 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R741 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R742 NRSA63J-5R1X MG RESISTOR 5.1
Ω 1/16W J
R799 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R811 NRS125J-330X MG RESISTOR 33 Ω 1/2W J
R812 NRS125J-330X MG RESISTOR 33 Ω 1/2W J
R813 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R814 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R819 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R821 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R822 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R823 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R851 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R855 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R856 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R857 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R858 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R859 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R860 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R861 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
CN101 QGF0523F3-24W CONNECTOR FFC/FPC (1-24)
CN201 QGF1016F8-08W CONNECTOR FFC/FPC (1-8)
CN451 QGF1016F8-15W CONNECTOR FFC/FPC (1-15)
CN452 QGA2001F6-02X CONNECTOR W-B (1-2)
CN453 QGA2001F6-03X CONNECTOR W-B (1-3)
CN701 QGF1016C6-28W CONNECTOR FFC/FPC (1-28)
CN702 QGF1016C6-18W CONNECTOR FFC/FPC (1-18)
CN801 QGF1016C6-05W CONNECTOR FFC/FPC (1-5)
CN811 QGA2001F6-05X CONNECTOR W-B (1-5)
K101 NQR0502-001X FERRITE BEADS
K351 NQR0502-001X FERRITE BEADS
K352 NQR0502-001X FERRITE BEADS
K353 NQR0502-001X FERRITE BEADS
K354 NQR0022-002X FERRITE BEADS
K454 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K455 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K456 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K501 NQR0502-001X FERRITE BEADS
K701 NQR0022-002X FERRITE BEADS
K702 NQR0022-002X FERRITE BEADS
K703 NQR0022-002X FERRITE BEADS
K704 NQR0022-002X FERRITE BEADS
K705 NQR0022-002X FERRITE BEADS
K706 NQR0022-005X FERRITE BEADS
K707 NQR0022-002X FERRITE BEADS
K708 NQR0022-002X FERRITE BEADS
K709 NQR0022-002X FERRITE BEADS
K710 NQR0022-002X FERRITE BEADS
K711 NQR0022-002X FERRITE BEADS
K720 NQR0022-002X FERRITE BEADS
K721 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K722 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K726 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K810 NQR0502-001X FERRITE BEADS
K811 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K812 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
TH301 NAD0025-103X N THERMISTOR 10k Ω
X301 NAX0741-001X CRYSTAL
X302 NAX0376-002X CRYSTAL
X451 NAX0248-001X C OSCILLATOR
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
IC1 LB1641 IC
IC2 LB1641 IC
D1 MTZJ6.2A-T2 Z DIODE
C1 QEKC1CM-107Z E CAPACITOR 100uF 16V M
C2 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C3 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C5 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C6 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C7 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
CN1 QGF1036F2-15 CONNECTOR FFC/FPC (1-15)
CN2 QGB2024K1-07S CONNECTOR B-B (1-7)
CN3 QGB2024J1-07S CONNECTOR B-B (1-7)
SW1 QSW0844-002 PUSH SWITCH
SW2 QSW0844-002 PUSH SWITCH
SW3 QSW0844-002 PUSH SWITCH
SW4 QSW0844-002 PUSH SWITCH
SW5 QSW0844-002 PUSH SWITCH
SW6 QSW0854-002 PUSH SW
SW7 QSW0886-002 DETECT SWITCH
SW8 QSW0923-001 DETECT SWITCH
