SCHEMATIC DIAGRAMS
TH-C90A,TH-C90US,TH-C90UX,TH-C90UG
TH-C60US,TH-C60UP,TH-C60UW
TH-C60UX,TH-C60UY,TH-C60UG
Contents
Block diagrams
Standard schematic diagrams
Printed circuit boards
2-1
2-3
2-18 to 22
CD-ROM No.SML200609
DVD DIGITAL CINEMA SYSTEM
No.MB570SCH
2006/9
COPYRIGHT 2006 Victor Company of Japan, Limited.
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
XV-THC90
SP-PWC90
SP-THC90F SP-THC90F
SP-THC90C
SP-THC90S SP-THC90S
XV-THC60
SP-PWC60
SP-THC60F SP-THC60F
SP-THC60C
SP-THC60S
