3-16
Audio board
Block No. [0][2]
R4763 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
C60US,
C60UP,
C60UW,
C60UX,
C60UY,
C60UG
R4771 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4772 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R4773 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
C90A,
C90US,
C90UX,
C90UG
R4774 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
C60UP,
C60UW
R4775 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R4776 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R4777 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R4778 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R4791 NRSA02J-221X MG RESISTOR 220 Ω 1/10W J
 R4811 QRZ9006-4R7X FUSI RESISTOR 4.7 Ω
R4821 QRE141J-181Y C RESISTOR 180 Ω 1/4W J
R4822 QRE141J-151Y C RESISTOR 150
Ω 1/4W J
R4823 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R4824 QRE141J-151Y C RESISTOR 150
Ω 1/4W J
R4825 QRE141J-151Y C RESISTOR 150
Ω 1/4W J
R4826 QRE141J-151Y C RESISTOR 150 Ω 1/4W J
R4827 QRE141J-151Y C RESISTOR 150 Ω 1/4W J
R4831 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R4833 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R4834 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R4835 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4841 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R4843 QRT017J-2R2 MF RESISTOR 2.2 Ω 1W J
 R4844 QRL02DJ-121X OMF RESISTOR 120 Ω 2W J
R4846 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4847 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
C90US,
C90UX,
C90UG,
C60US,
C60UX,
C60UG
R4848 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
C90A,
C60UP,
C60UW,
C60UY
R4849 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4851 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R4861 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R4863 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R4864 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R4866 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R4871 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R4872 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R4873 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R4875 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R4876 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R4881 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R4882 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R4883 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4884 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R4886 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R4893 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
 R4921 QRZ9005-100X FUSI RESISTOR 10 Ω
R4961 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
 L901 QQR0908-001 LINE FILTER
L951 QQL244K-R22Z COIL 0.22uH K
L955 QQL31AK-220Z COIL 22uH K
L957 QQL26AK-100Z COIL 10uH K
L972 QQL31AK-220Z COIL 22uH K
L4391 QQL25CK-221Z COIL 220uH K
 T901 QQS0371-001 SW TRANSF
CN402 QGF1036C2-28 CONNECTOR FFC/FPC (1-28)
CN403 QGF1036C2-18 CONNECTOR FFC/FPC (1-18)
CN404 QGF1036C2-05 CONNECTOR FFC/FPC (1-5)
CN406 QGF1205C2-05 CONNECTOR FFC/FPC (1-5)
CN410 QGF1205C2-11 CONNECTOR FFC/FPC (1-11)
CN411 QGF1036C2-25 CONNECTOR FFC/FPC (1-25)
CN413 QGB2501J1-06 CONNECTOR B-B (1-6)
 Symbol No. Part No. Part Name Description Local
CN450 QGF1036C2-17 CONNECTOR FFC/FPC (1-17)
CN451 QGF1205C2-07 CONNECTOR FFC/FPC (1-7)
CN455 QGF1205C2-07 CONNECTOR FFC/FPC (1-7)
C90US,
C90UX,
C90UG,
C60US,
C60UX,
C60UG
CN457 QGD2504C1-03Z CONNECTOR (1-3)
 CP951 ICP-N10-T IC PROTECTOR 400mA
 CP999 ICP-N20-T IC PROTECTOR 800mA
EP401 QNZ0870-001 EARTH PLATE
EP901 QNZ0870-001 EARTH PLATE
EP903 QNZ0870-001 EARTH PLATE
FC901 QNG0003-001Z FUSE CLIP
FC902 QNG0003-001Z FUSE CLIP
FW521 QUM213-08DGZ4-E PARA RIBON WIRE
HS901 LV40057-002A HEAT SINK
J4401 QNN0570-001 PIN JACK
J4402 QNN0572-001 PIN JACK
K901 QQR1769-001 FERRITE CORE
K4702 QQR0621-001Z COIL
 P901 QNC0081-001 AC INLET
PP401 QZW0112-001 WIRE CLAMP
PP402 QZW0112-001 WIRE CLAMP
PP403 QZW0112-001 WIRE CLAMP
PP404 QZW0112-001 WIRE CLAMP
S522 QSW1120-001Z PUSH SW
S523 QSW1120-001Z PUSH SW
S526 QSW1120-001Z PUSH SW
S527 QSW1120-001Z PUSH SW
S528 QSW1120-001Z PUSH SW
S529 QSW1120-001Z PUSH SW
X4701 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
IC101 R2S15902FP IC
IC111 RC4580ID-X IC
IC112 RC4580ID-X IC
IC113 RC4580ID-X IC
IC121 RC4580ID-X IC
IC131 RC4580ID-X IC
IC501 PT6315 IC
IC511 GP1UM261XKVF IR DETECT UNIT
IC701 RC4580ID-X IC
C90US,C90UX,
C90UG,C60US,
C60UX,C60UG
IC761 BU9253FS-X IC
C90US,C90UX,
C90UG,C60US,
C60UX,C60UG
Q1101 2SA1530A/QR/-X TRANSISTOR
Q1102 RT1N141C-X DIGI TRANSISTOR
Q1121 IMX9-W TRANSISTOR
Q1122 IMX9-W TRANSISTOR
Q1123 IMX9-W TRANSISTOR
Q1131 RT1N141C-X DIGI TRANSISTOR
Q1132 2SA1530A/QR/-X TRANSISTOR
Q1133 IMX9-W TRANSISTOR
Q2921 KTC3203/OY/-T TRANSISTOR
Q7301 RT1N141C-X DIGI TRANSISTOR
C90US,C90UX,
C90UG,C60US,
C60UX,C60UG
Q7302 2SA1037AK/RS/-X TRANSISTOR
C90US,C90UX,
C90UG,C60US,
C60UX,C60UG
Q7401 2SC2412K/R/-X TRANSISTOR
C90US,C90UX,
C90UG,C60US,
C60UX,C60UG
Q7402 2SC2412K/R/-X TRANSISTOR
C90US,C90UX,
C90UG,C60US,
C60UX,C60UG
 Symbol No. Part No. Part Name Description Local
