Mother board (TH-C90)
Block No. [0][3]
J7002 QNS0266-001 JACK
C90US,C90UX,
C90UG,C60US,
C60UX,C60UG
JS541 QSW1059-001 JOG VOLUME
K6001 NQR0007-002X FERRITE BEADS
K6002 NQR0007-002X FERRITE BEADS
K6003 NQR0007-002X FERRITE BEADS
K6004 NQR0007-002X FERRITE BEADS
K6101 NQR0502-001X FERRITE BEADS
K6102 NQR0022-002X FERRITE BEADS
K6103 NQR0022-002X FERRITE BEADS
K6104 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K7001 NQR0007-002X FERRITE BEADS
C90US,C90UX,
C90UG,C60US,
C60UX,C60UG
S521 QSW1120-001Z PUSH SW
S531 QSW0522-002Z PUSH SW I.M
S532 QSW0522-002Z PUSH SW I.M
S533 QSW0522-002Z PUSH SW I.M
S534 QSW0522-002Z PUSH SW I.M
S535 QSW0522-002Z PUSH SW I.M
S536 QSW0522-002Z PUSH SW I.M
S537 QSW0522-002Z PUSH SW I.M
S538 QSW0522-002Z PUSH SW I.M
S539 QSW0522-002Z PUSH SW I.M
S540 QSW0522-002Z PUSH SW I.M
 Symbol No. Part No. Part Name Description Local
IC251 RC4558D-X IC
IC301 IRS20124S-X IC
IC302 IRS20124S-X IC
IC303 IRS20124S-X IC
IC304 IRS20124S-X IC
IC305 IRS20124S-X IC
IC306 IRS20124S-X IC
IC307 IRS20124S-X IC
IC601 MN101C427NY IC
IC701 SN74HC00ANS-X IC
IC702 NJM2403M-X IC
IC703 IRS2011S-X IC
IC704 SN74HC74ANS-X IC
IC705 NJM2125F-X IC
Q151 KTC2026/Y/ TRANSISTOR
Q152 KTA1046/Y/ TRANSISTOR
Q153 KTC3203/OY/-T TRANSISTOR
Q156 KRC104S-X TRANSISTOR
Q157 KTC3875/YG/-X TRANSISTOR
Q501 KRA109S-X D.TRANSISTOR
Q502 KTC3875/YG/-X TRANSISTOR
Q503 KTC3875/YG/-X TRANSISTOR
Q504 KTA1504/YG/-X TRANSISTOR
Q505 KRC102S-X DIGI TRANSISTOR
Q511 KTC3875/YG/-X TRANSISTOR
Q521 KTC3875/YG/-X TRANSISTOR
Q522 KTC3265/Y/-X TRANSISTOR
Q523 KTC3875/YG/-X TRANSISTOR
Q524 KTA1504/YG/-X TRANSISTOR
Q525 KTC3875/YG/-X TRANSISTOR
Q531 KRC103S-X DIGITAL TR
Q532 KRA102S-X DIGI TRANSISTOR
Q533 KTC2026/Y/ TRANSISTOR
Q534 KTC3875/YG/-X TRANSISTOR
Q535 KRC104S-X TRANSISTOR
Q601 KRA102S-X DIGI TRANSISTOR
Q602 KTC3875/YG/-X TRANSISTOR
Q603 KTC3875/YG/-X TRANSISTOR
Q701 KTA1268/GL/-T TRANSISTOR
Q702 KTA1504/YG/-X TRANSISTOR
Q703 KRC102S-X DIGI TRANSISTOR
Q704 2SK3599-01MR POWER MOS FET
 Symbol No. Part No. Part Name Description Local
Q705 KTA1504/YG/-X TRANSISTOR
Q706 KTC2028/Y/ TRANSISTOR
Q708 KTC2028/Y/ TRANSISTOR
Q710 KRC102S-X DIGI TRANSISTOR
Q711 KRC102S-X DIGI TRANSISTOR
Q712 KRC102S-X DIGI TRANSISTOR
Q713 2SK3599-01MR POWER MOS FET
Q722 KRC102S-X DIGI TRANSISTOR
Q726 KRC102S-X DIGI TRANSISTOR
Q731 KTC3875/YG/-X TRANSISTOR
Q2501 KTC3875/YG/-X TRANSISTOR
Q2502 KTC3875/YG/-X TRANSISTOR
Q2701 KTC3875/YG/-X TRANSISTOR
Q3101 IRFB4212 FET
Q3102 IRFB4212 FET
Q3201 IRFB4212 FET
Q3202 IRFB4212 FET
Q3301 IRFB4212 FET
Q3302 IRFB4212 FET
Q3401 IRFB4212 FET
Q3402 IRFB4212 FET
Q3501 IRFB4212 FET
Q3502 IRFB4212 FET
Q3601 IRFB4212 FET
Q3602 IRFB4212 FET
Q3701 IRFB4212 FET
Q3702 IRFB4212 FET
Q3801 KTA1504/YG/-X TRANSISTOR
Q3802 KTC3875/YG/-X TRANSISTOR
Q3803 KTA1504/YG/-X TRANSISTOR
Q4001 KTA1023/OY/-T TRANSISTOR
Q4002 KTC3875/YG/-X TRANSISTOR
Q4003 KTC3875/YG/-X TRANSISTOR
D101 1SS133-T2 SI DIODE
D102 1SS133-T2 SI DIODE
 D151 GBU803 BRIDGE DIODE
 D152 10EDB20-T4 DIODE
 D153 10EDB20-T4 DIODE
D154 1SS133-T2 SI DIODE
D155 1SS133-T2 SI DIODE
D156 1SS133-T2 SI DIODE
D161 MTZJ8.2C-T2 Z DIODE
D162 1SS133-T2 SI DIODE
D163 MTZJ6.2B-T2 Z DIODE
D164 1SS133-T2 SI DIODE
D165 MTZJ8.2C-T2 Z DIODE
D166 1SS133-T2 SI DIODE
D501 1SS133-T2 SI DIODE
D502 MTZJ8.2C-T2 Z DIODE
D503 MTZJ6.8C-T2 Z DIODE
D504 1SS133-T2 SI DIODE
D505 MTZJ5.1C-T2 Z DIODE
D506 1SS133-T2 SI DIODE
D507 1SS133-T2 SI DIODE
D508 1SS133-T2 SI DIODE
D509 MTZJ20B-T2 Z DIODE
D511 1SS133-T2 SI DIODE
D512 1SS133-T2 SI DIODE
D513 1SS133-T2 SI DIODE
D514 1SS133-T2 SI DIODE
D515 1SS133-T2 SI DIODE
D516 1SS133-T2 SI DIODE
D517 1SS133-T2 SI DIODE
D518 1SS133-T2 SI DIODE
D519 1SS133-T2 SI DIODE
D523 1SS133-T2 SI DIODE
D524 1SS133-T2 SI DIODE
D525 1SS133-T2 SI DIODE
D526 1SS133-T2 SI DIODE
D531 1SS133-T2 SI DIODE
D541 MTZJ11C-T2 Z DIODE
D542 1SS133-T2 SI DIODE
D543 MA700A-T2 SB DIODE
D544 1SS133-T2 SI DIODE
D610 1SS133-T2 SI DIODE
D611 1SS133-T2 SI DIODE
D701 1SS133-T2 SI DIODE
 Symbol No. Part No. Part Name Description Local
