JVC TH-C90A User Manual

3-25
Amplifier board (TH-C90)
Block No. [0][4]
WC310 QZW0112-001 WIRE CLAMP
WC351 QZW0112-001 WIRE CLAMP
X601 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
IC101 JCV8015-X IC
IC102 JCV8015-X IC
IC103 JCV8015-X IC
IC202 SN74HCU04ANS-X IC
IC203 RC4558D-X IC
Q1101 KTA1504/YG/-X TRANSISTOR
Q1111 KTC3875/YG/-X TRANSISTOR
Q1112 KTC3875/YG/-X TRANSISTOR
Q1201 KTA1504/YG/-X TRANSISTOR
Q1211 KTC3875/YG/-X TRANSISTOR
Q1212 KTC3875/YG/-X TRANSISTOR
Q1301 KTA1504/YG/-X TRANSISTOR
Q1311 KTC3875/YG/-X TRANSISTOR
Q1312 KTC3875/YG/-X TRANSISTOR
Q1401 KTA1504/YG/-X TRANSISTOR
Q1411 KTC3875/YG/-X TRANSISTOR
Q1412 KTC3875/YG/-X TRANSISTOR
Q1501 KTA1504/YG/-X TRANSISTOR
Q1601 KTA1504/YG/-X TRANSISTOR
Q1701 KTA1504/YG/-X TRANSISTOR
Q2003 KRC102S-X DIGI TRANSISTOR
Q2004 KRA102S-X DIGI TRANSISTOR
Q2005 KTA1504/YG/-X TRANSISTOR
Q2007 KTC3875/YG/-X TRANSISTOR
Q2008 KRC102S-X DIGI TRANSISTOR
D561 SLR-342MC-T12 LED
D1111 1SS133-T2 SI DIODE
D1112 1SS133-T2 SI DIODE
D1211 1SS133-T2 SI DIODE
D1212 1SS133-T2 SI DIODE
D1311 1SS133-T2 SI DIODE
D1312 1SS133-T2 SI DIODE
D1411 1SS133-T2 SI DIODE
D1412 1SS133-T2 SI DIODE
D2021 1SS133-T2 SI DIODE
D2022 1SS133-T2 SI DIODE
D2023 1SS133-T2 SI DIODE
D2025 MTZJ3.3B-T2 Z DIODE
D2031 1SS133-T2 SI DIODE
D2032 1SS133-T2 SI DIODE
C1101 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1102 NCB31HK-221X C CAPACITOR 220pF 50V K
C1103 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1104 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1105 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1106 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1107 NDC31HJ-101X C CAPACITOR 100pF 50V J
C1111 NCB31HK-152X C CAPACITOR 1500pF 50V K
C1112 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1113 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C1122 NCB31HK-272X C CAPACITOR 2700pF 50V K
C1131 NDC31HJ-680X C CAPACITOR 68pF 50V J
C1141 NCB31CK-105X C CAPACITOR 1uF 16V K
C1142 NDC31HG-101X C CAPACITOR 100pF 50V G
C1143 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C1201 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1202 NCB31HK-221X C CAPACITOR 220pF 50V K
C1203 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1204 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1205 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1206 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1207 NDC31HJ-101X C CAPACITOR 100pF 50V J
 Symbol No. Part No. Part Name Description Local
C1211 NCB31HK-152X C CAPACITOR 1500pF 50V K
C1212 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1213 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C1222 NCB31HK-272X C CAPACITOR 2700pF 50V K
C1231 NDC31HJ-680X C CAPACITOR 68pF 50V J
C1241 NCB31CK-105X C CAPACITOR 1uF 16V K
C1242 NDC31HG-101X C CAPACITOR 100pF 50V G
C1243 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C1301 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C1302 NCB31HK-221X C CAPACITOR 220pF 50V K
C1303 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1304 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1305 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1307 NDC31HJ-101X C CAPACITOR 100pF 50V J
C1311 NCB31HK-152X C CAPACITOR 1500pF 50V K
C1312 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1313 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C1322 NCB31HK-272X C CAPACITOR 2700pF 50V K
C1331 NDC31HJ-680X C CAPACITOR 68pF 50V J
C1341 NCB31CK-105X C CAPACITOR 1uF 16V K
C1342 NDC31HG-101X C CAPACITOR 100pF 50V G
C1343 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C1401 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C1402 NCB31HK-221X C CAPACITOR 220pF 50V K
C1403 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1404 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1405 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1407 NDC31HJ-101X C CAPACITOR 100pF 50V J
C1411 NCB31HK-152X C CAPACITOR 1500pF 50V K
C1412 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1413 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C1422 NCB31HK-272X C CAPACITOR 2700pF 50V K
C1431 NDC31HJ-680X C CAPACITOR 68pF 50V J
C1441 NCB31CK-105X C CAPACITOR 1uF 16V K
C1442 NCS31HJ-101X C CAPACITOR 100pF 50V J
C1443 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C1501 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1502 NCB31HK-221X C CAPACITOR 220pF 50V K
C1503 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1504 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1505 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1507 NDC31HJ-101X C CAPACITOR 100pF 50V J
C1511 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C1512 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C1513 NCB21HK-563X C CAPACITOR 0.056uF 50V K
C1514 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1522 NCB31HK-272X C CAPACITOR 2700pF 50V K
C1531 NDC31HJ-680X C CAPACITOR 68pF 50V J
C1541 NCB31CK-105X C CAPACITOR 1uF 16V K
C1542 NDC31HG-101X C CAPACITOR 100pF 50V G
C1543 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C1601 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1603 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1604 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1605 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1607 NDC31HJ-101X C CAPACITOR 100pF 50V J
C1622 NCB31HK-272X C CAPACITOR 2700pF 50V K
C1631 NCB31HK-821X C CAPACITOR 820pF 50V K
C1641 NCB31CK-105X C CAPACITOR 1uF 16V K
C1642 NDC31HG-101X C CAPACITOR 100pF 50V G
C1643 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C1801 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1802 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1803 NCB31CK-105X C CAPACITOR 1uF 16V K
C1804 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1805 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1806 NCB31CK-105X C CAPACITOR 1uF 16V K
C1807 NCB31CK-105X C CAPACITOR 1uF 16V K
C1808 NCB31CK-105X C CAPACITOR 1uF 16V K
C1811 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1812 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1813 NCB31CK-105X C CAPACITOR 1uF 16V K
C1814 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1815 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1816 NCB31CK-105X C CAPACITOR 1uF 16V K
C1817 NCB31CK-105X C CAPACITOR 1uF 16V K
C1818 NCB31CK-105X C CAPACITOR 1uF 16V K
C1821 QETN1CM-107Z E CAPACITOR 100uF 16V M
 Symbol No. Part No. Part Name Description Local
