JVC TH-C90A User Manual

3-27
Mother board (TH-C60)
Block No. [0][5]
R1621 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R1624 NRSA63J-224X MG RESISTOR 220k Ω 1/16W J
R1626 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R1631 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R1632 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R1641 NRSA63F-562X MG RESISTOR 5.6k
Ω 1/16W F
R1642 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R1647 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R1747 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R2001 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R2002 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R2021 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2022 NRSA63J-184X MG RESISTOR 180k Ω 1/16W J
R2023 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R2024 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R2025 NRSA63J-184X MG RESISTOR 180k Ω 1/16W J
R2027 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R2028 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R2029 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
R2031 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R2032 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R2033 NRSA63J-220X MG RESISTOR 22
Ω 1/16W J
R2034 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R2035 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R2036 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2037 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R2038 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R2103 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
CN111 QGB2024J1-17S CONNECTOR B-B (1-17)
CN112 QGB2024J1-17S CONNECTOR B-B (1-17)
J1001 QND0118-001 DIN CONNECTOR
WR501 QUM213-22DGZ4-E PARA RIBON WIRE
X2001 QAX0734-001 C RESONATOR 400.00kHz
 Symbol No. Part No. Part Name Description Local
 IC201 STK413-430 IC
 IC202 STK413-400 IC
IC301 RC4558D-X IC
IC302 RC4558D-X IC
IC303 RC4558D-X IC
IC601 MN101C427NB IC
Q152 KTC2026/Y/ TRANSISTOR
Q501 RT1P441C-X DIGI TRANSISTOR
Q502 2SC3928A/QR/-X TRANSISTOR
Q503 2SC3928A/QR/-X TRANSISTOR
Q504 2SA1530A/QR/-X TRANSISTOR
Q505 RT1N44HC-X DIGI TRANSISTOR
Q517 RT1N431C-X TRANSISTOR
Q523 2SC3928A/QR/-X TRANSISTOR
Q524 2SA1530A/QR/-X TRANSISTOR
Q525 2SC3928A/QR/-X TRANSISTOR
Q542 RT1N136C-X DIGI TRANSISTOR
Q603 2SC3928A/QR/-X TRANSISTOR
Q604 KTC3265/Y/-X TRANSISTOR
Q2101 2SA1530A/QR/-X TRANSISTOR
Q2201 2SA1530A/QR/-X TRANSISTOR
Q2301 2SA1530A/QR/-X TRANSISTOR
Q2401 2SA1530A/QR/-X TRANSISTOR
Q2501 2SA1530A/QR/-X TRANSISTOR
Q2601 2SA1530A/QR/-X TRANSISTOR
Q2701 2SC3928A/QR/-X TRANSISTOR
Q2702 KTA1046/Y/ TRANSISTOR
Q2703 RT1N141C-X DIGI TRANSISTOR
Q2707 KTA1267/YG/-T TRANSISTOR
Q2708 KTC3199/GL/-T TRANSISTOR
Q2709 KTC2026/Y/ TRANSISTOR
Q2710 2SA1530A/QR/-X TRANSISTOR
Q2711 RT1P141C-X DIGI TRANSISTOR
 Symbol No. Part No. Part Name Description Local
Q3702 RT1P141C-X DIGI TRANSISTOR
Q3703 RT1N241C-X DIGI TRANSISTOR
Q3704 KTC2026/Y/ TRANSISTOR
D101 1SS133-T2 SI DIODE
 D151 GBU803 BRIDGE DIODE
 D152 GBU803 BRIDGE DIODE
D154 1SS133-T2 SI DIODE
D163 1SS133-T2 SI DIODE
D164 MTZJ6.2B-T2 Z DIODE
D165 MTZJ6.8C-T2 Z DIODE
D166 MTZJ6.8C-T2 Z DIODE
D501 1SS133-T2 SI DIODE
D504 1SS133-T2 SI DIODE
D505 UDZS5.1B-X Z DIODE
D506 1SS133-T2 SI DIODE
D507 1SS355-X SI DIODE
D510 1SS133-T2 SI DIODE
D514 1SS133-T2 SI DIODE
D515 1SS133-T2 SI DIODE
D516 MTZJ30C-T2 Z DIODE
D521 MTZJ6.8C-T2 Z DIODE
D535 1SS133-T2 SI DIODE
D541 1SS133-T2 SI DIODE
D543 1SS133-T2 SI DIODE
D546 1SS133-T2 SI DIODE
D548 1SS133-T2 SI DIODE
D549 1SS133-T2 SI DIODE
D550 1SS133-T2 SI DIODE
D551 1SS133-T2 SI DIODE
D553 1SS133-T2 SI DIODE
D561 SLR-342MC-T12 LED
D611 1SS133-T2 SI DIODE
D612 1SS133-T2 SI DIODE
D2101 1SS133-T2 SI DIODE
D2201 1SS133-T2 SI DIODE
D2301 1SS133-T2 SI DIODE
D2401 1SS133-T2 SI DIODE
D2501 1SS133-T2 SI DIODE
D2601 1SS133-T2 SI DIODE
D2701 MTZJ15C-T2 Z DIODE
D2702 MTZJ15C-T2 Z DIODE
D2703 MTZJ16C-T2 Z DIODE
D2704 1SS133-T2 SI DIODE
D2705 1SS133-T2 SI DIODE
D2706 MTZJ22A-T2 Z DIODE
D3101 1SS133-T2 SI DIODE
D3102 1SS133-T2 SI DIODE
D3201 1SS133-T2 SI DIODE
D3202 1SS133-T2 SI DIODE
D3301 1SS133-T2 SI DIODE
D3302 1SS133-T2 SI DIODE
D3401 1SS133-T2 SI DIODE
D3402 1SS133-T2 SI DIODE
D3501 1SS133-T2 SI DIODE
D3502 1SS133-T2 SI DIODE
D3601 1SS133-T2 SI DIODE
D3602 1SS133-T2 SI DIODE
D3703 MTZJ15C-T2 Z DIODE
 C101 QCZ9105-472 C CAPACITOR 4700pF 250V M
C153 NCF21HZ-473X C CAPACITOR 0.047uF 50V Z
C154 NCF21HZ-473X C CAPACITOR 0.047uF 50V Z
C155 NCF21HZ-473X C CAPACITOR 0.047uF 50V Z
C156 NCF21HZ-473X C CAPACITOR 0.047uF 50V Z
C157 NCF21HZ-223X C CAPACITOR 0.022uF 50V Z
C159 NCF21HZ-223X C CAPACITOR 0.022uF 50V Z
C161 QETM1HM-338 E CAPACITOR 3300uF 50V M
C162 QETM1HM-338 E CAPACITOR 3300uF 50V M
C163 QETM1EM-478 E CAPACITOR 4700uF 25V M
C164 QETM1EM-478 E CAPACITOR 4700uF 25V M
C167 QETN1EM-476Z E CAPACITOR 47uF 25V M
C168 QETN1CM-107Z E CAPACITOR 100uF 16V M
C171 QETN1CM-107Z E CAPACITOR 100uF 16V M
C172 QETN1CM-107Z E CAPACITOR 100uF 16V M
C501 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C503 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C512 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
 Symbol No. Part No. Part Name Description Local
