34
Center unit (XV-THD51)
Output power
Front:
140 W per channel, RMS at 4 at 1 kHz, with 10% total
harmonic distortion.
Center:
130 W, RMS at 4 at 1 kHz, with 10% total harmonic
distortion.
Surround:
130 W per channel, RMS at 4 at 1 kHz, with 10% total
harmonic distortion.
Subwoofer:
140 W, RMS at 4 at 100 Hz, with 10% total harmonic
distortion.
Audio section
Digital Input*
DIGITAL IN
OPTICAL: –21 dBm to –15 dBm (660 nm
±30 nm)
Analog Input: AUDIO IN
Video section
Video System: PAL
Horizontal Resolution: 500 lines
Signal-to-Noise Ratio: 54 dB
(Composite signal when “RGB” is selected)
Video Output Level
(AV—Scart)
Composite video: 1.0 V(p-p)/75
Y: 1.0 V(p-p)/75
C: 0.3 V(p-p)/75
RGB: 0.7 V(p-p)/75
(VIDEO OUT)
Component (Y): 1.0 V(p-p)/75
(P
B/PR): 0.7 V(p-p)/75
Video Input Sensitivity/Impedance (VIDEO IN)
Composite: 1.0 V(p-p)/75
S-video (Y): 1.0 V(p-p)/75
(C): 0.3 V(p-p)/75
HDMI
HDMI Output (MONITOR OUT):
576p/720p/1080i
USB storage
USB Specification: Compatible with USB 2.0 Full
Speed
Compatible Device: Mass Storage Class
Compatible File System: FAT16, FAT32
Bus Power Supply: Max. 500 mA
Tuner section
Tuner Range
FM: 87.50 MHz to 108.00 MHz
AM (MW): 522 kHz to 1 629 kHz
General
Power Requirements: AC 230 V , 50 Hz
Power Consumption: 160 W (during operation)
1.0 W (in standby mode)
Dimensions (W
× H × D): 435 mm ×115 mm ×270 mm
Mass: 6.8 kg
*
Corresponding to Linear PCM, Dolby Digital, and DTS
(with sampling frequency — 32 kHz, 44.1 kHz, 48 kHz)
Subwoofer (SP-THD51W)
Type: Bass-Reflex Type
Speaker: 16 cm cone
× 1
Power Handling Capacity: 140 W
Impedance: 4
Frequency Range: 30 Hz to 200 Hz
Sound Pressure Level: 72 dB/W
m
Dimensions (W
× H × D): 214 mm × 296 mm × 329 mm
Mass: 4.9 kg
Specifications
TH-D51[B]EN.book Page 34 Friday, August 3, 2007 10:26 AM
