UX-A70MD
3-16
Item
Parts number Parts name Area
Remarks
A
D2907 MTZJ7.5C-T2 ZENER DIODE
D2910 MTZJ7.5C-T2 ZENER DIODE
D2911 MTZJ7.5C-T2 ZENER DIODE
D2913 QUY150-050Y BUS WIRE
D2914 QUY150-050Y BUS WIRE
D2915 QUY150-050Y BUS WIRE
D2916 QUY150-050Y BUS WIRE
D2917 QUY150-050Y BUS WIRE
D2918 QUY150-050Y BUS WIRE
FW907 QUM025-14DGZ3 FLAT WIRE TO FMB
IC801 LA4628 IC
A
IC802 NJM4580L IC
IC901 GP1U271X RM RECIVER
J1001 QNB0099-001 SPK TERMINAL
J1002 QNS0170-001 HEADPHONE JACK
J1003 QNC0006-001 AC SOCKET
K1001 QQR0621-001Z FERRITE BEADS
K1003 QQR0621-001Z FERRITE BEADS
K1004 QQR0621-001Z FERRITE BEADS
K1006 QQR0621-001Z FERRITE BEADS
K1007 QQR0621-001Z FERRITE BEADS
K1009 QQR0779-001Z INDUCTOR
K1010 QQR0779-001Z INDUCTOR
L1003 QQL231K-470Y INDUCTOR
L1004 QQL231K-470Y INDUCTOR
L1005 QQL231K-470Y INDUCTOR
L1006 QQR1145-001 LINE FILTER EMC FILTER
L1101 QQR0797-001 INDUCTOR
L1201 QQR0797-001 INDUCTOR
PP801 QZW0038-001 WIRE CLAMP
PP802 QZW0038-001 WIRE CLAMP
PP804 QZW0038-001 WIRE CLAMP
Q
1023 KRA101M-T TRANSISTOR
Q
1101 KTC3199/GL/-T TRANSISTOR
Q
1102 2SC3576-JVC-T TRANSISTOR
Q
1201 KTC3199/GL/-T TRANSISTOR
Q
1202 2SC3576-JVC-T TRANSISTOR
Q
1301 2SC2001/LK/-T TRANSISTOR
Q
1401 2SB562/BC/-T TRANSISTOR
Q
1402 KTC3199/GL/-T TRANSISTOR
Q
1501 KTB772/Y/ TRANSISTOR
A
Q
1502 2SC3576-JVC-T TRANSISTOR
Q
1601 KTB772/Y/ TRANSISTOR
A
Q
1602 2SA1175/FE/-T TRANSISTOR
Q
1603 DTC144TSA-T D.TRANSISTOR
Q
1604 DTA144TSA-T D.TRANSISTOR
Q
1605 KTC3199/GL/-T TRANSISTOR
Q
1606 KTC3199/GL/-T TRANSISTOR
Q
1607 DTC143TSA-T TRANSISTOR
Q
1701 DTA144WSA-T D.TRANSISTOR
Q
1702 DTA144WSA-T D.TRANSISTOR
Q
1703 DTA144WSA-T D.TRANSISTOR
Q
1704 DTA144WSA-T D.TRANSISTOR
Q
1705 DTC144WSA-T DIGI TRANSISTOR
Q
1801 KTB772/Y/ TRANSISTOR
A
Q
1802 KTC3199/GL/-T TRANSISTOR
Q
1803 KTC3199/GL/-T TRANSISTOR
Q
1901 KTA1046/Y/ TRANSISTOR
Q
1902 KTA1267/YG/-T TRANSISTOR
Q
1903 KRC114M-T TRANSISTOR
Q
1904 DTA144TSA-T D.TRANSISTOR
Q
1905 KTC3199/GL/-T TRANSISTOR
Q
1906 KTC3199/GL/-T TRANSISTOR
Q
1908 2SA1038S/SE/-T TRANSISTOR
Q
1909 2SA1038S/SE/-T TRANSISTOR
Q
1910 DTC144ESA-T D TRANSISTOR
Q
2601 DTC114ESA-T DIGITAL.TR TAPE
R1022 QRZ9006-4R7X F RESISTOR
A
4.7 1/0W
R1049 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1050 QRE141J-513Y C RESISTOR 51K 5% 1/4W
R1051 QRE141J-154Y C RESISTOR 150K 5% 1/4W
R1054 QRE141J-124Y C RESISTOR 120K 5% 1/4W
R1059 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R1060 QRE141J-101Y C RESISTOR 100 5% 1/4W
R1065 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R1066 QRE141J-224Y C RESISTOR 220K 5% 1/4W
R1077 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1086 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R1087 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R1090 QRE141J-151Y C RESISTOR 150 5% 1/4W
R1091 QRE141J-151Y C RESISTOR 150 5% 1/4W
R1101 QRE141J-182Y C RESISTOR 1.8K 5% 1/4W
R1102 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1103 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R1104 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R1105 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R1106 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1107 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R1108 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R1109 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1110 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1111 QRE141J-2R2Y C RESISTOR 2.2 5% 1/4W
R1112 QRE141J-2R2Y C RESISTOR 2.2 5% 1/4W
R1113 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1114 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1115 QRE141J-471Y C RESISTOR 470 5% 1/4W
R1201 QRE141J-182Y C RESISTOR 1.8K 5% 1/4W
R1202 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1203 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R1204 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R1205 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R1206 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1207 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R1208 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R1209 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1210 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1211 QRE141J-2R2Y C RESISTOR 2.2 5% 1/4W
R1212 QRE141J-2R2Y C RESISTOR 2.2 5% 1/4W
R1213 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1214 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1215 QRE141J-471Y C RESISTOR 470 5% 1/4W
R1301 QRE141J-561Y C RESISTOR 560 5% 1/4W
R1401 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R1402 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1403 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1404 QRZ9006-4R7X F RESISTOR
A
4.7 1/0W
R1501 QRE141J-101Y C RESISTOR 100 5% 1/4W
R1502 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1503 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1601 QRE141J-1R0Y C RESISTOR 1.0 5% 1/4W
R1602 QRE141J-1R0Y C RESISTOR 1.0 5% 1/4W
R1603 QRE141J-1R0Y C RESISTOR 1.0 5% 1/4W
R1604 QRE141J-391Y C RESISTOR 390 5% 1/4W
R1605 QRE141J-911Y C RESISTOR 910 5% 1/4W
R1606 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R1607 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
Electrical parts list (Main AMP. board)
Block No. 03
Item
Parts number Parts name Area
Remarks
A
