3-15
UX-A70MD
Item
Parts number Parts name Area
Remarks
A
CN801 QGB2510K2-13 CONNECTOR
CN802 QGB2510K2-13 CONNECTOR
CN803 QGA3901C1-04 4P CONNECTOR
CN804 QGA2501C1-05 5P CONNECTOR
CN805 QGA7901C1-04 CONNECTOR
UB,US,UT,UJ
CN805 QGA7901C1-02 CONNECTOR
UF
CN806 QGA2501C1-02 2P CONNECTOR
CN807 QGA2501C1-02 2P CONNECTOR
CN905 QGF1201F3-07 CONNECTOR
CN908 QGF1016F1-17 CONNECTOR TO CONN. BOARD
CN909 QGF1201C3-18 FFC/FPC CONNE FROM FMB
CN911 QGF1016C1-17 CONNECTOR FROM CONN.BOARD
CN912 QGB2024K1-17S CONNECTOR TO LCD
CN913 QGB2024J1-17S B TO B CONNE LED CONN.
C1001 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C1002 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C1003 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C1004 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C1007 QDGB1HK-103Y C CAPACITOR
C1008 QDGB1HK-102Y C CAPACITOR
C1009 QCZ0205-155Z ML C CAPACITOR 1.5MF
C1010 QETM1CM-478 E CAPACITOR
A
4700MF 20% 16V
C1014 QFLK1HJ-104Z TF CAPACITOR .10MF 5% 50V
C1015 QFLK1HJ-104Z TF CAPACITOR .10MF 5% 50V
C1016 QFLK1HJ-104Z TF CAPACITOR .10MF 5% 50V
C1017 QFLK1HJ-104Z TF CAPACITOR .10MF 5% 50V
C1018 QEZ0512-828 E CAPACITOR
A
8200MF
C1026 EETC1HM-105ZJC E CAPACITOR
C1027 EETC1HM-106ZJC E CAPACITOR
C1032 EETC1EM-476ZJC E CAPACITOR
C1033 EETC1EM-476ZJC E CAPACITOR
C1042 EETC1HM-106ZJC E CAPACITOR
C1043 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C1046 QETN1HM-336Z E CAPACITOR 33MF 20% 50V
C1047 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C1052 EETC1HM-105ZJC E CAPACITOR
C1053 EETC1HM-105ZJC E CAPACITOR
C1054 QFLC1HJ-563Z TF CAPACITOR .056MF 5% 50V
C1055 QFLC1HJ-563Z TF CAPACITOR .056MF 5% 50V
C1056 QFLK1HJ-104Z TF CAPACITOR .10MF 5% 50V
C1057 EETC1HM-225ZJC E CAPACITOR
C1058 QEKC1CM-107Z E CAPACITOR 100MF 20% 16V
C1090 QDYB1CM-103Y C CAPACITOR
C1101 QFVF1HJ-274Z MF CAPACITOR .27MF 5% 50V
C1102 QFVJ1HJ-823Z MF CAPACITOR .082MF 5% 50V
C1103 QFVJ1HJ-823Z MF CAPACITOR .082MF 5% 50V
C1104 QTE1C06-226Z E CAPACITOR
C1105 QTE1V06-106Z E CAPACITOR
C1106 QDGB1HK-102Y C CAPACITOR
C1107 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C1108 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C1109 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C1110 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C1111 QDXB1CM-332Y C CAPACITOR
C1201 QFVF1HJ-274Z MF CAPACITOR .27MF 5% 50V
C1202 QFVJ1HJ-823Z MF CAPACITOR .082MF 5% 50V
C1203 QFVJ1HJ-823Z MF CAPACITOR .082MF 5% 50V
C1204 QTE1C06-226Z E CAPACITOR
C1205 QTE1V06-106Z E CAPACITOR
C1206 QDGB1HK-102Y C CAPACITOR
C1207 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C1208 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C1209 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C1210 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C1211 QDXB1CM-332Y C CAPACITOR
C1301 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C1401 QER61EM-106Z E CAPACITOR 10MF 20% 25V
C1402 EETC1HM-226ZJC E CAPACITOR
C1501 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C1502 QTE1C06-226Z E CAPACITOR
C1503 QTE1C06-476Z E CAPACITOR
C1601 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C1602 QDYB1CM-103Y C CAPACITOR
C1603 EETC1CM-107ZJC E CAPACITOR
C1703 QDGB1HK-103Y C CAPACITOR
C1704 QDGB1HK-102Y C CAPACITOR
C1705 QDGB1HK-102Y C CAPACITOR
C1706 QENC1HM-106Z NP E CAPACITOR 10MF 20% 50V
C1707 QENC1HM-106Z NP E.CAPACITOR 10MF 20% 50V
C1709 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C1710 QCBB1HK-181Y C CAPACITOR 180PF 10% 50V
C1801 QDYB1CM-103Y C CAPACITOR
C1802 EETC1EM-476ZJC E CAPACITOR
C1803 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C1901 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C1902 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C1903 QDYB1CM-103Y C CAPACITOR
C1904 EETC1EM-476ZJC E CAPACITOR
C1905 QDYB1CM-103Y C CAPACITOR
C1907 EEKC1CM-106ZJC E CAPACITOR
C2901 QER41AM-107 E CAPACITOR 100MF 20% 10V
C2902 QDGB1HK-102Y C CAPACITOR
C2904 QCBB1HK-223Y C CAPACITOR .022MF 10% 50V
D1001 1N4003S-T5 SI DIODE
A
D1002 1N4003S-T5 SI DIODE
A
D1003 1N4003S-T5 SI DIODE
A
D1004 1N4003S-T5 SI DIODE
A
D1005 1N4003S-T5 SI DIODE
A
D1012 6A10E2 SI DIODE
A
D1013 6A10E2 SI DIODE
A
D1014 6A10E2 SI DIODE
A
D1015 6A10E2 SI DIODE
A
D1023 1SS133-T2 SI DIODE
D1024 1SS133-T2 SI DIODE
D1025 MTZJ4.3B-T2 ZENER DIODE
D1026 1SS133-T2 SI DIODE
D1027 1SS133-T2 SI DIODE
D1301 MTZJ11A-T2 Z.DIODE
D1401 MTZJ3.6B-T2 S.B.DIODE
D1402 MTZJ10A-T2 ZENER DIODE
D1501 MTZJ6.2C-T2 Z DIODE
D1601 1SS133-T2 SI DIODE
D1602 MTZJ5.6B-T2 ZENER DIODE
D1603 MTZJ18C-T2 Z.DIODE
D1604 MTZJ5.6C-T2 ZENER DIODE
D1702 1SS133-T2 SI DIODE
D1801 MTZJ7.5C-T2 ZENER DIODE
D1901 1SS133-T2 SI DIODE
D1902 MTZJ5.6C-T2 ZENER DIODE
D1903 MTZJ10A-T2 ZENER DIODE
D1904 1SS133-T2 SI DIODE
D2601 1SS133-T2 SI DIODE
D2602 SPR-39MVWF LED
D2902 MTZJ7.5C-T2 ZENER DIODE
D2903 MTZJ7.5C-T2 ZENER DIODE
D2906 MTZJ7.5C-T2 ZENER DIODE
Electrical parts list (Main AMP. board)
Block No. 03
Item
Parts number Parts name Area
Remarks
A
