UX-A70MD
3-14
Item
Parts number Parts name Area
Remarks
A
R2106 NRSA02J-153X MG RESISTOR
R2110 NRSA02J-122X MG RESISTOR
R2111 NRSA02J-682X MG RESISTOR
R2112 NRSA02J-222X MG RESISTOR
R2113 NRSA02J-123X MG RESISTOR
R2115 QRE141J-622Y C RESISTOR 6.2K 5% 1/4W
R2116 QRE141J-182Y C RESISTOR 1.8K 5% 1/4W
R2117 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R2118 NRSA02J-221X MG RESISTOR
R2119 NRSA02J-222X MG RESISTOR
R2120 NRSA02J-562X MG RESISTOR
R2122 QRE141J-622Y C RESISTOR 6.2K 5% 1/4W
R2123 NRSA02J-222X MG RESISTOR
R2201 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R2203 NRSA02J-203X MG RESISTOR
R2204 NRSA02J-393X MG RESISTOR
R2206 NRSA02J-153X MG RESISTOR
R2210 NRSA02J-122X MG RESISTOR
R2211 NRSA02J-682X MG RESISTOR
R2212 NRSA02J-222X MG RESISTOR
R2213 NRSA02J-123X MG RESISTOR
R2215 QRE141J-622Y C RESISTOR 6.2K 5% 1/4W
R2216 QRE141J-182Y C RESISTOR 1.8K 5% 1/4W
R2217 QRE141J-152Y C RESISTOR 1.5K 5% 1/4W
R2218 NRSA02J-221X MG RESISTOR
R2219 NRSA02J-222X MG RESISTOR
R2220 NRSA02J-562X MG RESISTOR
R2222 QRE141J-622Y C RESISTOR 6.2K 5% 1/4W
R2223 NRSA02J-222X MG RESISTOR
R2303 QRE141J-561Y C RESISTOR 560 5% 1/4W
R2304 QRE141J-331Y C RESISTOR 330 5% 1/4W
R2351 NRSA02J-390X MG RESISTOR
R2352 NRSA02J-222X MG RESISTOR
R2353 NRSA02J-333X MG RESISTOR
R2354 NRSA02J-101X MG RESISTOR
R2503 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R2504 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R2505 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R2701 NRSA02J-103X MG RESISTOR
R2702 NRSA02J-822X MG RESISTOR
R2703 NRSA02J-822X MG RESISTOR
R2704 NRSA02J-103X MG RESISTOR
R2705 NRSA02J-331X MG RESISTOR
R2706 NRSA02J-103X MG RESISTOR
R2707 NRSA02J-103X MG RESISTOR
R2708 NRSA02J-103X MG RESISTOR
R2709 NRSA02J-103X MG RESISTOR
R2710 NRSA02J-104X MG RESISTOR
R2711 NRSA02J-473X MG RESISTOR
R2712 NRSA02J-333X MG RESISTOR
R2713 NRSA02J-102X MG RESISTOR
R2714 NRSA02J-102X MG RESISTOR
R2715 NRSA02J-102X MG RESISTOR
R2716 NRSA02J-102X MG RESISTOR
R2717 NRSA02J-102X MG RESISTOR
R2718 NRSA02J-102X MG RESISTOR
R2719 NRSA02J-391X MG RESISTOR
R2720 NRSA02J-391X MG RESISTOR
R2721 NRSA02J-681X MG RESISTOR
R2722 NRSA02J-681X MG RESISTOR
R2723 NRSA02J-681X MG RESISTOR
R2724 NRSA02J-681X MG RESISTOR
R2725 NRSA02J-391X MG RESISTOR
R2726 NRSA02J-391X MG RESISTOR
R2727 NRSA02J-681X MG RESISTOR
R2728 NRSA02J-681X MG RESISTOR
R2729 NRSA02J-681X MG RESISTOR
R2730 NRSA02J-681X MG RESISTOR
R2731 NRSA02J-391X MG RESISTOR
R2732 NRSA02J-391X MG RESISTOR
R2733 NRSA02J-681X MG RESISTOR
R2734 NRSA02J-681X MG RESISTOR
R2735 NRSA02J-681X MG RESISTOR
R2736 NRSA02J-681X MG RESISTOR
R2740 NRSA02J-222X MG RESISTOR
R2741 NRSA02J-222X MG RESISTOR
R2742 NRSA02J-222X MG RESISTOR
R2743 NRSA02J-222X MG RESISTOR
R2744 NRSA02J-222X MG RESISTOR
R2745 NRSA02J-222X MG RESISTOR
R2852 QRE141J-100Y C RESISTOR 10 5% 1/4W
R2853 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R2854 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R2855 QRE141J-100Y C RESISTOR 10 5% 1/4W
R2856 QRE141J-9R1Y C RESISTOR 9.1 5% 1/4W
X2701 QAX0283-001Z CRYSTAL MAIN CLOCK
X2702 QAX0401-001 CRYSTAL SUB CLOCK
Electrical parts list (System control board)
Block No. 02
Item
Parts number Parts name Area
Remarks
A
