3-13
UX-A70MD
Item
Parts number Parts name Area
Remarks
A
K2301 QQR0621-001Z FERRITE BEADS
K2302 QQR0621-001Z FERRITE BEADS
K2303 QQR0621-001Z FERRITE BEADS
K2304 QQR0621-001Z FERRITE BEADS
K2305 QQR0621-001Z FERRITE BEADS
K2306 QQR0621-001Z FERRITE BEADS
LF711 QQR0590-001 FILTER
LF721 QQR0590-001 FILTER
L2001 QQL244K-100Z INDUCTOR
L2002 QQL244K-100Z INDUCTOR
L2101 QQL231K-4R7Y INDUCTOR
L2201 QQL231K-4R7Y INDUCTOR
L2302 QQL173K-470Z INDUCTOR
L2304 QQL231K-4R7Y INDUCTOR
L2305 QQL231K-4R7Y INDUCTOR
L2306 QQL231K-4R7Y INDUCTOR
Q
2103 2SC2412K/R/-X TRANSISTOR
Q
2104 2SC2412K/R/-X TRANSISTOR
Q
2203 2SC2412K/R/-X TRANSISTOR
Q
2204 2SC2412K/R/-X TRANSISTOR
Q
2301 2SC2001/LK/-T TRANSISTOR
Q
2351 2SA1037AK/R/-X TRANSISTOR
Q
2352 2SC2412K/R/-X TRANSISTOR
Q
2451 KRA101M-T D.TRANSISTOR
Q
2452 KRA101M-T D.TRANSISTOR
Q
2453 KRC102M-T D.TRANSISTOR
Q
2701 2SC2668/O/-T TRANSISTOR CLOCK SHIFT
Q
2702 2SC2668/O/-T TRANSISTOR CLOCK SHIFT
Q
2703 2SA1037AK/RS/-X TRANSISTOR SW5V
Q
2704 2SC2412K/R/-X TRANSISTOR RESET SW
Q
2705 2SC2412K/R/-X TRANSISTOR BACKUP CONT
Q
2706 2SC2412K/R/-X TRANSISTOR
Q
2707 2SC2412K/R/-X TRANSISTOR
Q
2708 2SC2412K/R/-X TRANSISTOR
Q
2709 2SC2412K/R/-X TRANSISTOR
Q
2710 2SC2412K/R/-X TRANSISTOR
Q
2711 2SC2412K/R/-X TRANSISTOR
Q
2712 2SC2412K/R/-X TRANSISTOR
Q
2713 2SC2412K/R/-X TRANSISTOR
Q
2714 2SC2412K/R/-X TRANSISTOR
Q
2715 2SC2412K/R/-X TRANSISTOR
Q
2716 2SC2412K/R/-X TRANSISTOR
Q
2717 2SC2412K/R/-X TRANSISTOR
Q
2853 KTC3199/GL/-T TRANSISTOR
R2002 NRSA02J-103X MG RESISTOR
R2003 NRSA02J-222X MG RESISTOR
R2004 NRSA02J-222X MG RESISTOR
R2005 NRSA02J-222X MG RESISTOR
R2006 NRSA02J-222X MG RESISTOR
R2007 NRSA02J-222X MG RESISTOR
R2008 NRSA02J-103X MG RESISTOR
R2009 NRSA02J-222X MG RESISTOR
R2010 NRSA02J-222X MG RESISTOR
R2011 NRSA02J-102X MG RESISTOR
R2012 NRSA02J-153X MG RESISTOR
R2014 NRSA02J-222X MG RESISTOR
R2015 NRSA02J-102X MG RESISTOR
R2016 NRSA02J-103X MG RESISTOR
R2017 NRSA02J-103X MG RESISTOR
R2018 NRSA02J-222X MG RESISTOR
R2019 NRSA02J-222X MG RESISTOR
R2020 NRSA02J-103X MG RESISTOR
R2021 NRSA02J-103X MG RESISTOR
R2022 NRSA02J-222X MG RESISTOR
R2023 NRSA02J-102X MG RESISTOR
R2024 NRSA02J-102X MG RESISTOR
R2025 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R2026 NRSA02J-222X MG RESISTOR
R2027 NRSA02J-102X MG RESISTOR
R2028 NRSA02J-103X MG RESISTOR
R2029 NRSA02J-102X MG RESISTOR
R2030 NRSA02J-104X MG RESISTOR
R2031 NRSA02J-104X MG RESISTOR
R2032 NRSA02J-102X MG RESISTOR
R2033 NRSA02J-222X MG RESISTOR
R2035 NRSA02J-222X MG RESISTOR
R2036 NRSA02J-222X MG RESISTOR
R2037 NRSA02J-222X MG RESISTOR
R2038 NRSA02J-102X MG RESISTOR
R2039 NRSA02J-223X MG RESISTOR
R2040 NRSA02J-472X MG RESISTOR
R2041 NRSA02J-222X MG RESISTOR
R2042 NRSA02J-222X MG RESISTOR
R2043 NRSA02J-222X MG RESISTOR
R2044 NRSA02J-222X MG RESISTOR
R2045 NRSA02J-103X MG RESISTOR
R2046 NRSA02J-222X MG RESISTOR
R2047 NRSA02J-103X MG RESISTOR
R2051 NRSA02J-222X MG RESISTOR
R2052 NRSA02J-222X MG RESISTOR
R2053 NRSA02J-102X MG RESISTOR
R2054 NRSA02J-102X MG RESISTOR
R2055 NRSA02J-102X MG RESISTOR
R2056 NRSA02J-102X MG RESISTOR
R2057 NRSA02J-222X MG RESISTOR
R2058 NRSA02J-222X MG RESISTOR
R2059 NRSA02J-103X MG RESISTOR
R2060 NRSA02J-222X MG RESISTOR
R2061 NRSA02J-222X MG RESISTOR
R2062 NRSA02J-102X MG RESISTOR
R2063 NRSA02J-102X MG RESISTOR
R2064 NRSA02J-102X MG RESISTOR
R2065 NRSA02J-102X MG RESISTOR
R2066 NRSA02J-102X MG RESISTOR
R2067 NRSA02J-222X MG RESISTOR
R2068 NRSA02J-103X MG RESISTOR
R2069 NRSA02J-103X MG RESISTOR
R2070 NRSA02J-103X MG RESISTOR
R2071 NRSA02J-103X MG RESISTOR
R2072 NRSA02J-222X MG RESISTOR
R2073 NRSA02J-222X MG RESISTOR
R2075 NRSA02J-222X MG RESISTOR
R2077 NRSA02J-222X MG RESISTOR
R2084 NRSA02J-103X MG RESISTOR
R2085 NRSA02J-473X MG RESISTOR
R2086 NRSA02J-473X MG RESISTOR
R2087 NRSA02J-473X MG RESISTOR
R2088 NRSA02J-104X MG RESISTOR
R2090 NRSA02J-222X MG RESISTOR
R2091 NRSA02J-473X MG RESISTOR
R2092 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R2093 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R2094 NRSA02J-222X MG RESISTOR
R2101 QRE141J-392Y C RESISTOR 3.9K 5% 1/4W
R2103 NRSA02J-203X MG RESISTOR
R2104 NRSA02J-393X MG RESISTOR
Electrical parts list (System control board)
Block No. 02
Item
Parts number Parts name Area
Remarks
A
