UX-A70MD
3-12
Item
Parts number Parts name Area
Remarks
A
Electrical parts list (System control board)
Block No. 02
Item
Parts number Parts name Area
Remarks
A
CN701 QGF1205C1-09 CONNECTOR TO TUNER
CN703 QGB1214K1-14S CONNECTOR TO CD MECHA
CN704 QGB1214K1-14S CONNECTOR TO CD MECHA
CN705 QGF1201C3-07 CONNECTOR TO FUNCTION KEY
CN706 QGA2501C1-02 2P CONNECTOR DIGITAL IN
CN707 QGD2504C1-05Z CONNER FR PANEL SENSOR
CN708 QGF1201C3-18 FFC/FPC CONNE TO LCD
CN711 QGB2510J1-13 CONNECTOR TO FMH
CN712 QGB2510J1-13 CONNECTOR TO FMH
CN721 QGF1016C1-21 CONNECTOR TO MD MECHA
C2001 NCB21HK-103X C CAPACITOR
C2002 NCB21HK-103X C CAPACITOR
C2003 NCS21HJ-101X C CAPACITOR
C2004 NCS21HJ-101X C CAPACITOR
C2005 NCB21HK-103X C CAPACITOR
C2006 NCS21HJ-101X C CAPACITOR
C2007 NCS21HJ-101X C CAPACITOR
C2008 NCS21HJ-470X C CAPACITOR
C2009 NCS21HJ-101X C CAPACITOR
C2010 NCS21HJ-101X C CAPACITOR
C2011 NCS21HJ-101X C CAPACITOR
C2015 EEKC1AM-476ZJC E CAPACITOR
C2017 EETC1CM-476ZJC E CAPACITOR
C2101 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C2102 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C2103 QFLM1HJ-272Z M CAPACITOR 2700PF 5% 50V
C2104 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2106 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2107 EETC1HM-475ZJC E CAPACITOR
C2108 EETC1HM-475ZJC E CAPACITOR
C2110 QTE1V06-106Z E CAPACITOR
C2112 NCS21HJ-221X C CAPACITOR
C2114 QFN31HJ-562Z M CAPACITOR 5600PF 5% 50V
C2115 EEKC1EM-106ZJC E CAPACITOR
C2116 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C2117 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C2118 QDGB1HK-102Y C CAPACITOR
C2119 QFLC1HJ-123Z M CAPACITOR .012MF 5% 50V
C2120 EETC1HM-475ZJC E CAPACITOR
C2121 NCS21HJ-221X C CAPACITOR
C2201 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C2202 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C2203 QFLM1HJ-272Z M CAPACITOR 2700PF 5% 50V
C2204 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2206 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2207 EETC1HM-475ZJC E CAPACITOR
C2208 EETC1HM-475ZJC E CAPACITOR
C2210 QTE1V06-106Z E CAPACITOR
C2212 NCS21HJ-221X C CAPACITOR
C2214 QFN31HJ-562Z M CAPACITOR 5600PF 5% 50V
C2215 EEKC1EM-106ZJC E CAPACITOR
C2216 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C2217 QCBB1HK-151Y C CAPACITOR 150PF 10% 50V
C2218 QDGB1HK-102Y C CAPACITOR
C2219 QFLC1HJ-123Z M CAPACITOR .012MF 5% 50V
C2220 EETC1HM-475ZJC E CAPACITOR
C2221 NCS21HJ-221X C CAPACITOR
C2305 QDGB1HK-102Y C CAPACITOR
C2306 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C2307 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C2308 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C2309 QDGB1HK-102Y C CAPACITOR
C2310 QDGB1HK-102Y C CAPACITOR
C2313 QDGB1HK-102Y C CAPACITOR
C2316 QDYB1CM-103Y C CAPACITOR
C2317 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V
C2318 QDVB1EZ-223Y C CAPACITOR
C2319 QDVB1EZ-223Y C CAPACITOR
C2322 QCFB1HZ-104Y C CAPACITOR .10MF +80:-20%
C2326 QDGB1HK-102Y C CAPACITOR
C2328 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C2351 QER61EM-475Z E CAPACITOR 4.7MF 20% 25V
C2352 QER61CM-107Z E CAPACITOR 100MF 20% 16V
C2451 QER41HM-105 E CAPACITOR 1.0MF 20% 50V
C2452 QER41HM-105 E CAPACITOR 1.0MF 20% 50V
C2453 NCB21HK-103X C CAPACITOR
C2501 QEKC1EM-106Z E CAPACITOR 10MF 20% 25V
C2502 QEK41CM-476 E CAPACITOR 47MF 20% 16V
C2701 NCB21HK-102X C CAPACITOR
C2702 NCB21HK-102X C CAPACITOR
C2703 NCS21HJ-470X C CAPACITOR
C2704 NCS21HJ-270X C CAPACITOR
C2705 NCS21HJ-330X C CAPACITOR
C2706 NCS21HJ-470X C CAPACITOR
C2707 NCB21HK-102X C CAPACITOR
C2708 EEKC1CM-107ZJC E CAPACITOR
C2709 NCB21HK-103X C CAPACITOR
C2710 NCS21HJ-220X C CAPACITOR
C2711 NCS21HJ-220X C CAPACITOR
C2712 QETM0JM-228 E CAPACITOR 2200MF 20% 6.3V
C2713 EEKC1HM-225ZJC E CAPACITOR
C2714 EEKC1HM-475ZJC E CAPACITOR
C2715 EETC1CM-107ZJC E CAPACITOR
C2716 QFVF1HJ-104Z MF CAPACITOR .10MF 5% 50V
C2751 EEKC1HM-105ZJC E CAPACITOR
C2752 EEKC1HM-105ZJC E CAPACITOR
C2753 EEKC1HM-105ZJC E CAPACITOR
C2852 QDYB1CM-103Y C CAPACITOR
C2853 EEKC1CM-107ZJC E CAPACITOR
C2855 QDYB1CM-103Y C CAPACITOR
D2001 1SS133-T2 SI DIODE
D2301 MTZJ6.2A-T2 Z.DIODE
D2351 MTZJ3.9B-T2 Z DIODE
D2352 1SS133-T2 SI DIODE
D2353 1SS133-T2 SI DIODE
D2451 1SS133-T2 SI DIODE
D2452 1SS133-T2 SI DIODE
D2453 MTZJ3.3B-T2 ZENER DIODE
D2456 MTZJ7.5C-T2 ZENER DIODE
D2701 1SS133-T2 SI DIODE US5V
D2702 1SS133-T2 SI DIODE
D2703 MTZJ5.1C-T2 ZENER DIODE
D2704 MTZJ8.2B-T2 DIODE
D2705 1SS133-T2 SI DIODE
D2706 1SS133-T2 SI DIODE
D2707 1SS133-T2 SI DIODE
D2708 1SS133-T2 SI DIODE
D2851 MTZJ5.1B-T2 ZENER DIODE
D2852 MTZJ6.8B-T2 ZENER DIODE
IC701 UPD784215AGF506 IC SYSTEM MICOM
IC702 LC75342 IC
IC703 LB1641 IC
IC704 KIA78S06P-T IC US6V REG
J2001 QNN0018-001 PIN JACK AUX I/O JACK
K2001 QQR0621-001Z FERRITE BEADS
K2002 QQR0621-001Z FERRITE BEADS
