3-11
UX-A70MD
Item
Parts number Parts name Area
Remarks
A
C 602 NCS21HJ-150X C CAPACITOR
C 604 QEKC1CM-107Z E CAPACITOR 100MF 20% 16V
C 605 QEKC1EM-106Z E CAPACITOR 10MF 20% 25V
C 606 NCB21HK-102X C CAPACITOR
C 607 NCB21HK-102X C CAPACITOR
C 608 QEKC1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 609 NCS21HJ-101X C CAPACITOR
C 610 NCB21HK-273X C CAPACITOR
C 611 NCB21HK-222X C CAPACITOR
C 612 NCB21HK-103X C CAPACITOR
C 613 NCS21HJ-331X C CAPACITOR
C 614 NCB21EK-104X C CAPACITOR
C 615 NCB21HK-223X C CAPACITOR
C 616 NCB21HK-223X C CAPACITOR
C 617 NCB21HK-223X C CAPACITOR
C 618 NCB21HK-222X C CAPACITOR
C 619 NCS21HJ-271X C CAPACITOR
C 620 NCS21HJ-181X C CAPACITOR
C 621 NCS21HJ-102X C CAPACITOR
C 622 QEK41CM-476 E CAPACITOR 47MF 20% 16V
C 623 NCB21EK-104X C CAPACITOR
C 625 NCS21HJ-470X C CAPACITOR
C 628 NCB21EK-473X C CAPACITOR
C 629 QEKC1CM-107Z E CAPACITOR 100MF 20% 16V
C 631 EETC1AM-477ZJC E CAPACITOR
C 632 QETC1AM-477Z E CAPACITOR 470MF 20% 10V
C 633 NCS21HJ-391X C CAPACITOR
C 634 NCS21HJ-391X C CAPACITOR
C 635 NCS21HJ-391X C CAPACITOR
C 636 NCS21HJ-391X C CAPACITOR
C 637 NCF21CZ-105X C CAPACITOR
C 641 NCB21HK-223X C CAPACITOR
C 642 NCB21HK-472X C CAPACITOR
C 643 QEQF1EM-475Z NP E CAPACITOR 4.7MF 20% 25V
C 644 NCB21HK-273X C CAPACITOR
C 645 QEQF1HM-105Z NP E CAPACITOR 1.0MF 20% 50V
C 651 NDC21HJ-120X C CAPACITOR
C 652 NDC21HJ-120X C CAPACITOR
C 653 NCB21HK-223X C CAPACITOR
C 655 NCB21EK-473X C CAPACITOR
C 661 NCS21HJ-471X C CAPACITOR
C 662 NCB21HK-223X C CAPACITOR
C 663 NCB21HK-223X C CAPACITOR
C 664 NCB21HK-223X C CAPACITOR
C 665 NCB21CK-104X C CAPACITOR
C 668 QEKC0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 669 NCB21HK-222X C CAPACITOR
C 671 NCB21HK-222X C CAPACITOR
C 672 NCB21HK-222X C CAPACITOR
C 673 QETC1AM-477Z E CAPACITOR 470MF 20% 10V
C 674 NCB21HK-223X C CAPACITOR
C 675 NCB21HK-102X C CAPACITOR
C 676 NCB21HK-102X C CAPACITOR
C 677 NCB21HK-223X C CAPACITOR
C 681 NCB21CK-104X C CAPACITOR
C 682 NCB21HK-103X C CAPACITOR
C 683 QEKC1CM-107Z E CAPACITOR 100MF 20% 16V
C 691 NCS21HJ-151X C CAPACITOR
C 692 NCS21HJ-151X C CAPACITOR
C 693 NCS21HJ-151X C CAPACITOR
C 694 NCS21HJ-101X C CAPACITOR
C 698 NCS21HJ-102X C CAPACITOR
CN601 QGF1023F1-15 15PIN CONNECTOR
Electrical parts list (CD servo board)
Block No. 01
Item
Parts number Parts name Area
Remarks
A
CN604 QGB1214J1-14S CONNECTOR
D 661 1SS254-T2 SI DIODE
D 681 MTZJ5.6B-T2 ZENER DIODE
IC601 AN8806SB-W IC
IC603 MN35510 IC
IC604 LB1641 IC
IC641 LA6541-X IC
L 681 QQL244K-100Z INDUCTOR
Q
601 2SA952/LK/-T TRANSISTOR
Q
602 DTC124EKA-X TRANSISTOR
Q
631 2SA952/LK/-T TRANSISTOR
R 601 NRSA02J-562X MG RESISTOR
R 603 NRSA02J-155X MG RESISTOR
R 605 NRSA02J-274X MG RESISTOR
R 606 NRSA02J-154X MG RESISTOR
R 607 NRSA02J-273X MG RESISTOR
R 608 NRSA02J-474X MG RESISTOR
R 609 NRSA02J-104X MG RESISTOR
R 610 NRSA02J-154X MG RESISTOR
R 612 NRSA02J-102X MG RESISTOR
R 613 NRSA02J-121X MG RESISTOR
R 614 NRSA02J-100X MG RESISTOR
R 615 NRSA02J-120X MG RESISTOR
R 616 NRSA02J-910X MG RESISTOR
R 621 NRSA02J-330X MG RESISTOR
R 622 NRSA02J-330X MG RESISTOR
R 623 NRSA02J-330X MG RESISTOR
R 627 NRSA02J-562X MG RESISTOR
R 628 NRSA02J-222X MG RESISTOR
R 629 NRSA02J-752X MG RESISTOR
R 632 NRSA02J-473X MG RESISTOR
R 634 NRSA02J-472X MG RESISTOR
R 635 NRSA02J-155X MG RESISTOR
R 641 NRSA02J-224X MG RESISTOR
R 642 NRSA02J-912X MG RESISTOR
R 643 NRSA02J-133X MG RESISTOR
R 644 NRSA02J-243X MG RESISTOR
R 645 NRSA02J-273X MG RESISTOR
R 646 NRSA02J-242X MG RESISTOR
R 647 NRSA02J-182X MG RESISTOR
R 648 NRSA02J-332X MG RESISTOR
R 649 NRSA02J-821X MG RESISTOR
R 650 NRSA02J-122X MG RESISTOR
R 651 NRSA02J-102X MG RESISTOR
R 652 NRSA02J-102X MG RESISTOR
R 653 NRSA02J-102X MG RESISTOR
R 654 NRSA02J-102X MG RESISTOR
R 656 NRSA02J-102X MG RESISTOR
R 659 NRSA02J-271X MG RESISTOR
R 660 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 661 NRSA02J-104X MG RESISTOR
R 662 NRSA02J-155X MG RESISTOR
R 663 NRSA02J-124X MG RESISTOR
R 664 NRSA02J-471X MG RESISTOR
R 665 NRSA02J-683X MG RESISTOR
R 666 NRSA02J-220X MG RESISTOR
R 668 NRSA02J-220X MG RESISTOR
R 671 NRSA02J-102X MG RESISTOR
R 672 NRSA02J-102X MG RESISTOR
R 682 NRSA02J-220X MG RESISTOR
R 683 NRSA02J-220X MG RESISTOR
W 605 QJP002-022200 WIRE
W 606 QJB001-051800 WIRE
X 651 QAX0599-001Z CRYSTAL
CN602 QGA2001F1-06 6P PLUG ASSY
CN603 QGB1214J1-14S CONNECTOR
