UX-A70MD
3-10
Item Parts number Parts name Area
A
Parts list (MD mechanism)
Q'ty Description
Block No. M4MM
49 WJT0042-001A E-CARD WIRE 1
50 LV41477-001A MINI TAP SCREW 1 T.MECHA PWB
51 LV40761-003A INSULATOR 4
52 QAH0039-002 MD HEAD 1
53 QYSPSPT1740N MINI SCREW 1 MD HEAD
54 LV31487-002A HEAD LIFTER 1
55 LV41349-001A H.LIFTER SPRING 1
56 LV10284-002A SINGLE FRAME 1
57 LV10285-003A MECHA COVER 1
58 LV41477-001A MINI TAP SCREW 4 MECHA COVER
59 LV30225-068A SPACER 1
60 VKZ4539-024 MINI SCREW 2 SERVO PWB
61 LV30225-096A SPACER 1
To Next Page
