JVC UX-G5 Service Manual

3-12
CD board
Block No. [0][5]
R281 BIRC2200105A00 C RESISTOR 22 Ω 1/10W
R282 BIRC2200105A00 C RESISTOR 22
Ω 1/10W
R283 BIRC1030105A00 C RESISTOR 10K
Ω 1/10W
R284 BIRC1030105A00 C RESISTOR 10K
Ω 1/10W
R285 BIRC4710105A00 C RESISTOR 470
Ω 1/10W
R286 BIRC4740105A00 C RESISTOR 470K
Ω 1/10W
R287 BIRC1000085M00 C RESISTOR 10
Ω 1/8W
R289 BIRC2220105A00 C RESISTOR 2.2K
Ω 1/10W
R290 BIRC1030105A00 C RESISTOR 10K
Ω 1/10W
R291 BIRC6810025N00 C RESISTOR 680
Ω 1/2W
R292 BIRC6810025N00 C RESISTOR 680
Ω 1/2W
R293 BIRC1020105A00 C RESISTOR 1K
Ω 1/10W
R294 BIRC1020105A00 C RESISTOR 1K
Ω 1/10W
R295 BIRC2220105A00 C RESISTOR 2.2K
Ω 1/10W
R296 BIRC2220105A00 C RESISTOR 2.2K
Ω 1/10W
R297 BIRC3920105A00 C RESISTOR 3.9K
Ω 1/10W
L101 BI18A843556N00 FILTER BEAD 843556
L201 BI2600702V CHOKE COIL 1uH
L202 BI2600702V CHOKE COIL 1uH
CN101 BI12S60119V CONNECTOR WIRE
6P for POWER
TRANS
CN102 BI12S600961 CONNECTOR 6P
CN105 BI12S20057V SOCKET 2P
CN157 BI12S200161V CONNECTOR 4P
CN201 BI12S150028V SOCKET 15P
CN202 BI12S80058V SOCKET 8P
CN204 BI12S40047V CONNECTOR 4P
JR101 BIRC0000085A00 C RESISTOR 0
Ω 1/8W
JR102 BIRC0000085A00 C RESISTOR 0
Ω 1/8W
JR103 BIRC0000105A00 C RESISTOR 0
Ω 1/10W
P102 BI11A050M0Y BLACK WIRE 50mm UL1007
P103 BI11A050M0Y BLACK WIRE 50mm UL1007
RY201 BI8RL00191V RELAY
DC12V ME-7C-012-
3H
SP201 BI23F0741V SPK TERMINAL
XXXXX BT000604S3 SCREW
HEATSINK AMP-
PCB-1
XXXXX BI12P20205V WIRE 2P L=60mm
XXXXX BIRT103THMSP01 THERMISTOR 10K
XXXXX BI202672010101 HEAT SINK for IC104
XXXXX BI202672010101 HEAT SINK for Q101
XXXXX BIRT000611B3 SCREW 3 X L8 B-TYPE(x9)
ZD101 UZ12BSC Z DIODE BI3UZ12BSCM000
ZD121 MTZJ3.3B Z DIODE BI3MTZJ33BM000
ZD157 UZ5.6BSB Z DIODE BI3UZ5.6BSBM000
 Symbol No. Part No. Part Name Description Local
IC701 S1L9226 IC BI116431
IC703 IP4001S IC BI118471
IC801 S5L9279 IC BI116401
IC802 K4S161622H-UC60 IC BI117401V
IC803 BH18FB1WG IC BI118171
IC871 MN101C61G IC BI118121
IC872 BR93L56RF IC BI118251
Q701 KTA1266GR TRANSISTOR BI2KTA1266GP00
Q703 KTA1273Y TRANSISTOR BI2KTA1273YP000
Q762 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q871 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
D762 1SS133 FR DIODE BI31SS133M000V7
C701 BICC104500ZA04 C CAPACITOR 0.1uF 50V
C702 BICC104500ZA04 C CAPACITOR 0.1uF 50V
C703 BICC102500JA04 C CAPACITOR 1000pF 50V
C704 BICE476160MP11 E CAPACITOR 47uF 16V
C705 BICC102500JA04 C CAPACITOR 1000pF 50V
C706 BICC102500JA04 C CAPACITOR 1000pF 50V
C707 BICC103250KA04 C CAPACITOR 0.01uF 25V
 Symbol No. Part No. Part Name Description Local
C708 BICC473250KA04 C CAPACITOR 0.047uF 25V
C709 BICE227063MP11 E CAPACITOR 220uF 6.3V
C710 BICE107100MP11 E CAPACITOR 100uF 10V
C711 BICC040500CA04 C CAPACITOR 4pF 50V
C712 BICC100500DA04 C CAPACITOR 10pF 50V
C713 BICC682500KA04 C CAPACITOR 6800pF 50V
C714 BICC103250KA04 C CAPACITOR 0.01uF 25V
C715 BICE475500MP11 E CAPACITOR 4.7uF 50V
C716 BICC104250KA04 C CAPACITOR 0.1uF 25V
C717 BICC104250KA04 C CAPACITOR 0.1uF 25V
C718 BICC102500JA04 C CAPACITOR 1000pF 50V
C719 BICC104250KA04 C CAPACITOR 0.1uF 25V
C720 BICC333250KA04 C CAPACITOR 0.033uF 25V
C721 BICC474100KA04 C CAPACITOR 0.47uF 10V
C722 BICC474100KA04 C CAPACITOR 0.47uF 10V
C723 BICC332500KA04 C CAPACITOR 3300pF 50V
C724 BICC103250KA04 C CAPACITOR 0.01uF 25V
C725 BICC683160KA04 C CAPACITOR 0.068uF 16V
C726 BICE106100MP11 E CAPACITOR 10uF 10V
C727 BICC823160KA04 C CAPACITOR 0.082uF 16V
C728 BICC331500JA04 C CAPACITOR 330pF 50V
C729 BICC102500JA04 C CAPACITOR 1000pF 50V
C730 BICC222500KA04 C CAPACITOR 2200pF 50V
C731 BICC333250KA04 C CAPACITOR 0.033uF 25V
C732 BICC104250KA04 C CAPACITOR 0.1uF 25V
C733 BICC104250KA04 C CAPACITOR 0.1uF 25V
C734 BICC101500JA04 C CAPACITOR 100pF 50V
C735 BICC101500JA04 C CAPACITOR 100pF 50V
C736 BICC101500JA04 C CAPACITOR 100pF 50V
C737 BICC101500JA04 C CAPACITOR 100pF 50V
C738 BICC101500JA04 C CAPACITOR 100pF 50V
C739 BICC101500JA04 C CAPACITOR 100pF 50V
C740 BICC101500JA04 C CAPACITOR 100pF 50V
C741 BICC391500JA04 C CAPACITOR 390pF 50V
C742 BICC391500JA04 C CAPACITOR 390pF 50V
C743 BICC391500JA04 C CAPACITOR 390pF 50V
C744 BICC391500JA04 C CAPACITOR 390pF 50V
C755 BICC102500JA04 C CAPACITOR 1000pF 50V
C756 BICC102500JA04 C CAPACITOR 1000pF 50V
C761 BICE477100MP01 E CAPACITOR 470uF 10V
C762 BICC104500ZA04 C CAPACITOR 0.1uF 50V
C763 BICE107100MP11 E CAPACITOR 100uF 10V
C803 BICE107100MP11 E CAPACITOR 100uF 10V
C804 BICC104500ZA04 C CAPACITOR 0.1uF 50V
C805 BICC270500JA04 C CAPACITOR 27pF 50V
C806 BICC270500JA04 C CAPACITOR 27pF 50V
C807 BICC104500ZA04 C CAPACITOR 0.1uF 50V
C808 BICE107100MP11 E CAPACITOR 100uF 10V
C809 BICC104250KA04 C CAPACITOR 0.1uF 25V
C810 BICC122500KA04 C CAPACITOR 1200pF 50V
C811 BICC122500KA04 C CAPACITOR 1200pF 50V
C812 BICC122500KA04 C CAPACITOR 1200pF 50V
C813 BICC104500ZA04 C CAPACITOR 0.1uF 50V
C814 BICE107100MP11 E CAPACITOR 100uF 10V
C815 BICE107100MP11 E CAPACITOR 100uF 10V
C816 BICC104500ZA04 C CAPACITOR 0.1uF 50V
C817 BICC104500ZA04 C CAPACITOR 0.1uF 50V
C818 BICC104500ZA04 C CAPACITOR 0.1uF 50V
C819 BICC104500ZA04 C CAPACITOR 0.1uF 50V
C820 BICC104500ZA04 C CAPACITOR 0.1uF 50V
C821 BICC104500ZA04 C CAPACITOR 0.1uF 50V
C822 BICC104500ZA04 C CAPACITOR 0.1uF 50V
C823 BICC104500ZA04 C CAPACITOR 0.1uF 50V
C825 BICC103250KA04 C CAPACITOR 0.01uF 25V
C826 BICE106100MP11 E CAPACITOR 10uF 10V
C827 BICE106100MP11 E CAPACITOR 10uF 10V
C835 BICC100500DA04 C CAPACITOR 10pF 50V
C841 BICC102500KA04 C CAPACITOR 1000pF 50V
C842 BICC330500JA04 C CAPACITOR 33pF 50V
C843 BICC330500JA04 C CAPACITOR 33pF 50V
C844 BICC330500JA04 C CAPACITOR 33pF 50V
C871 BICC103250KA04 C CAPACITOR 0.01uF 25V
C872 BICC104500ZA04 C CAPACITOR 0.1uF 50V
C873 BICC150500JA04 C CAPACITOR 15pF 50V
C874 BICC101500JA04 C CAPACITOR 100pF 50V
C875 BICC330500JA04 C CAPACITOR 33pF 50V
C876 BICC470500JA04 C CAPACITOR 47pF 50V
C877 BICC470500JA04 C CAPACITOR 47pF 50V
 Symbol No. Part No. Part Name Description Local
