JVC UX-G5 Service Manual

3-13
Wiring
Block No. [0][6]
C878 BICC470500JA04 C CAPACITOR 47pF 50V
C880 BICC470500JA04 C CAPACITOR 47pF 50V
C881 BICC470500JA04 C CAPACITOR 47pF 50V
C882 BICC104250KA04 C CAPACITOR 0.1uF 25V
C883 BICC104500ZA04 C CAPACITOR 0.1uF 50V
R701 BIRC0820105A00 C RESISTOR 8.2
Ω 1/10W
R702 BIRC1840105A00 C RESISTOR 180K
Ω
R703 BIRC3930105A00 C RESISTOR 39K Ω 1/10W
R704 BIRC3930105A00 C RESISTOR 39K
Ω 1/10W
R705 BIRC3930105A00 C RESISTOR 39K
Ω 1/10W
R706 BIRC3930105A00 C RESISTOR 39K
Ω 1/10W
R707 BIRC1840105A00 C RESISTOR 180K
Ω
R708 BIRC4700105A00 C RESISTOR 47 Ω 1/10W
R709 BIRC4720105A00 C RESISTOR 4.7K
Ω 1/10W
R710 BIRC1010105A00 C RESISTOR 100
Ω 1/10W
R711 BIRC5620105A00 C RESISTOR 5.6K
Ω 1/10W
R714 BIRC1030105A00 C RESISTOR 10K
Ω 1/10W
R715 BIRC1830105A00 C RESISTOR 18K
Ω 1/10W
R716 BIRC2230105A00 C RESISTOR 22K
Ω 1/10W
R717 BIRC1050105A00 C RESISTOR 1M
Ω 1/10W
R718 BIRC1030105A00 C RESISTOR 10K
Ω 1/10W
R719 BIRC5620105A00 C RESISTOR 5.6K
Ω 1/10W
R720 BIRC1020105A00 C RESISTOR 1K
Ω 1/10W
R721 BIRC1030105A00 C RESISTOR 10K
Ω 1/10W
R722 BIRC1030105A00 C RESISTOR 10K
Ω 1/10W
R723 BIRC8230105A00 C RESISTOR 82K
Ω 1/10W
R724 BIRC8230105A00 C RESISTOR 82K
Ω 1/10W
R725 BIRC1530105A00 C RESISTOR 15K
Ω 1/10W
R726 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R727 BIRC1240105A00 C RESISTOR 120K
Ω 1/10W
R728 BIRC2730105A00 C RESISTOR 27K
Ω 1/10W
R729 BIRC1540105A00 C RESISTOR 150K
Ω 1/10W
R730 BIRC1240105A00 C RESISTOR 120K
Ω 1/10W
R731 BIRC1040105A00 C RESISTOR 100K
Ω 1/10W
R732 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R746 BIRC1010085M00 C RESISTOR 100
Ω 1/8W J
R747 BIRC1010085M00 C RESISTOR 100
Ω 1/8W J
R756 BIRC1030105A00 C RESISTOR 10K
Ω 1/10W
R757 BIRC1830085M00 C RESISTOR 18K
Ω 1/8W J C
R763 BIRC1220105A00 C RESISTOR 1.2K
Ω 1/10W
R764 BIRC1030105A00 C RESISTOR 10K
Ω 1/10W
R765 BIRC4710105A00 C RESISTOR 470
Ω 1/10W
R771 BIRC1020105A00 C RESISTOR 1K
Ω 1/10W
R802 BIRC1020085N00 C RESISTOR 1K
Ω 1/8W
R803 BIRC1020085N00 C RESISTOR 1K
Ω 1/8W
R804 BIRC3310105A00 C RESISTOR 330
Ω 1/10W
R805 BIRC1050105A00 C RESISTOR 1M
Ω 1/10W
R806 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R807 BIRC3310105A00 C RESISTOR 330
Ω 1/10W
R808 BIRC1010085M00 C RESISTOR 100
Ω 1/8W J
R809 BIRC1210085M00 C RESISTOR 120
Ω 1/8W
R810 BIRC1210105A00 C RESISTOR 120
Ω 1/10W
R811 BIRC1010105A00 C RESISTOR 100
Ω 1/10W
R812 BIRC1230105A00 C RESISTOR 12K
Ω 1/10W
R813 BIRC1230105A00 C RESISTOR 12K
Ω 1/10W
R814 BIRC1010105A00 C RESISTOR 100
Ω 1/10W
R836 BIRC1040105A00 C RESISTOR 100K
Ω 1/10W
R837 BIRC1040105A00 C RESISTOR 100K
Ω 1/10W
R841 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R842 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R843 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R844 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R845 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R846 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R847 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R848 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R849 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R850 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R851 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R852 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R853 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R854 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R871 BIRC1020105A00 C RESISTOR 1K
Ω 1/10W
R876 BIRC1210085M00 C RESISTOR 120
Ω 1/8W
R877 BIRC1210085M00 C RESISTOR 120
Ω 1/8W
R878 BIRC1210085M00 C RESISTOR 120
Ω 1/8W
R879 BIRC1210085M00 C RESISTOR 120
Ω 1/8W
 Symbol No. Part No. Part Name Description Local
R880 BIRC1210085M00 C RESISTOR 120 Ω 1/8W
R881 BIRC1210085M00 C RESISTOR 120
Ω 1/8W
R882 BIRC1030105A00 C RESISTOR 10K
Ω 1/10W
R883 BIRC1030105A00 C RESISTOR 10K
Ω 1/10W
R884 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R885 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R886 BIRC1020105A00 C RESISTOR 1K
Ω 1/10W
R887 BIRC1020105A00 C RESISTOR 1K
Ω 1/10W
R888 BIRC1020105A00 C RESISTOR 1K
Ω 1/10W
R889 BIRC1020105A00 C RESISTOR 1K
Ω 1/10W
R890 BIRC1020085N00 C RESISTOR 1K
Ω 1/8W
R891 BIRC1020105A00 C RESISTOR 1K
Ω 1/10W
R892 BIRC1020105A00 C RESISTOR 1K
Ω 1/10W
R893 BIRC1020105A00 C RESISTOR 1K
Ω 1/10W
R894 BIRC1020105A00 C RESISTOR 1K
Ω 1/10W
R895 BIRC1030105A00 C RESISTOR 10K
Ω 1/10W
R896 BIRC1030105A00 C RESISTOR 10K
Ω 1/10W
L710 BI26100000KM00 FIXED INDUCTOR 10UH
L761 BI18A843556N00 FILTER BEAD 843556
L801 BI26100000KN00 FIXED INDUCTOR 10UH
L802 BI26100000KN00 FIXED INDUCTOR 10UH
L803 BI26100000KM00 FIXED INDUCTOR 10UH
L804 BI26100000KM00 FIXED INDUCTOR 10UH
L805 BI26100000KM00 FIXED INDUCTOR 10UH
L806 BI26100000KN00 FIXED INDUCTOR 10UH
L808 BI18A843556N00 FILTER BEAD 843556
L809 BI18A916121A00 FERRITE BEAD 120
Ω
L822 BI18A843556N00 FILTER BEAD 843556
L871 BI26100000KM00 FIXED INDUCTOR 10UH
CN701 BI12S160043V SOCKET 16P
CN702 BI12P60170V CONNECTOR WIRE 6P for CD MECH
CN801 BI12S280005U SOCKET 28P
CN802 BI12SBI120038 SOCKET 12P
CN871 BI12S150027V SOCKET 15P
CN872 BI12S200161
SOCKET
CONNECTOR
2P
CN873 BI12S30039 CONNECTOR 3P
JR701 BIRC0000105A00 C RESISTOR 0
Ω
JR702 BIRC0000105A00 C RESISTOR 0 Ω
JR704 BIRC0000105A00 C RESISTOR 0 Ω
JR706 BIRC0000105A00 C RESISTOR 0 Ω
JR707 BIRC0000105A00 C RESISTOR 0 Ω
JR708 BIRC0000105A00 C RESISTOR 0 Ω
JR801 BIRC0000105A00 C RESISTOR 0 Ω
JR802 BIRC0000105A00 C RESISTOR 0 Ω
JR803 BIRC0000085A00 C RESISTOR 0 Ω
JR804 BIRC0000085A00 C RESISTOR 0 Ω
JW801 BI18A843556N00 FILTER BEAD 843556
X801 BI2100796 CRYSTAL 16.9344MHz
X871 BI29ZTA8.00P015 C RESONTOR 8MHz
 Symbol No. Part No. Part Name Description Local
XXXXX BI1206561Y FFC CABLE
16P for CD CN701
to CD MECH
XXXXX BI1206821Y FFC CABLE
12P for MAIN
CN681 to TUNER
XXXXX BI1207001Y FFC CABLE
16P for MAIN
CN402 to KEY
CN351
XXXXX BI1206841Y FFC CABLE
28P for MAIN
CN401 to CD
CN801
XXXXX BI1206851Y FFC CABLE
12P for MAIN
CN661 to CD
CN802
