JVC UX-G6 Service Manual

3-25
UX-G6/FS-G6
Parts list (Cassette mechanism)
Item
Parts number Parts name
Area
Q'ty
Description
Block No
.
M6MM
1 EGS-E5A1001 CHASSIS 1
3 EGS-E5A3002 CAM GEAR 1
4 EGS-E5B3004 TRIGGER ARM 1
5 EGS-E5D6006 SPRING 1 TRIGGER ARM
17 EGS-E5D6011 SPRING 1 CLUTCH ARM
19 EGS-E5D3024 IDLER GEAR 1 REW
20 EGS-E5D8002 CAM SCREW 1
21 EGS-E5D3030 IDLER GEAR 1 PLAY
22 EGS-E5D3062 REEL BUSH
(
D
)
2
23 EGS-FC3037 REEL CAP
(
A
)
2
24 EGS-MOD6015 B.T SPRING 2
25 EGS-E5D3031 REEL GEAR 2
26 EGS-E5C5001 HOUSING ASSY
(
L
)
1
27 EGS-E5C5002 HOUSING ASSY
(
R
)
1
28 EGS-E5B1002 HEAD CHASSIS 1
29 EGS-E5C3006 HEAD PLATE 1
30 EGS-E5D6003 HEAD SPRING 1
31 EGS-E5D6002 HEAD SPRING 1
32 EGS-E5D6018 SPRING
(
B
)
1 RETURN GEAR
33 EGS-E5D3020 RETURN GEAR 1
34 EGS-E5D9009 HEAD WIRE
(
R/P
)
1
36 EGS-E5B3003 HEAD BASE 1
37 EGS-E5D1004 AZIMUTH PLATE 1
38 EGS-MOD8005 AZIMUTH SCREW 2
39 EGS-E5D6005 EARTH SPRING 1
40 EGS-E5D1005 HEAD PLATE 1
41 EGS-E5D2004 ROTATOR COLLAR 1
42 EGS-E5C3061 ROTATOR 1
43 EGS-PD8011 HEAD WIRE CLAMP 1
44 EGS-92432230 ROTATION HEAD 1 R/P KC-9242
45 EGS-E5D8003 HEAD SCREW 2
52 EGS-E5D3023 CASSETTE GUIDE 1
57 EGS-E5C3007 BRAKE ARM 1
58 EGS-E5D6001 SPRING 1 BRAKE ARM
63 EGS-E5D4007 DRIVE BELT
(
H
)
1
64 EGS-E5D4005 CLUTCH BELT
(
W
)
1
65 EGS-FDS1037 PACK SPRING
(
N
)
1
66 EGS-MOD9038 SOLENOID ASSY
(
H 1
67 EGS-E5D3029 PULLEY GEAR 1
68 EGS-MOC9036 REC SWITCH
(
B
)
5
69 EGS-E5D9007 IC
(
PH.INTER.
)
1
71 EGS-MOC9004 PLAY SWITCH 1
72 RD14BB2C222J RESISTOR 1 2.2K
73 EGS-99415181 CONNECTOR 1 IMSA-9604S-15F
75 EGS-E5C9019 MECHA BOARD
(
H
)
1
79 EGS-8341116108 POLY WASHER 1 4X7X0.4CUT
80 EGS-8340419002 NYLON WASHER 1 1.9X5X0.5
81 EGS-8340421023 NYLON WASHER 1 2.19X5.5X0.5
82 EGS-8341116591 POLY WASHER 1 1.57X5X0.5CUT
83 EGS-8341118065 POLY WASHER 1 1.8X6X0.5CUT
84 EGS-8340504111 TEFRON WASHER 2 4.1X5.5X0.25
