3-26
UX-G6/FS-G6
Parts list (Cassette mechanism)
Item
Parts number Parts name
Area
Q'ty
Description
Block No
.
M6MM
85 EGS-8342121030 POLY WASHER 1 2.1X5X0.25
86 EGS-8342123076 POLY WASHER 1 2.3X4X0.25
88 EGS-8341115998 POLY WASHER 1 1.57X4X0.5 CUT
90 EGS-8113112005 TAPPING SCREW 7 M2X5
91 EGS-8114512006 TAPPING SCREW 6 M2X6
92 EGS-8115512604 SCREW 2 M2.6X4
93 EGS-96901033 FILAMENT TAPE 1
94 EGS-E5D3055 MECHA BASE
(
H
)
AS 1
95 EGS-E5D9025 MOTOR ASSY
(
H
)
1
96 EGS-E5C3032 CLUCH ASSY 1
97 EGS-E5D5007 FLYWHEEL ASSY 1 RH-A
98 EGS-E5D5009 FLYWHEEL ASSY 1 LH-A
99 EGS-E5D3035 PINCH ROLLER
(
R
)
1
100 EGS-E5D3034 PINCH ROLLER
(
L
)
1
101 EGS-E5D9022 MOTOR WIRE
(
H
)
1
104 EGS-99054172 CONNECTOR 1 S6B-PH
105 EGS-8113112004 SCREW 1 M2X4
106 EGS-8341140008 POLY WASHER 1 4X1.57X0.13CUT
107 EGS-E5A3041 GUIDE BASE
(
R
)
1
108 EGS-E5A3042 GUIDE BASE
(
L
)
1
109 EGS-E5A3043 TRAY
(
A
)
1
110 EGS-E5B3044 TRAY
(
B
)
1
111 EGS-E5B3045 SLIDER 1
112 EGS-E5C3048 LINK
(
A
)
1
113 EGS-E5C3047 LINK
(
B
)
1
114 EGS-E5D3050 GEAR
(
A
)
1
115 EGS-E5D3051 PULLY GEAR 1
116 EGS-E5D3052 STOPPER 1
117 EGS-E5C1009 MOTOR HOLDER 1
118 EGS-E5C1014 CLAMPER ASSY 1
119 EGS-E5D1012 EARTH PLATE 1
120 EGS-E5D1010 CLAMPER ARM 1
121 EGS-E5D6019 STOPPER SPRING 1
122 EGS-E5D6020 SPRING 1 CLAMPER ARM
123 EGS-E5D6021 P.RETURN SPRING 1 R
124 EGS-E5D6022 P.RETURN SPRING 1 L
125 EGS-C3D8010 SCREW
(
F
)
1
126 EGS-E1D8012 SCREW
(
A2
)
4
127 EGS-E5D4008 BELT
(
LD
)
1
128 EGS-E5D8011 SCREW
(
H
)
3
129 EGS-E5D9020 PCB
(
LD
)
1
131 EGS-E5D1013 GUIDE BASE 1
133 EGS-E5D6023 LINK SPRING 1
134 EGS-E5D9023 WIRE 1 OPEN
135 EGS-E5D9024 WIRE 1 CLOSE
136 EGS-94081105 SWITCH 2 MPU10420MLB0
137 EGS-99054175 CONNECTOR 1 S5B-PH
138 EGS-E5D9026 MOTOR ASSY 1 LD
139 EGS-8114512606 SCREW 6 M2.6X6
140 EGS-8115712635 SCREW 2 M2.6X3.5
141 EGS-8114512008 SCREW 4 M2X8
