(No.MB665<Rev.004>)1-13

3.1.11 Removing the FL board (See Fig.18)

(1) Remove the seven screws M attaching the FL board.

3.1.12 Removing the Volume board (See Fig.18)

(1) Remove the volume knob.

(2) Remove the nine screws N attaching the Volume board.

Fig.18
