3-15
C2008 QEZ0884-227 M CAPACITOR 220uF 300US,300UT,
300UW,300UG,
300UN,305UT
C2009 QCZ0136-331Z C CAPACITOR 330pF 1kV K
C2010 QCZ0134-472 C CAPACITOR 4700pF
C2012 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2013 NDC31HJ-221X C CAPACITOR 220pF 50V J
C2014 QCZ0136-221Z C CAPACITOR 220pF 1kV K
C2015 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2016 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C2017 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2018 NDC31HJ-471X C CAPACITOR 470pF 50V J
C2020 QCZ9134-222 C CAPACITOR 2200pF
C2100 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C2101 QETN1EM-476Z E CAPACITOR 47uF 25V M
C2102 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C2103 NDC31HJ-201X C CAPACITOR 200pF 50V J
C2105 QETN1CM-107Z E CAPACITOR 100uF 16V M
C2106 NCB31HK-471X C CAPACITOR 470pF 50V K
C2121 QETN1AM-477Z E CAPACITOR 470uF 10V M
C2125 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C2131 QEZ0658-396Z E CAPACITOR 39uF 50V M
C2133 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C2153 QETM1EM-228 E CAPACITOR 2200uF 25V M
C2155 QETN1EM-337Z E CAPACITOR 330uF 25V M
C2156 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C2160 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C2301 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2600 QETN1EM-476Z E CAPACITOR 47uF 25V M
C2601 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3650 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3651 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3652 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3658 QETN1CM-107Z E CAPACITOR 100uF 16V M
C7000 QERF0JM-107Z E CAPACITOR 100uF 6.3V M
C7201 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7209 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7210 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C8000 NDC31HJ-150X C CAPACITOR 15pF 50V J
C8001 NDC31HJ-101X C CAPACITOR 100pF 50V J
C8002 NDC31HJ-150X C CAPACITOR 15pF 50V J
C8004 NDC31HJ-100X C CAPACITOR 10pF 50V J
C8100 NDC31HJ-331X C CAPACITOR 330pF 50V J 300B,300E,
300EN,300EV,
303E,303EN,
303EV,305E,
305EN,305EV
C8104 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8200 NDC31HJ-331X C CAPACITOR 330pF 50V J 300B,300E,
300EN,300EV,
303E,303EN,
303EV,305E,
305EN,305EV
C8300 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8400 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8401 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C8402 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9600 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9602 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9603 NCB31HK-104X C CAPACITOR 0.1uF 50V K
R2001 QRZ9037-335 COMP RESISTOR 3.3M
Ω
1/2W K
R2002 QRZ0255-224 UNF C RESISTOR 220k
Ω
R2003 QRZ0255-224 UNF C RESISTOR 220k
Ω
R2005 QRZ0255-154 UNF C RESI 150k
Ω
R2006 NRSA63J-680X MG RESISTOR 68
Ω
1/16W J
R2007 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R2008 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R2010 QRT01DJ-R39X MF RESISTOR 0.39
Ω
1W J
R2011 QRT01DJ-R39X MF RESISTOR 0.39
Ω
1W J
R2012 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R2013 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2015 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R2100 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R2101 NRSA63J-203X MG RESISTOR 20k
Ω
1/16W J
R2102 NRSA63J-512X MG RESISTOR 5.1k
Ω
1/16W J
R2104 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
R2105 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R2106 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
R2108 QRT01DJ-R22X MF RESISTOR 0.22
Ω
1W J
R2121 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R2125 NRSA63J-151X MG RESISTOR 150
Ω
1/16W J
R2126 NRSA63J-151X MG RESISTOR 150
Ω
1/16W J
R2131 QRZ9015-100X FUSI RESISTOR 10
Ω
R2133 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R2134 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R2160 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R2161 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R2162 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R2163 NRSA63J-623X MG RESISTOR 62k
Ω
1/16W J
R2164 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R2165 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R2170 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R2300 QRZ9005-101X F RESISTOR 100
Ω
R2301 NRSA63J-242X MG RESISTOR 2.4k
Ω
1/16W J
R7000 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R7100 NRSA63J-363X MG RESISTOR 36k
Ω
1/16W J
R7101 NRSA63J-113X MG RESISTOR 11k
Ω
1/16W J
R7102 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R7103 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R7104 NRSA63J-202X MG RESISTOR 2k
Ω
1/16W J
R7200 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
R7201 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7202 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7203 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R8400 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9500 NRSA63J-113X MG RESISTOR 11k
Ω
1/16W J
R9501 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R9502 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R9503 NRSA63J-202X MG RESISTOR 2k
Ω
1/16W J
L2103 QQL28AK-470 CHOKE COIL 47uH K
L2151 QQLZ043-120 COIL 12uH
T2000 QQS0422-001 SW TRANSF
CN200 QGA7901C1-02 CONNECTOR W-B (1-2)
CN201 QGD2504C1-05ZCONNECTOR (1-5)
CN203 QGD2504C1-04ZCONNECTOR (1-4)
CN204 QGB2510K2-06 CONNECTOR B-B (1-6)
CN205 QGF1040C1-07 CONNECTOR FFC/FPC (1-7)
CN360 QGF1040F1-05 CONNECTOR FFC/FPC (1-5)
CN362 QGF1040F1-19 CONNECTOR FFC/FPC (1-19)
CN364 QGF1040C1-25 CONNECTOR FFC/FPC (1-25)
CN704 QGF1208F1-13 CONNECTOR FFC/FPC (1-13)
CN803 QGB1214K1-08S CONNECTOR B-B (1-8)
CN904 QGF1208F1-05 CONNECTOR FFC/FPC (1-5)
CP211 ICP-N10-T IC PROTECTOR 400mA
EP200 QNZ0136-001Z EARTH PLATE
EP201 QNZ0136-001Z EARTH PLATE
EP800 QNZ0136-001Z EARTH PLATE
EP801 QNZ0136-001Z EARTH PLATE
EP810 QNZ0136-001Z EARTH PLATE
FC201 QNG0003-001Z FUSE CLIP
FC202 QNG0003-001Z FUSE CLIP
FL720 QLF0194-001 FL TUBE
HS201 LV40057-004A HEAT SINK
HS251 GV40614-001A HEAT SINK
HS260 GV40606-002A HEAT SINK
J8000 QNZ0851-001 USB CONNECTOR
J8100 QNS0188-001 JACK
J8300 QNS0188-001 JACK
JS960 QSW1060-001 ROTARY SW
K8001 NQR0627-002X FERRITE
1.5K/
100MHz200mA0.4R
K8002 NQR0627-002X FERRITE
1.5K/
100MHz200mA0.4R
K9600 NQR0022-002X FERRITE BEADS
LF201 QQR1790-001 LINE FILTER
LF202 QQR1790-001 LINE FILTER
S7100 QSW0683-001Z PUSH SW
S7101 QSW0683-001Z PUSH SW
S7102 QSW0683-001Z PUSH SW
S7103 QSW0683-001Z PUSH SW
S7104 QSW0683-001Z PUSH SW
S7105 QSW0683-001Z PUSH SW
S9500 QSW0683-001Z PUSH SW
S9501 QSW0683-001Z PUSH SW
Symbol No.
Part No. Part Name Description Local
