JVC UX-G800D Service Manual

3-16
CD servo board(FMU-MJ4-1M)
Block No. [0][4]
S9502 QSW0683-001Z PUSH SW
S9503 QSW0683-001Z PUSH SW
S9504 QSW0683-001Z PUSH SW
 TH201 QAD0143-3R9 THERMISTOR 3.9 Ω 300B,300E,
300EN,300EV,
303E,303EN,
303EV,305E,
305EN,305EV,
300A,300UF
 TH201 QAD0141-4R0 N THERMISTOR 4 Ω 300US,300UT,
300UW,300UG,
300UN,305UT
WC201 QZW0112-001 WIRE CLAMP
 Symbol No. Part No. Part Name Description Local
IC201 LA6242H-X IC
IC301 MN6627971DA IC
IC302 S-24CS16A0I-G-X IC
IC304 MM3233DF-X IC
IC801 MN103SFB5KWM1 IC(MCU)
IC802 MM1565AF-X IC
Q301 ISA1530AC1/QR/X TRANSISTOR
Q801 RT1N141C-X DIGI TRANSISTOR
D302 MA2SD31-X SB DIODE
C101 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C102 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C103 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C205 NCB31HK-122X C CAPACITOR 1200pF 50V K
C206 NCB31HK-182X C CAPACITOR 1800pF 50V K
C207 NCB31HK-682X C CAPACITOR 6800pF 50V K
C208 NCB31HK-222X C CAPACITOR 2200pF 50V K
C211 NDC31HJ-680X C CAPACITOR 68pF 50V J
C218 QERF1AM-227Z E CAPACITOR 220uF 10V M
C219 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C220 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C221 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C301 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C304 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C305 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C306 NCB21CK-105X C CAPACITOR 1uF 16V K
C309 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C310 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C312 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C314 NCB31CK-154X C CAPACITOR 0.15uF 16V K
C315 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C316 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C319 NCB31CK-334X C CAPACITOR 0.33uF 16V K
C320 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C321 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C322 NCB31HK-681X C CAPACITOR 680pF 50V K
C324 NCB31CK-334X C CAPACITOR 0.33uF 16V K
C325 NCB31HK-102X C CAPACITOR 1000pF 50V K
C326 NCB31CK-823X C CAPACITOR 0.082uF 16V K
C327 NCB31HK-102X C CAPACITOR 1000pF 50V K
C328 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C329 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C330 NCB20JK-475X C CAPACITOR 4.7uF 6.3V K
C331 NCB31HK-332X C CAPACITOR 3300pF 50V K
C332 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C333 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C334 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C337 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C338 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C339 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C340 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C341 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C342 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C343 NDC31HJ-270X C CAPACITOR 27pF 50V J
 Symbol No. Part No. Part Name Description Local
C344 NDC31HJ-270X C CAPACITOR 27pF 50V J
C361 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C376 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C377 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C701 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C702 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C801 NDC31HJ-300X C CAPACITOR 30pF 50V J
C802 NDC31HJ-270X C CAPACITOR 27pF 50V J
C803 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C804 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C805 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C806 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C807 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C809 NCB20JK-106X C CAPACITOR 10uF 6.3V K
C811 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C814 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C815 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C816 NDC31HJ-471X C CAPACITOR 470pF 50V J
C817 NCB21CK-105X C CAPACITOR 1uF 16V K
R101 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R102 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R201 NRSA63J-683X MG RESISTOR 68k
Ω 1/16W J
R202 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R203 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R204 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R205 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R206 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R207 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R208 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R209 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R210 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R211 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R212 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R213 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R214 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R221 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R222 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R223 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R224 NRS181J-0R0X MG RESISTOR 0
Ω 1/8W J
R301 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
R303 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R304 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
R308 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R309 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R310 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R311 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R312 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R313 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R314 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R315 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R319 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R320 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R321 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R322 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R323 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R324 NRSA63J-823X MG RESISTOR 82k
Ω 1/16W J
R325 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R330 NRSA02F-100X MG RESISTOR 10
Ω 1/10W F
R331 NRSA02F-100X MG RESISTOR 10
Ω 1/10W F
R336 NRSA63J-100X MG RESISTOR 10
Ω 1/16W J
R338 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R339 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R341 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R343 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R346 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R348 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R350 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R351 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R352 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R353 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R356 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R357 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R358 NRSA63J-105X MG RESISTOR 1M
Ω 1/16W J
R359 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R360 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R363 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R364 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
