JVC UX-G800D Service Manual

3-17
Loader board(FLM-J6-2M)
Block No. [0][5]
CD servo board(FMU-VK1-1M)
Block No. [0][6]
R367 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R368 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R369 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R376 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R377 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R381 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R382 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R383 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R701 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R801 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R802 NRSA63J-200X MG RESISTOR 20
Ω 1/16W J
R803 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R805 NRSA63J-151X MG RESISTOR 150
Ω 1/16W J
R806 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R807 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R808 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R809 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R810 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R814 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R815 NRSA63J-200X MG RESISTOR 20
Ω 1/16W J
R816 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R817 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R819 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
R820 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R821 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
L801 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
CN101 QGF0501F8-15X CONNECTOR FFC/FPC (1-15)
CN701 QGF1036F2-19 CONNECTOR FFC/FPC (1-19)
CN702 QGF1036F2-08 CONNECTOR FFC/FPC (1-8)
CN801 QGF1036F2-07 CONNECTOR FFC/FPC (1-7)
CN802 QGA2001F6-05X CONNECTOR W-B (1-5)
K701 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K702 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K703 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K704 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K705 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K706 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K707 NQR0022-002X FERRITE BEADS
K708 NQR0022-002X FERRITE BEADS
K709 NQR0022-002X FERRITE BEADS
K801 NQR0360-002X COIL
K802 NQR0360-002X COIL
SW601 QSW1047-002 PUSH SWITCH
X301 NAX0375-001X CRYSTAL 16.9344MHz
X801 QAX0724-001Z CRYSTAL 12.000000MHz
 Symbol No. Part No. Part Name Description Local
CN1 QGF1016F9-05 CONNECTOR FFC/FPC (1-5)
S1 QSW1074-002 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
IC201 LA6242H-X IC
IC301 MN6627971DB IC
IC302 S-24CS16A0I-G-X IC
IC304 MM3233DF-X IC
IC801 MN103SFB5KWM2 IC(MCU)
IC802 MM1565AF-X IC
Q301 ISA1530AC1/QR/X TRANSISTOR
Q801 RT1N141C-X DIGI TRANSISTOR
 Symbol No. Part No. Part Name Description Local
D302 MA2SD31-X SB DIODE
C101 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C102 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C103 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z
C205 NCB31HK-152X C CAPACITOR 1500pF 50V K
C206 NCB31HK-182X C CAPACITOR 1800pF 50V K
C207 NCB31HK-682X C CAPACITOR 6800pF 50V K
C208 NCB31HK-222X C CAPACITOR 2200pF 50V K
C211 NDC31HJ-680X C CAPACITOR 68pF 50V J
C218 NEAF1CM-107X E CAPACITOR 100uF 16V M
C219 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C220 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C221 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C301 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C304 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C305 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C306 NCB21CK-105X C CAPACITOR 1uF 16V K
C309 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C310 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C312 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C314 NCB31CK-154X C CAPACITOR 0.15uF 16V K
C315 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C316 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C319 NCB31CK-334X C CAPACITOR 0.33uF 16V K
C320 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C321 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C322 NCB31HK-681X C CAPACITOR 680pF 50V K
C324 NCB31CK-334X C CAPACITOR 0.33uF 16V K
C325 NCB31HK-102X C CAPACITOR 1000pF 50V K
C326 NCB31CK-823X C CAPACITOR 0.082uF 16V K
C327 NCB31HK-102X C CAPACITOR 1000pF 50V K
C328 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C329 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C330 NCB20JK-475X C CAPACITOR 4.7uF 6.3V K
C331 NCB31HK-332X C CAPACITOR 3300pF 50V K
C332 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C333 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C334 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C337 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C338 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C339 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C340 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C341 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C342 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C343 NDC31HJ-270X C CAPACITOR 27pF 50V J
C344 NDC31HJ-270X C CAPACITOR 27pF 50V J
C361 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C376 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C377 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C701 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C702 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C801 NDC31HJ-300X C CAPACITOR 30pF 50V J
C802 NDC31HJ-270X C CAPACITOR 27pF 50V J
C803 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C804 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C805 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C806 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C807 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C809 NCB20JK-106X C CAPACITOR 10uF 6.3V K
C811 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C814 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C815 NEAF0JM-227X E CAPACITOR 220uF 6.3V M
C816 NDC31HJ-471X C CAPACITOR 470pF 50V J
C817 NCB21CK-105X C CAPACITOR 1uF 16V K
R101 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R102 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R201 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R202 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R203 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R204 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R205 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R206 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R207 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R208 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R209 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
