3-18
Loader board(FMU-VK1-1M)
Block No. [0][7]
R210 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R211 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R212 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R213 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R214 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R221 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R222 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R223 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R224 NRS181J-0R0X MG RESISTOR 0
Ω
1/8W J
R301 NRSA63J-563X MG RESISTOR 56k
Ω
1/16W J
R303 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R304 NRSA63J-563X MG RESISTOR 56k
Ω
1/16W J
R315 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R319 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R320 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R321 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R322 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R323 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R324 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
R325 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R326 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R327 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R328 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R329 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R330 NRSA02F-100X MG RESISTOR 10
Ω
1/10W F
R331 NRSA02F-100X MG RESISTOR 10
Ω
1/10W F
R336 NRSA63J-100X MG RESISTOR 10
Ω
1/16W J
R338 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R339 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R341 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R343 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R346 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R348 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R350 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R351 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R352 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R353 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R356 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R357 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R358 NRSA63J-105X MG RESISTOR 1M
Ω
1/16W J
R359 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R360 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R363 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R364 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R367 NRSA63J-563X MG RESISTOR 56k
Ω
1/16W J
R368 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R376 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R377 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R381 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R382 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R383 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R701 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R801 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R802 NRSA63J-200X MG RESISTOR 20
Ω
1/16W J
R803 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R804 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R805 NRSA63J-151X MG RESISTOR 150
Ω
1/16W J
R806 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R807 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R808 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R809 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R810 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R814 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R815 NRSA63J-200X MG RESISTOR 20
Ω
1/16W J
R816 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R817 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R819 NRSA63J-563X MG RESISTOR 56k
Ω
1/16W J
R820 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R821 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
CN101 QGF1016F8-16W CONNECTOR FFC/FPC (1-16)
CN102 QGA2001F6-06X CONNECTOR W-B (1-6)
CN701 QGF1016F8-19W CONNECTOR FFC/FPC (1-19)
CN801 QGF1016F8-07W CONNECTOR FFC/FPC (1-7)
CN802 QGA2001F6-05X CONNECTOR W-B (1-5)
K701 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K702 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K703 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
K704 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K705 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K706 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K801 NQR0360-002X COIL
K802 NQR0360-002X COIL
K803 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K804 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
X301 NAX0375-001X CRYSTAL 16.9344MHz
X801 NAX0832-001X CRYSTAL
Symbol No.
Part No. Part Name Description Local
CN1 QGF1040F1-05 CONNECTOR FFC/FPC (1-5)
CN1 or QGF1036F2-05 CONNECTOR FFC/FPC (1-5)
S1 QSW1074-002 DETECT SWITCH
Symbol No.
Part No. Part Name Description Local
To Next Page
