JVC UX-H100 Service Manual

2-2
US,UT,UW,UJ version
CN401
CN403
FRONT COMB board assy
BI635UXH10060
CN402
JK201
CN201
CN204
MAIN COMB board assy
BI652UXH10060
CN202
J3
J4
PIN1
W01
1P WITH TERMINAL WIRE
P/N:BI11AT125B0
JK202
IC202
CN203
PHONE OUTPUT
CONN assy 7P P=2.0MM L=140MM
PART NO:BI12P70079
FF-CABLE 12P P-1.0 L=(4+100+4)MM
PAR NO:BI120599
FF-CABLE 12P P=1.0 L=(4+60+4)MM
PART NO:BI1205981
CN704
J1
CN702
CW705
CN701
CONN 8PINS assy P=2.0MM
PART NO:BI12P80101
CN205
CONN assy 7P P=2.5MM L=190MM
PART NO:BI12P70080
POWER TRANSFORMER assy
BI697UXH10060
CASSETTE DECK 'ADR2080'
PART NO:BI3101561
CD COMB board assy
BI650UXH10050
CN703
CNN 6P AWG#28 L=55MM
PART NO:BI12P60154
CD MECH
CMS-B31BG6
CASSETTE
MOTOR
FF-CABLE 16P P=1.0 L=95MM PART NO:BI1205181
CONN assy 7PINS P=2.0MM
PART NO:BI12P70088
