General assembly
Block No. [M][1][M][M]
Symbol No.
Part No. Part Name Description Local
1 GV10127-003A FRONT PANEL
2 GV40077-002A JVC BADGE
3 GV20202-001A PUSH BUTTON
4 QYSBSF2608Z TAP SCREW 2.6mm x 8mm(x2)
5 QYSBSF2608Z TAP SCREW 2.6mm x 8mm(x2)
6 GV30423-001A LAMP CASE
7 GV40384-001A LCD FILTER
8 GV30402-001A LCD LENS
9 GV30349-009A SPACER
10 GV30424-001A DOOR HOLDER
11 GV40393-001A EJECT LEVER
12 GV40377-003A EJECT KNOB
13 QYSBSF2608Z TAP SCREW 2.6mm x 8mm
14 VKZ4323-202 SCREW (x2)
15 GV30421-001A TENSION SPRING
16 GV40394-002A EJECT ARM
17 VKZ4341-205 SPECIAL SCREW
18 GV40385-001A TORSION SPRING
19 QYSBSF3010Z TAP SCREW 3mm x 10mm(x2)
20 VKY4180-401 CASSETTE SPRING (x2)
21 VYH5601-001 GEAR
22 GV40386-001A DOOR SPRING
23 GV20198-003A CASSETTE HOLDER
24 GV30403-001A DOOR LENS
25 VKL7850-002 EJECT SAFTY(R)
26 VKW5258-003 TORSION SPRING
27 QYSBSF3012Z TAP SCREW 3mm x 12mm(x2)
28 QYSBST3008Z TH TAP SCREW 3mm x 8mm(x2)
29 KSM-213CCMJ CD MECHA ASSY
30 GV30412-001A PICK COVER
31 LV42763-001A INSULATOR (x2)
32 LV42763-002A INSULATOR (x2)
33 GV40379-001A CD M.HOLDER(L)
34 GV40379-002A CD M.HOLDER(R)
35 QYSBSF3010Z TAP SCREW 3mm x 10mm(x4)
36 GV40390-001A SHIELD
37 GV10134-001A CD CASE
38 VYH4769-002SS GEAR
39 GV40391-001A CD DOOR SPRING
40 GV40395-001A LOCK LEVER
41 GV40396-001A CD EJECT KNOB
42 GV20199-001A CD DOOR
43 QYSDSF2006Z SCREW 2mm x 6mm
44 GV40378-001A CD LENS
45 GV40423-002A CLAMPER BRACKET
46 LV33270-001A CLAMPER
47 VYH7313-005 P.C.MAGNET
48 VKL7757-001 YOKE
49 LV41741-001A SPECIAL SCREW
50 QYSBSF3010Z TAP SCREW 3mm x 10mm(x4)
51 GV40392-002A SHIELD
52 E3400-431 SPACER
53 GV10133-001A BOTTOM CHASSIS
54 QYSBST4006Z SCREW 4mm x 6mm(x4)
55 GV30404-001A JACK HOLDER
56 QYSBSF2608Z TAP SCREW 2.6mm x 8mm
57 GV30405-001A RADIATION
58 QYSBST3012Z SCREW 3mm x 12mm(x3)
59 QYSBST3006Z TAP SCREW 3mm x 6mm
60 QYSBST3006Z TAP SCREW 3mm x 6mm
61 QYSBST3006Z TAP SCREW 3mm x 6mm
62 GV30408-001A IC HOLDER
63 GV30422-001A SHIELD
64 QYSBST4006Z SCREW 4mm x 6mm
65 QYSBSG3006Z TAPPING SCREW 3mm x 6mm
66 LV30225-011A SPACER (x4)
67 GV10128-003A REAR PANEL
H30UP
67 GV10128-005A REAR PANEL
H30U,
H30UT,
H30U
W
68 GV20221-001A SIDE PANEL(L)
69 GV20218-001A SIDE PANEL (R)
70 QYSBSF3010Z TAP SCREW 3mm x 10mm(x2)
71 QYSBSF3010Z TAP SCREW 3mm x 10mm
72 QYSBSF3010Z TAP SCREW 3mm x 10mm
73 QYSBSF3010Z TAP SCREW 3mm x 10mm(x2)
74 QYSBSF3010Z TAP SCREW 3mm x 10mm
75 QYSBSF3010Z TAP SCREW 3mm x 10mm
76 QYSBSF3010Z TAP SCREW 3mm x 10mm
H30U,
H30UT,
H30U
W
77 QYSSST3008Z SCREW 3mm x 8mm(x4)
78 GV30230-003A UP LABEL
H30UP
78 GV30406-006A NAME PLATE
H30U,
H30UT,
H30U
W
79 E70891-001 CLASS 1 LABEL
80 LV41843-001A LASER CAUTION
81 QQT0396-002 POWER TRANSF T901
H30UP
81 QQT0396-003 POWER TRANSF T901
H30U,
H30UT,
H30U
W
82 QMF51W2-R50-J8 FUSE F901 0.5A AC250V
H30UP
82 QMF51W2-1R0-J8 FUSE T901 1A AC250V
H30U,
H30UT,
H30U
W
83 QMF51W2-6R3-J8 FUSE F902 6.3A AC250V
H30U,
H30UT,
H30U
W
84 QMF51W2-6R3-J8 FUSE F903 6.3A AC250V
85 QUQH12-0411BJ FFC WIRE
86 QUQH12-0714AJ FFC WIRE
87 QUQH12-0909BJ CARD WIRE
88 QUQH12-0913BJ FFC WIRE
89 QUQH12-1022BJ FFC WIRE
90 E3400-431 SPACER
91 QUQH12-1406BJ FFC WIRE
92 QUQ110-1607AJ FFC WIRE
93 GV30497-001A UT LABEL
H30UT
Symbol No.
Part No. Part Name Description Local
To Next Page
