SECTION 2
Disassembly method
2.1 Main body
2.1.1 Removing the metal cover
(See Fig.1~3)
(1) Remove the six screws A on the back of the main body.
(2) Remove the two screws B on each side and remove the
metal cover in the direction of the arrow.
Fig.1
Fig.2
Fig.3
Metal cove
r
A
A
A
B
B
