5
English
Y
P
B
P
R
S-VIDEO
VIDEO
VIDEO OUT
VIDEO
OUT
SELECT
PAL
NTSC
PUSH
OPEN
AUTO REVERSE
FM antenna (supplied)
Extend it so that you can obtain
the best reception.
AM loop antenna (supplied)
Turn it until the best reception is
obtained.
To a wall outlet
Plug the AC power cord only after all connections and
selector settings on the rear are complete.
Before plugging in the System
Set the correct voltage for your area with the voltage
selector on the rear.
Use a screwdriver to rotate the voltage selector so
that the voltage marker is pointing at the same
voltage as where you are plugging in the unit. (See
also the back cover page.)
Voltage marker
DO NOT plug in before setting
the voltage selector and all
connection procedures are
complete.
Connection.fm Page 5 Wednesday, May 19, 2004 5:53 PM
To Next Page
