JVC UX-V10GN

1-30
UX-V10GN
GP1U271X (IC701) : Receiver for remote
+
–
GND
B.P.F
VCC Vout
Amp.
Limiter Integrator Comparator
Demodulator
1 2 3 4 5 6 7 8 9
10
GND OUT1 P1
VZ IN1 IN2
VCC1
VCC2 P2
OUT2
Input Output
Mode
IN1 IN2 OUT1 OUT2
Brake
0 0 0 0
1 0 1 0
0 1 0 1
1 1 0 0
CLOCKWISE
COUNTER-CLOCKWISE
Brake
LB1641 (IC501) : DC Motor Driver
1. Pin Layout
2. Pin Functions
