JVC UX-V30 User Manual

3-4
I
HA
BC
DE
F
G
1
2
3
4
5
6
UX-V30 UX-V30
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M1MM
1 GV10020-018A FRONT PANEL 1
2 GV40067-001A REMOTE LENS 1
3 GV40068-001A STANDBY LENS 1
4 GV30060-003A FRONT BUTTON AS 1 F.BTN+FUNC.BTN
5 GV40116-002A FRONT LENS ASSY 1
6 GV30063-001A POWER BUTTON 1
7 GV30064-001A VOLUME BUTTON 1
8 QYSDSF2608Z SCREW 8 SW.PWB+FR.PANEL
9 GV20044-012A CD DOOR LENS 1
10 GV40077-001A JVC BADGE 1
11 GV30065-001A CD DOOR PLATE
(
L 1
12 GV30065-002A CD DOOR PLATE
(
R 1
13 GV30066-001A CD DOOR HOLDER 1 DOOR LEFT
14 GV30066-002A CD DOOR HOLDER 1 DOOR RIGHT
15 QYSDSF2006M SCREW 8 CD DOOR ASSY
16 GV20046-006A CD CHASSIS 1
17 QYSDSF2608Z SCREW 2 CD PWB+CD CHASI
18 GV40072-003A WORM PULLEY 1
19 GV30038-001A BELT 1
20 GV40071-002A GEAR 1
21 GV40070-002A INSULATOR 3
22 KSM-770ABA CD MECHA 1
23 QYSDSF2608Z SCREW 1 ILM PWB L+CD CH
24 GV20045-005A CD CASE 1
25 MXN-13FB12F DC MOTOR ASS'Y 1
26 QYSPSP3004Z SCREW 2 MOTOR+CD CHASSI
27 VYH7699-001SS PULLEY 1
28 QYSDSF2608Z SCREW 5 CD CHASSIS+CD C
29 WJM0112-001A MOTOR WIRE 1
30 QYSDSF2608Z SCREW 5 CD CHASSIS+F.PA
31 GV10021-001A BOTTOM CHASSIS 1
32 QYSBST4006Z T.SCREW 4 TRANS+B.CHASSIS
33 GV30073-001A JACK HOLDER 1
34 QYSBSTG3006Z T.SCREW 1 M.BRD+B.CHASSIS
35 QYSBSTG3006Z T.SCREW 2 AC J.PWB+B.CHAS
36 FMYH4004-001 PLASTIC RIVET 1 H.P.PWB+B.CHASS
37 QQT0284-003 POWER TRANSF. 1
38 QMF51E2-R63-J1 FUSE
A
1
(
F901
)
39 QMF51E2-6R3-J1 FUSE
A
1
(
F902
)
40 QUQ412-0908DJ FFC WIRE 1 TU TO FMB
41 QUQ412-1022CJ FFC WIRE 1 CD TO MAIN
42 QUQ412-1320CJ FFC WIRE 1 CD TO FMB
43 QUQ110-1607BJ FFC WIRE 1 PICKUP TO CD
44 GV40111-001A PROTECT SHEET 1
45 GV10022-001A TOP COVER 1
46 GV20047-001A CASSETTE DOOR 1
47 GV40074-001A CASSETTE LENS 1
48 VYH7366-001MM GEAR 1
(General assembly)
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M1MM
49 GV40073-001A EJECT KNOB 1
50 GV40085-002A DOOR SPRING 1
51 ----------- S.CASSETTE MECH 1
52 VYH3965-001 SIDE BRACKET
(
R
)
1
53 VKL7850-002 EJECT SAFTY
(
R
)
1
54 VKW5258-003 TORSION SPRING 1
55 VYH8146-012 EJECT ARM
(
R
)
1
56 VKW3006-230 TORSION SPRING 1
57 VKZ4341-004 SPECIAL SCREW 1
58 GV30071-001A HEAD SHIELD 1
59 QYSBSF2606Z SCREW 2 H.SHIELD+SLC.ME
60 VKZ4001-110S WIRE HOLDER 1
61 QYSBSF3010Z SCREW 4 SLC + TOP COVER
62 GV30068-001A HEAT SINK 1
63 QYSPSF3010Z TAP SCREW 3 H.SINK+IC HOLDE
64 QYSSSF3008Z SCREW 2 T.COVER+F.PANEL
65 GV20048-001A SIDE PANEL
(
L
)
1
66 GV20048-002A SIDE PANEL
(
R
)
1
67 GV10023-009A REAR PANEL 1
68 QYSSST3010Z SCREW 2
69 QYSBSF3010Z TAP SCREW 7 REAR PANEL
70 GV30099-039A NAME PLATE 1
71 GV40091-001A FOOT 4
72 VND4118-004 CAUTION LABEL 1
73 QYSDSF2608Z SCREW 2 L.CASE+F.PANEL
74 QYSBSTG3006Z T.SCREW 1 TUNER PWB+B.CHA
75 QUQ412-1024CJ FFC WIRE 1 SLC TO MAIN
76 QUQ412-0924CJ FFC WIRE 1 SLC TO MAIN
77 QYSSST3010Z SCREW 2 F.PANEL+B.CHASS
78 VYH7237-002 I.C.COVER 1
79 QYSBSF3010N TAP SCREW 4 TUNER TER+B.CHA
80 GV30070-002A LAMP CASE 1
81 GV40084-002A L.C.D.SHEET 1
82 QYSBSFG3008Z T.SCREW 1 M.BOARD+ IC HOL
83 QYSBSF2606Z SCREW 2 DC PWB+T.COVER
84 QYSBSG3008Z T.SCREW 1 SLC+SIDE BKT.
86 GV40122-002A FOOT SPACER 1 STICK AT CD MEC
(General assembly)
