JVC VCB008 - External Device; Listening to an External Device

18
Listening to an external device
1. Set the volume level of the System to
minimum.
2. Connect the external device.
Refer also to the instruction manual for the
external device.
3. Press AUDIO IN to select ”AUDIO IN.”
4. Start playback of the external device.
5. Adjust the volume of the System and of
the external device.
Adjusting the audio input level
Adjust the audio input level when the volume
of the external device is too low compared to
other sources.
When AUDIO IN is selected as the source,
press SET.
Each time you press the button, the input level
changes as follows:
LEVEL1
\ LEVEL2 \ LEVEL3 \ (back to the
beginning)
A higher number indicates a greater increase
in input level.
The initial setting is "LEVEL 3."
Main unit
(Press repeatedly)
Remote control
External device
External
device(not
supplied)
Headphone
jack, etc.
Stereo mini
plug cord
(not
supplied)
