56
English
Main Specifications
CD Player Section
System Compact disc digital audio system
Readout system Non-contact optical readout (using semiconductor laser)
Error correction system CIRC
Number of channels 2
Pitch control ±12%
Total harmonic distortion (1 kHz) 0.009%
Dynamic range (1 kHz) 90 dB
Signal-to-noise ratio 94 dB
Frequency response 8Hz ~ 20 kHz
Wow and flutter Less than measurable limit
MD Recorder Section
System Mini-disc digital audio system
Recording system Magnetic field modulation overwrite system
Signal readout system Non-contact optical system using semiconductor laser (λ = 780nm)
Sound compression system ATRAC system
Number of channels 2
Wow and flutter Less than measurable limit
Sampling frequency 44.1 kHz
Frequency response 8 Hz ~ 20 kHz
Inputs: Analog (LINE IN) Minimum input level: 300 mV (Full scale –12 dB)/50 kΩ
Digital (optical) Input level: –23 dBm – –15 dBm
Microphone Minimum input level: 3 mV (Full scale –12 dB)/600-10 kΩ matching
impedance
Dynamic range (1 kHz) 88 dB (during play)
Signal-to-noise ratio 88 dB (during play)
Timer Section
Timer system Once-a-day operation (ON/OFF timer)
Clock display 12-hour display
Common Specifications
Output connectors: Analog LINE x 1 set, 2 V/5 kΩ (Full scale)
Headphones x 1, 4 mW/32 Ω, 8 Ω – 1 kΩ matching impedance
Digital OPTICAL x 1, –21 dBm ~ –15 dBm
Other connectors COMPU LINK-3/SYNCHRO x 2
TEXT COMPU LINK x 2
Power requirements AC 120 V (60 Hz)
Power consumption 15 W in power ON mode; 6 W in STANDBY mode
Dimensions 17-3/16" x 5 x 12-1/2" inches (W x H x D)
(435 x 127 x 316 mm)
Mass Approx. 13.3 lbs (6.0 kg)
Accessories
Remote control (RM-XU301U) (1)
R03, size “AAA” or UM4 dry batteries (to check operation of remote control
) (
2)
Pin cords (2)
COMPU LINK-3 cable (1)
TEXT COMPU LINK cable (1)
• This unit is licensed under the U.S. and foreign patents of Dolby Laboratories Licensing Corpora-
tion.
The unit’s specifications and exte-
rior are subject to change without
notice due to improvements.
