JVC XV-521BK - Page 41

SERVICE MANUAL
No.20836
XV-521BK/523GD
XV-525BK/421BK
XV-521BK/523GD
XV-525BK/421BK
Contents
Safety precautions
Importance administering
point on the safety
Dismantling and assembling
the traverse unit
Disassembly method
Precautions for service
Description of major ICs
1-2
1-3
1-4
1-5
1-15
1-16
VICTOR COMPANY OF JAPAN, LIMITED
OPTICAL DISC BUSINESS DIV. PERSONAL & MOBILE NETWORK BUSINESS UNIT
AV & MULTIMEDIA COMPANY 1644, Shimotsuruma, Yamato, Kanagawa 242-8514, Japan
DVD PLAYER
No.20836
Jun. 2000
COPYRIGHT 2000 VICTOR COMPANY OF JAPAN, LTD.
Printed in Japan
2000 06 (S)
XV-521BK/523GD
XV-525BK/421BK
J U.S.A
Area Suffix
XV-525BK/523GD
J U.S.A
C Canada
Area Suffix
XV-521BK
Area Suffix
XV-421BK
