JVC XV-521BK Service Manual

XV-521BK/523GD/525BK/421BK
3-5
Item Parts number Parts name Area
A
Parts list (General assembly)
Q'ty Description
Block No. M1MM
38 LV41363-002A HOLDER 1
FOR HEAT SINK
39 QYSBSGG3006E SCREW 1
MODULE + CHASSIS
40 E408621-002 FASTENER 1
41 E309322-001SC STAND
(
L
)
1
MECHA FORE SIDE
42 E309321-001SC STAND
(
R
)
1
MECHA FORE SIDE
43 QYSBST3020Z T.SCREW 2
MECHA + CHASSIS
44 E309323-001SC STAND
(
REAR
)
1
MECHA REAR SIDE
45 QYSBST3020Z T.SCREW 1
MECHA + CHASSIS
46 QUQ605-4015AJ FFC WIRE 1
MECHA --> MODUL
47 LV20698-025A REAR PANEL 1
XV-523GD
LV20698-023A REAR PANEL 1
XV-525BK
LV20698-022A REAR PANEL 1
XV-521BK
LV20698-024A REAR PANEL 1
XV-421BK
48 QYSBSGY3008M SPECIAL SCREW 3
REAR + CHASSIS
49 QYSBSGY3008M SPECIAL SCREW 1
XV-525BK/521BK/523GD
50 QYSBSGY3008M SPECIAL SCREW 2
LEFT & RIGHT ON
51 QYSBSGY3008M SPECIAL SCREW 1
XV-525BK/521BK/523GD
52 QYSBSGY3008M SPECIAL SCREW 1
FOR GND TERMINA
53 QYSBSGY3008M SPECIAL SCREW 1
AC INLET
54 QMF51U1-1R6-J8 FUSE
A
1
55 LE20082-002A/S/ METAL COVER 1
XV-523GD
LE20082-004A/S/ METAL COVER 1
XV-525BK/521BK/421BK
56 QYSBSGY3008E SPECIAL SCREW 2
METAL + REAR
57 E406308-003 SPECIAL SCREW 4
XV-525BK/521BK/421BK
E406308-004 SPECIAL SCREW 4
XV-523GD
58 LE30714-001A SHUTTLE KNOB 1
XV-525/521BK
LE30714-005A SHUTTLE KNOB 1
XV-523GD
59 LV20631-001A TRAY FITTING 1
XV-525/521BK
LV20631-002A TRAY FITTING 1
XV-523GD
LV20631-003A TRAY FITTING 1
XV-421BK
60 LE40564-002A MARK 1
XV-525BK/521BK/523GD
61 LV31791-001A PUSH BUTTON
(
E
)
1
XV-421BK
62 QLF0064-001 FL TUBE 1
DI801
63 E308192-331 FL HOLDER 1
BK801
64 E306805-134 SPACER 1
