JVC XV-521BK Service Manual

XV-521BK/523GD/525BK/421BK
3-7
Item Parts number Parts name Area
A
Parts list (DVD mechanism)
Q'ty Description
Block No. M2MM
1 LV20638-001A MECHA BASE 1
2 LV20635-001A SHAFT HOLDER 1
3 QYSBST2606M T.SCREW 1
4 VDG1099001TSVME SP. MOTOR ASS'Y 1
5 QUM193-08B2B2 PARA RIBON WIRE 1
6 QYSBST2606M T.SCREW 1
FOR
S
.B
AS
E&M.B
A
7 OPTIMA-2010A1 DVD PICKUP 1
8 LV31670-001A SWITCH ACTUATOR 1
9 LV31666-002A LEAD SPRING 1
10 QYSPSGT2040M SCREW 1
11 LV31743-002A P.U. SPRING 1
12 QYSPSGT1416M MINI SCREW 1
13 LV41121-002A SHAFT 1
MAIN SHAFT
14 LV41121-002A SHAFT 1
SUB SHAFT
15 LV41732-001A SKEW SPRING 3
16 LV31669-001A SHAFT STOPPER R 2
17 LV31668-001A SHAFT STOPPER F 1
18 QYSPST2614M SCREW 2
FOR SSTOPER R
19 QYSPST2614M SCREW 1
FOR SSTOPER F
20 LV31746-003A FEED HOLDER ASY 1
21 QAR0127-001 FEED MOTOR 1
22 LV41510-001A FEED GEAR T 1
23 QYSPSPU2040M SCREW 1
FOR F.M
24 LV41512-001A FEED GEAR E 1
25 LV41517-001A LEAD SCREW 1
26 LV41511-002A FEED GEAR M 1
27 LV31667-001A THRUST SPRING 1
28 QYSPSPU2040M SCREW 1
FOR F.M
29 QYSBST2606M T.SCREW 2
FOR F.HOLDER
30 QYYASPF2608N HEX SCREW 3
FOR TILT ADJUST
31 QYSBST2606M T.SCREW 1
FOR PW BOARD
