XV-521BK/523GD/525BK/421BK
3-9
Item Parts number Parts name Area
A
Parts list (DVD loading base)
Q'ty Description
Block No. M3MM
1 E102357-441 LOADING BASE 1
2 MMN-6F1LB8K MOTOR 1
3 E75984-001SC MOTOR PULLEY 1
4 QYSPSPT2640Z MINI SCREW 2
5 E75950-002 BELT 1
6 E75985-222SS GEAR
(
1
)
1
7 E60912-005SS SPEED NUT 1
8 E75986-221SS GEAR
(
2
)
1
9 E75987-221SS GEAR
(
3
)
1
10 E307162-331 LEVER 1
11 E307252-331 CAM PLATE 1
12 E65923-003 TAPPING SCREW 1
13 E75989-001 SPRING 1
14 QYSBSF3008Z SCREW 1
15 E307179-332 E.BASE ASS'Y 1
16 LV30225-089A SPACER 2
17 LV41527-001A INSULATOR 2
18 LV41527-002A INSULATOR 2
19 E406871-001 SPRING 2
20 LV30226-019A SPACER 2
21 E65923-003 TAPPING SCREW 2
22 QYSBSFG3008Z T.SCREW 1
23 LV41961-001A TRAY TUBE 1
24 EMW10095-003 P.C.BOARD 1
LOADING MOTOR
25 QGA2001F1-05 5P PLUG ASSY 1
26 QSW0472-001 SWITCH 1
