JVC XV-THA85 Service Manual

3-17
Block No. [0][4][0][0]
 Symbol No. Part No. Part Name Description Local
 Q151 KTC3203/OY/-T TRANSISTOR
Q501 KRA104M-T DIGI TRANSISTOR
Q502 KRC102M-T DIGI TRANSISTOR
Q503 KTC3199/GL/-T TRANSISTOR
Q504 KTA1267/YG/-T TRANSISTOR
Q505 KRC102M-T DIGI TRANSISTOR
Q511 KRC104M-T TRANSISTOR
Q512 KTC3199/GL/-T TRANSISTOR
Q513 KTC3199/GL/-T TRANSISTOR
Q514 KRA102M-T DIGI TRANSISTOR
Q515 KTC3203/OY/-T TRANSISTOR
Q516 KTC3199/GL/-T TRANSISTOR
Q517 KRC104M-T TRANSISTOR
Q521 KRA104M-T DIGI TRANSISTOR
Q522 KTC3199/GL/-T TRANSISTOR
Q523 KTC3199/GL/-T TRANSISTOR
Q524 KTA1267/YG/-T TRANSISTOR
Q525 KTC3199/GL/-T TRANSISTOR
Q531 KTC3199/GL/-T TRANSISTOR
Q532 KTC3199/GL/-T TRANSISTOR
Q545 KRC102M-T DIGI TRANSISTOR
D101 1SS133-T2 DIODE
 D151 GBU803 BRIDGE DIODE
 D152 GBU803 BRIDGE DIODE
D153 1SS133-T2 DIODE
D154 1SS133-T2 DIODE
D161 1SS133-T2 DIODE
D162 MTZJ13C-T2 Z DIODE
D401 11ES2-T4 DIODE
D402 1SS133-T2 DIODE
D403 MTZJ6.2B-T2 Z DIODE
D501 1SS133-T2 DIODE
D502 1SS133-T2 DIODE
D503 MTZJ5.1C-T2 Z DIODE
D504 1SS133-T2 DIODE
D505 1SS133-T2 DIODE
D511 1SS133-T2 DIODE
D512 1SS133-T2 DIODE
D513 1SS133-T2 DIODE
D514 1SS133-T2 DIODE
D515 MTZJ15C-T2 Z DIODE
D516 1SS133-T2 DIODE
D517 MTZJ27B-T2 Z DIODE
D518 MTZJ27B-T2 Z DIODE
D519 1SS133-T2 DIODE
D520 MTZJ3.6A-T2 ZENER DIODE
D521 1SS133-T2 DIODE
D522 1SS133-T2 DIODE
D523 1SS133-T2 DIODE
D524 1SS133-T2 DIODE
D525 MTZJ15C-T2 Z DIODE
D526 MTZJ6.2B-T2 Z DIODE
D535 1SS133-T2 DIODE
C101 QCZ9105-472 C CAPACITOR 4700pF 250V M
C151 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C152 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C153 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C154 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C155 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C156 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C161 QEZ0223-478 E CAPACITER 4700uF
C162 QEZ0223-478 E CAPACITER 4700uF
C163 QETM1EM-688 E CAPACITOR 6800uF 25V M
C164 QETM1EM-688 E CAPACITOR 6800uF 25V M
C165 QETN1EM-476Z E CAPACITOR 47uF 25V M
C166 QETN1EM-107Z E CAPACITOR 100uF 25V M
C501 QETN1HM-335Z E CAPACITOR 3.3uF 50V M
C502 QFN31HJ-103Z M CAPACITOR 0.01uF 50V J
C503 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C511 QETN1CM-227Z E CAPACITOR 220uF 16V M
C512 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C521 QETN1HM-226Z E CAPACITOR 22uF 50V M
C522 QETN1HM-106Z E CAPACITOR 10uF 50V M
C523 QETN1EM-476Z E CAPACITOR 47uF 25V M
C531 QETN1HM-106Z E CAPACITOR 10uF 50V M
C532 QCF31HZ-103Z C CAPACITOR 0.01uF 50V Z
C533 QCF31HZ-103Z C CAPACITOR 0.01uF 50V Z
R151 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R152 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R153 QRL027J-391 OMF RESISTOR 390
Ω 2W J
 R161 QRZ9005-100X F RES I/M 10 Ω
R162 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
 R491 QRL027J-470 OMF RESISTOR 47 Ω 2W J
R492 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R501 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R502 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R503 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R504 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R505 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R506 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R510 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R511 QRE141J-753Y C RESISTOR 75k Ω 1/4W J
R512 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R513 QRE141J-101Y C RESISTOR 100
Ω 1/4W J
R514 QRE141J-753Y C RESISTOR 75k
Ω 1/4W J
R515 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R516 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R517 QRE141J-224Y C RESISTOR 220k Ω 1/4W J
R518 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R519 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R520 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R521 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R522 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R531 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R532 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R533 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R534 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R535 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R536 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R537 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R538 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R539 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R541 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R543 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R544 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R545 QRE141J-123Y C RESISTOR 12k Ω 1/4W J
R546 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R547 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R548 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R549 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R550 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
 R555 QRZ9005-271X FUSI RESISTOR 270 Ω
R556 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R557 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R561 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R562 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R563 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R564 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R565 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R566 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
 CN101 QGA7901C1-02 CONNECTOR W-B (1-2)
 CN102 QGA7901C1-02 CONNECTOR W-B (1-2)
 CN151 QGA3901C1-05 CONNECTOR W-B (1-5)
CN401 QGB2510K2-08 CONNECTOR B-B (1-8)
CN402 QGA3901F2-04 CONNECTOR W-B (1-4)
CN403 QGB2510K2-14 CONNECTOR B-B (1-14)
CN404 QGB2510K2-18 CONNECTOR B-B (1-18)
CN501 QGB2510J1-08 CONNECTOR B-B (1-8)
CN503 QGB2510J1-14 CONNECTOR B-B (1-14)
CN504 QGB2510J1-18 CONNECTOR B-B (1-18)
CN521 QGB2510J1-07 CONNECTOR B-B (1-7)
CN522 QGB2510J1-18 CONNECTOR B-B (1-18)
CN531 QGB2510J1-07 CONNECTOR B-B (1-7)
CN532 QGB2510J1-18 CONNECTOR B-B (1-18)
FC101 QNG0003-001Z FUSE CLIP
FC155 QNG0003-001Z FUSE CLIP
FC157 QNG0003-001Z FUSE CLIP
HS151 QZW0115-001 HEATSINK
J401 QND0118-001 DIN CONNECTOR
J402 QNB0162-002 SPK TERMINAL
 Symbol No. Part No. Part Name Description Local

JVC XV-THA85 Specifications

General

Brand	JVC
Model	XV-THA85
Category	Home Theater System
Language	English
