JVC XV-THA85 Service Manual

3-18
Module board
Block No. [0][5][0][0]
J403 QNB0161-002 SPK TERMINAL
J404 QNB0162-002 SPK TERMINAL
K401 QQR1277-001Z COIL
 RY101 QSK0142-001 RELAY
RY401 QSK0127-001 RELAY
RY402 QSK0127-001 RELAY
RY403 QSK0127-001 RELAY
 Symbol No. Part No. Part Name Description Local
IC101 AN8703FH-V IC
IC201 BA5983FM-X IC
IC251 BA6679FM-X LSI
IC301 MN103S26EGA IC
IC401 MN102L62GLF3 IC
IC451 S-93C66AFJ-X IC
IC501 NDV8601VWA-BE IC
IC505 or K4S643232F-TC70 IC
IC505 K4S643232F-TC60 IC
IC505 or HY57643220CT7 IC
IC505 or HY57643220CT55 IC
IC509 SST39VF160-7CEK IC (FLASH)
IC509 or SST39VF160-9DD IC
IC510 AK93C65AF-X IC
IC511 LM1117MP1.8-X IC
IC512 74LCX373MTC-X IC(DIGITAL)
IC513 74LCX373MTC-X IC(DIGITAL)
IC521 MM74HCT32MTC-X IC
IC522 74LCX32MTC-X IC(DIGITAL)
IC523 NC7SZ125P5-X IC(DIGITAL)
Q101 KTA1001/Y/-X TRANSISTOR
Q102 KTA1001/Y/-X TRANSISTOR
Q103 DTA144EE-X DIGI TRANSISTOR
Q501 2SB1424/QR/-W TRANSISTOR
Q502 2SC2412K/RS/-X TRANSISTOR
D101 RB521S-30-X SB DIODE
D202 1SS355-X SI DIODE
C105 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C106 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C109 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C110 NCS31HJ-221X C CAPACITOR 220pF 50V J
C111 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C112 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C113 NEA70JM-226X E CAPACITOR 22uF 6.3V M
C115 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C116 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C117 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C118 NCB31CK-273X C CAPACITOR 0.027uF 16V K
C119 NCB31HK-561X C CAPACITOR 560pF 50V K
C120 NCB31HK-561X C CAPACITOR 560pF 50V K
C121 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C122 NCS31HJ-120X C CAPACITOR 12pF 50V J
C123 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C124 NCS31HJ-470X C CAPACITOR 47pF 50V J
C125 NCB31HK-271X C CAPACITOR 270pF 50V K
C126 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C127 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C128 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C129 NCB31HK-472X C CAPACITOR 4700pF 50V K
C135 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C137 NEA70GM-476X E CAPACITOR 47uF 4V M
C138 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C139 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C141 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C142 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C143 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C144 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C146 NCB31CK-104X C CAPACITOR 0.1uF 16V K
 Symbol No. Part No. Part Name Description Local
C201 NEA70JM-226X E CAPACITOR 22uF 6.3V M
C203 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C204 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C205 NCS31HJ-121X C CAPACITOR 120pF 50V J
C207 NCB31HK-391X C CAPACITOR 390pF 50V K
C208 NCB31HK-391X C CAPACITOR 390pF 50V K
C211 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C212 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C215 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C216 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C217 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C218 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C251 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C252 NEA71AM-336X E CAPACITOR 33uF 10V M
C253 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C255 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C256 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C257 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C258 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C259 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C260 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C261 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C262 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C263 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C264 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C301 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C302 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C303 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C304 NEA70GM-107X E CAPACITOR 100uF 4V M
C306 NEA70GM-107X E CAPACITOR 100uF 4V M
C308 NEA70GM-107X E CAPACITOR 100uF 4V M
C310 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C311 NCB31HK-561X C CAPACITOR 560pF 50V K
C312 NCB31HK-561X C CAPACITOR 560pF 50V K
C313 NCB31HK-561X C CAPACITOR 560pF 50V K
C314 NCB31HK-331X C CAPACITOR 330pF 50V K
C315 NCB31HK-471X C CAPACITOR 470pF 50V K
C316 NCB31HK-271X C CAPACITOR 270pF 50V K
C317 NCS31HJ-121X C CAPACITOR 120pF 50V J
C318 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C319 NCB31HK-102X C CAPACITOR 1000pF 50V K
C320 NCB31HK-102X C CAPACITOR 1000pF 50V K
C321 NCB31HK-102X C CAPACITOR 1000pF 50V K
C322 NCB31HK-562X C CAPACITOR 5600pF 50V K
C323 NCB31HK-102X C CAPACITOR 1000pF 50V K
C324 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C325 NCS31HJ-470X C CAPACITOR 47pF 50V J
C326 NCB31CK-183X C CAPACITOR 0.018uF 16V K
C327 NCB31HK-102X C CAPACITOR 1000pF 50V K
C328 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C329 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C330 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C331 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C332 NCB21CK-105X C CAPACITOR 1uF 16V K
C333 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C334 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C337 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C338 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C339 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C340 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C341 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C342 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C343 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C344 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C345 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C346 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C347 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C348 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C349 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C350 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C401 NEA70GM-476X E CAPACITOR 47uF 4V M
C402 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C403 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C404 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C405 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C406 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C407 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C450 NCB31CK-104X C CAPACITOR 0.1uF 16V K
 Symbol No. Part No. Part Name Description Local
