Caution: Proper Ventilation
To avoid risk of electric shock and fire and to protect from damage,
locate the apparatus as follows:
Top: No obstructions and open spacing.
Sides/Front/Back: No obstructions should be placed in the areas
shown by the dimensions below.
Bottom: Place on the level surface. Maintain adequate air
path for ventilation by placing on a stand with a
height of 10 cm more.
XV-THV70
XV-THV70
SP-PWV70
Front view
Side view
Wall or
obstructions
Floor
Front
